SpeedyTel PBX-220 Wireless Router - 802.11n/b/g, 1-Port WAN 10/100, 4-Port LAN 10/100 Switch, QoS, DDNS, VPN

No Longer Available

Part Number:

372953

(?) Brand:

SpeedyTel Web Site

Manuf No:

PBX-220
PBX220

Shipping Weight:

2 KG (Includes product packaging)
Estimate Shipping

Date Added:

2/9/2014

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

PBX220, PBX-220

WIFI Mini IP-PBX PBX220

For SMB and SOHO business

Wi-Fi router
Full IPPBX features
QoS, VPN,DDNS
16 extensions
HD video/audio
One touch to deploy
Skype Connect support

The PBX220 is the ideal system for small businesses and home offices requiring a pint-sized yetpowerful on premise Wi-Fi router IP PBX.

The compact solid-state device support 16 extensions and offers a wide range of IP PBX telephony features.

Keeping up with the demands of sustainability, the Mini-PBX is based on a low-power, high performance MIPS processor, providing the complicated communication features including the hardest HD communication protocol, complete router features and QoS (Ensure the voice quality in a case the bandwidth is not enough).Meanwhile, the feature of one touch to configure the phones makes the setting of phone easy and enjoyable thing.

Specifications

Wireless	Channels: Support 1-11 channels and auto mode TxPower: 802.11n 300M 14dBm, 802.11g 54M 16dBm, 802.11b 11M 17-19dBm Antenna: Internal 2T2R 3dBi Coverage Area: Indoor 100 meters, Outdoor 300 meters Encryption:WEP-Auto,WPA-PSK,WPA-PSK2 Crypto: AES, TKIP HT Bandwidth: 20Mhz, 40Mhz
Networks	WAN: DHCP, STATIC, PPPoE LAN: Static IP Time Zone: Multinational Dynamic DNS: Supported VPN: PPTP in Tunnel, PPTP in PBX only
Router Utilities	DHCP: Server / Client Port Forward: Supported Firewall: Support flood attack protect DMZ: Supported uPNP & NAT-PMP: Supported Qos: WMM, DSCP External Disk: USB 2.0 in Fat32 , Ext3, Ext4
Hardware	Processor: MIPS RAM: 64MB FLASH: 16MB WAN: 1xRJ45 10/100MB Ethernet port LAN: 4xRJ45 10/100MB Ethernet port Button: Reset Button, One Touch to auto Config Power adapter: AC 100~240V input and DC 12V/1A output Power Consumption: 1.2-2.0W Operating humidity: 10~95% Operating temperature: 0~45C
Management	System logs viewer: Supported Admin user: Support to modify the password Reboot: Supported Factory Reset: supported Configuration: Browser / Third Party Software Web Admin: HTML5AJAXCSS
PBX Features	Extensions: Up to 16 sets SIP extensions Extension Features: Support Ring Group, Follow Me, Extension Outbound Routes, Extension dialing intelligent analysis, Extension for BLF support, MWI(Message Waiting Indicator) Support SIP trunkRegistration modeIP docking mode(SIP Direct) Trunk featuresDID set, routes way, Inbound call system support routing, Support for multiple devices in the cluster, Support automatic looking for the callees number. Call Pickup Voicemail One Touch to Config Codec: G.722,G.711U/A,G.729,GSM, H.264, T.38, T.30 SIP Protocol: Over TCP/UDP, RFC3261 DTMFIn-BandRFC2833,SIP Info
Advanced PBX Features	Conference: Up to 8 parties conference system, support multiple independent meeting room Queues: Call queue strategy support randomresonancerotate members call IVR: Support voice menu, multi-level and key recognition Background Music: Supported IVR Voice file: play, record or upload Call record: Call record will automatically store in the external disk Time Frames: Support the IVR auto-switch based on the time SIP Behind NAT: Supported
Security	SIP Digest Authentication: using MD5 SSH Login with Username/Password

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 year return to base

Full manufacturers warranty details are available at the manufacturers (SpeedyTel) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
