PB287Q can support true 4K UHD content at refresh rate via DisplayPort 1.2.
One Display, Two Sources
Build-in Picture-in-Picture (PiP) and Picture-by-Picture (PbP) functionality let you view content from two different sources simultaneously, with the ability to switch video between sources easily. PiP mode places the second input source window in one corner of the display, while PbP mode splits the screen down the middle.
Picture-in-Picture (PiP) mode places the second input source window in one corner of the display you are allowed to place the second input source window in either top right or bottom right.
Picture-by-Picture (PbP) mode splits the screen down the middle to display content from two separate sources side-by-side to view images from different signals and easily switch between the main and PbP source, including audio.
Innovations That Raise the Bar
ASUS-exclusive Technologies for Stunning Image Quality
Weve raised the bar by incorporating some of our proprietary technologies into the ASUS PB287Q to give you a truly vivid visual experience. The PB287Q features the new SplendidPlus Video Intelligence Technology that optimizes videos and images by enhancing color brightness, contrast, and sharpness. SplendidPlus features two new modes Reading and Darkroom in addition to the Scenery, Standard, Theater, sRGB, and Night View modes. Low-blue Light and Flicker-free technologies also reduce the strain on your eyes after long-time usage.
Reading
Creating comfortable experience as if reading actual books by adjusting the monitors color temperature and brightness levels, simulating paperback books.
Darkroom
Best choice for soft ambient light environment for visual pleasure.
Scenery
Increases the brightness range, introducing more contrast gradations and selectively tweaking color saturation for more lush landscapes.
Theater
Enhances the contrast and color saturation of the image delivering livelier and more vivid visuals for greater immersion.
sRGB
Provides the best performance for viewing graphics.
Game
Brings out dark, hard-to-see areas while leaving well-lit portions untouched allowing you to see opponents lurking in obscure corners.
Night View
Intelligently raises Y-luminance to highlight poorly-lit details, capturing each scenes beauty in a crisp and vibrant fashion.
Standard
Delivers clear document viewing and web browsing experiences with optimized color and contrast.
ASUS SplendidPlus Video Intelligence Technology is built upon a color engine that provides 8 preset modes that allow you to adjust your display accordingly to ensure color accuracy and image fidelity to give you colors that best suit whats showing on the screen. You can access different modes via a designated hotkey.
Conventional monitors without the flicker-free technology
PB287Q True 4K UHD Monitor with the flicker-free technology
The PB287Q also equipped with the latest ASUS display technology: ASUS EyeCare Technology. The EyeCare technology adopts new Flicker-free technology by utilizing DC adjustment backlighting, which clears out the distracted flicker shown on the screen and delivers a more comfortable viewing experience. EyeCare technology is also the basis of the Reading and Darkroom modes in SplendidPlus; these profiles effectively reduce the level of blue light, ensuring less eyestrain and healthier eyes.
Conventional monitors without the ASUS VividPixel Technology
PB287Q True 4K UHD Monitor with the ASUS VividPixel Technology
ASUS VividPixel Technology adds to the PB287Qs crystal-clear and detailed visuals by enhancing image outlines and reducing noise bars.
ASUS QuickFit Virtual Scales onscreen alignment grid overlay also helps you align and preview actual-size photos and documents on screen prior to printing, thereby adding to the overall flexibility and productivity aspects of the PB287Q display.
Support Formats:
Document: B5, A4, Letter,
Grid: Alignment
Photo: 8x10, 5x7, 4x6, 3x5, 2x2
Say Hello to Extraordinary Comfort
Your Viewing Experience Matters
The PB287Q features a slim profile and an ergonomically-designed stand with tilt, swivel, pivot, and height adjustments so you can always find that ideal viewing position.
Specifications
- Display
Panel Size: Wide Screen 28"(71.12cm) 16:9
True Resolution : 3840x2160 at 60Hz (DisplayPort) ,3840x2160 at 30Hz (HDMI)
Pixel Pitch : 0.16mm
Brightness(Max) : 300 cd/
ASUS Smart Contrast Ratio (ASCR) : 100000000:1
Viewing Angle (CR10) : 170(H)/160(V)
Response Time : 1ms (Gray to Gray)
Display Colors : 1073.7M (10bit)
LCD ZBD Warranty : Yes
- Video Feature
Trace Free Technology
SPLENDID Video Intelligence Technology
SPLENDID Video Preset Modes : 8 Modes (sRGB Mode/Scenery Mode/Theater Mode/Standard Mode/Night View Mode/Game Mode/Reading Mode/Darkroom Mode)
Skin-Tone Selection : 3 Modes
Color Temperature Selection : 4 Modes
QuickFit (modes) : Yes ( Modes)
GamePlus(modes) : Yes (Aimpoint/Timer)
Picture-in-Picture
Picture-by-Picture
HDCP support
VividPixel
- Audio Features
Stereo Speakers : 2W x 2 Stereo RMS
- Convenient Hotkey
SPLENDID Video Preset Mode Selection
Auto. Adjustment
Brightness Adjustment
Contrast Adjustment
Volume Adjustment
Input Selection
Picture-in-Picture
QuickFit
- I/O Ports
Signal Input : HDMI , HDMI/MHL, DisplayPort
PC Audio Input : 3.5mm Mini-Jack
Earphone jack : 3.5mm Mini-Jack (for HDMI & DisplayPort Only)
- Signal Frequency
Digital Signal Frequency : 24~99KHz(H) / 30~75Hz(V)
- Power Consumption
Power ON (Typical): < 60W*
Power Saving Mode : < 0.5W
Power Off Mode : < 0.5W
Voltage : 100240V, 50 / 60 Hz
- Mechanical Design
Chassis Colors : Black
Tilt : +20~-5
Swivel : Yes
Pivot : Yes
Height Adjustment : Yes
VESA Wall Mounting : 100x100mm
- Security
Kensington lock
- Dimensions
Phys. Dimension with Stand(WxHxD): 660x414(lowest)x220.06 mm
Phys. Dimension without Stand(WxHxD): 660.26x380.67x63.55 mm
Box Dimension (WxHxD): 764x465x224 mm
- Weight
Net Weight (Esti.) : 7.9kg
Gross Weight (Esti.) : 10.6kg
- Accessories
Cable Clamp
Audio cable
Power cord
DisplayPort cable (Optional)
Quick start guide
HDMI cable (Optional)
Warranty Card
MHL cable (Optional)
- Regulation Approval
Energy Star, BSMI, CB, CCC, CE, CEL level 1, C-Tick, CU, ErP, FCC, ISO-9241-307, RoHS, TCO6.0, UL/cUL, VCCI, WEEE, WHQL (Windows 8, Windows 7)
- Note
*Based on Energy Star 6.0 standard
Features EyeCare Technology (Low-blue Light / Flicker-free)
