** Note: Thermal solution is not included and may be ordered separately **


Intel® Xeon® Processor E5-1650 v3 (15M Cache, 3.50 GHz)

Specifications

Essentials
Status Launched
Launch Date Q3'14
Processor Number E5-1650V3
# of Cores 6
# of Threads 12
Clock Speed 3.5 GHz
Max Turbo Frequency 3.8 GHz
Intel Smart Cache 15 MB
Intel QPI Speed 0 GT/s
# of QPI Links 0
Instruction Set 64-bit
Instruction Set Extensions Intel AVX
Embedded Options Available

No
Lithography 22 nm
Scalability 1S Only
Max TDP 140 W
VID Voltage Range 0.651.30V


Memory Specifications

Max Memory Size (dependent on memory type) 768 GB
Memory Types DDR4-1333/1600/1866/2133
# of Memory Channels 4
Max Memory Bandwidth 68 GB/s
Physical Address Extensions 46-bit
ECC Memory Supported Yes

Expansion Options

PCI Express Revision 3.0
PCI Express Configurations   x4, x8, x16
Max # of PCI Express Lanes 40

Package Specifications

Max CPU Configuration 1
TCASE 66.7C
Package Size 52.5mm x 45.0 mm
Sockets Supported FCLGA2011-3
Low Halogen Options Available See MDDS

Advanced Technologies

Intel Turbo Boost Technology   2.0
Intel vPro Technology

Yes
Intel Hyper-Threading Technology

Yes
Intel Virtualization Technology (VT-x)   Yes
Intel Virtualization Technology for Directed I/O (VT-d)

Yes
Intel VT-x with Extended Page Tables (EPT)

Yes
Intel TSX-NI No
Intel 64

Yes
Idle States Yes
Enhanced Intel SpeedStep Technology

Yes
Intel Demand Based Switching

Yes
Thermal Monitoring Technologies Yes
Intel Flex Memory Access No
Intel Identity Protection Technology   Yes

Intel Data Protection Technology

AES New Instructions

Yes
Secure Key Yes

Intel Platform Protection Technology

OS Guard Yes
Trusted Execution Technology

Yes
Execute Disable Bit   Yes
