All stock codes associated to this product
AP128GAS510SB1, AP128GAS510SB-1, AP35445
Apacer AS510S
The Speedy and Reliable Companion for PC and Notebooks
Apacer AS510S solid state drive (SSD) is a speedy and reliable companion for consumer PC and laptops. Designed in SATA 6 Gb/s interface, the drive can deliver out standing performance up to 530 MB/s data transfer speed, highly suitable to serve as operating system boot drive or storage media of important data. With its compliance with the latest SATA specification, this cutting edge device supports power management features such as DEVSLP, Partial, Slumber, Auto-slumber and Power Throttling modes, which greatly saves in power consumption, making it more environmental and economical than traditional hard disk drives.
Regarding data reliability, the controller unit of AS510S supports 256-bit AES encryption and decrypti on to protect your stored data from theft. In addition, enhanced data integrity is enabled by a powerful ECC engine in the device correcting up to 72bit per 1KB data. For better I/O performance, the controller unit comes with an external DDR3 cache to strengthen the IOPS (Input Output Per Second) of the device, proving to be the ideal companion for PC and laptop users.
Applications
- PC/NB for general storage
- Operating system boot drive for PC/NB
- Network servers
- Industrial PCsGraphic and video applications
- Kiosk, POS and automation.
- Multimedia
- Gaming
Features
- Compatible with SATA 6 Gb/s interface
- Outstanding read/write performance
- Supports SATA Power Management
- Powerful ECC engine correcting up to 72bit/1KB
- DDR3 cache buffer for strengthened I/O efficiency
- Supports S.M.A.R.T. commands
- 256-bit AES encryption and decryption
- TRIM command support
Specifications
Interface: SATA 6 Gb/s interface
SATA III Burst Speed: 600 MB/s
Capacity: 64, 128 and 256 GB
Performance
64 GB Read: up to 440 MB/s; Write: up to 205 MB/s
128 GB Read: up to 525 MB/s; Write: up to 380 MB/s
256 GB Read: up to 530 MB/s; Write: up to 410 MB/s
Form Factor: 2.5 inch
NAND Flash Media: MLC
ECC: up to 72bit/1KB
Encryption: AES 256-bit
MTBF: 1,000,000 hours (approx.)
Operating Voltage: 5V±5%
Power consumption *** (Unit: mA):
Capacity: 64GB, 128GB, 256GB
Operating: 850, 870, 900
Idle: 85, 85, 85
Partial: 20, 20,20
Slumber: 15, 15, 15
Dimensions: 100.10mm(L) x 69.85mm(W) x 7.00mm(H)
Endurance
64GB: 170TBW
128GB: 340TBW
256GB: 670TBW
Reliability Features: S.M.A.R.T, TRIM, Wear-leveling
Temperature
Operating: 0 Degree C to 70 Degree C
Storage - 40 ~ +85 Degree C
Shock: 500G/2ms
Vibration: 80 – 2000Hz/20G
Acoustic: 0dB
Warranty: 3 years
Package Content: Retail package
Certifications: RoHS, CE, FCC
