Intel Xeon E5-2660 v3 10-Core CPU (2.60GHz, 3.30GHz Turbo) - LGA2011-V3, 9.6 GT/s QPI, 25MB Cache, 22nm, 105W
  • Thermal Solution Is Not Included And May Be Ordered Separately

IMG 1 of 1
No Longer Available
Part Number:
373303
(?) Brand:
Intel Web Site
Manuf No:
BX80644E52660V3
Shipping Weight:
0.5 KG (Includes product packaging)
Estimate Shipping
Date Added:
10/9/2014
Details Files Finance Images & Video
All stock codes associated to this product
BX80644E52660V3, 2700491, 735858283533, 5032037064545

** Note: Thermal Solution Is Not Included And May Be Ordered Separately **

Intel Xeon Processor E5-2660 v3
(25M Cache, 2.60 GHz)


Specifications

Essentials
Status Launched
Launch Date Q3'14
Processor Number E5-2660V3
# of Cores 10
# of Threads 20
Clock Speed 2.6 GHz
Max Turbo Frequency 3.3 GHz
Intel Smart Cache 25 MB
Intel QPI Speed 9.6 GT/s
# of QPI Links 2
Instruction Set 64-bit
Instruction Set Extensions Intel AVX
Embedded Options Available

 No
Lithography 22 nm
Scalability 2S
Max TDP 105 W
VID Voltage Range 0.65V1.30V


Memory Specifications

Max Memory Size (dependent on memory type) 768 GB
Memory Types DDR4-1600/1866/2133
# of Memory Channels 4
Max Memory Bandwidth 68 GB/s
Physical Address Extensions 46-bit
ECC Memory Supported Yes

Expansion Options

PCI Express Revision 3.0
PCI Express Configurations   x4, x8, x16
Max # of PCI Express Lanes 40

Package Specifications

Max CPU Configuration 2
TCASE 79C
Package Size 52.5mm x 45mm
Sockets Supported FCLGA2011-3
Low Halogen Options Available See MDDS

Advanced Technologies

Intel Turbo Boost Technology   2.0
Intel vPro Technology

 Yes
Intel Hyper-Threading Technology

 Yes
Intel Virtualization Technology (VT-x)   Yes
Intel Virtualization Technology for Directed I/O (VT-d)

 Yes
Intel VT-x with Extended Page Tables (EPT)

 Yes
Intel TSX-NI No
Intel 64

 Yes
Idle States Yes
Enhanced Intel SpeedStep Technology

 Yes
Intel Demand Based Switching

 Yes
Thermal Monitoring Technologies Yes
Intel Flex Memory Access No
Intel Identity Protection Technology   No

Intel Data Protection Technology
AES New Instructions

 Yes
Secure Key Yes

Intel Platform Protection Technology

OS Guard Yes
Trusted Execution Technology

 Yes
Execute Disable Bit   Yes

No additional files, specification sheets, guides or documentation found for product.

Warranty: 3-year Manufact.

Full manufacturers warranty details are available at the manufacturers (Intel) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
