All stock codes associated to this product
VTX460A25SAT3240G, VTX460A-25SAT3-240G, MMOCSSD25VT240A
Vertex 460A - SATA 3 2.5" SSD
Overview
Specifications
- Up to 545 MB/s Sequential Read
- Up to 525 MB/s Sequential Write
- Up to 95,000 IOPS 4KB Random Read
- Up to 90,000 IOPS 4KB Random Write
- Available in 120GB, 240GB and 480GB
- 3-Year ShieldPlus Warranty
OCZ, the most awarded SSD brand of all time, introduces the Vertex 460A for those seeking a high-performance yet value-minded SSD. Combining OCZs own controller design and Toshibas latest generation of flash, Vertex 460A keeps your system ahead of the game and delivers a faster, more responsive PC experience.
Its storage for your multimedia, multitasking world
The OCZ Vertex 460A Series delivers the performance, productivity, and energy efficiency youre craving from your system. Say goodbye to lag and get a computing experience worthy of your time.
Performance that matters
Do you write a lot of data? Vertex 460A delivers leading write speeds that you wont get with any other solution. No fancy behind-the-scenes tricks, just pure storage performance.
Do more than just store
Imagine faster file transfers, snappier boot ups, and system responsiveness that makes you wonder why you put up with that hard drive for so long.
Reliability and durability from the inside out
With quality Toshiba technology built into every drive, the Vertex 460A Series is built to provide years of hard drive-humiliating performance. Ditch that spinning mechanical hard drive for some storage peace of mind.
Features
Next Generation A19nm MLC NAND flash
Cutting-edge A19nm process geometry NAND for exceptional performance on consumer workstations, desktops, and laptops
Enhanced Endurance
Putting emphasis on client workload endurance, rated at 20GB/day of host writes for 3 years
Lasting Performance
Advanced suite of NAND flash management to analyze and dynamically adapt as flash cells wear
Added Value
Bundled with 3.5 desktop adapter and Acronis True Image cloning software to easily transfer data from your old hard drive
Superior Mixed Workload Performance
Excels in both incompressible and compressible data types such as multimedia, encrypted data, .ZIP files and software
Proprietary
Proprietary Barefoot 3 controller technology delivers superior sustained speeds over the long term
Ultra Slim
Sleek alloy housing offers slim 7mm z-height for compatibility with the ultra-thin notebooks
Secure
Superior reliability with in-house technology and high quality components based on the latest technology
OCZ's ShieldPlus Warranty
An industry-leading approach to service that eliminates all the hassle surrounding support and warranty claims consumers may have to deal with. NO shipping costs and NO hassle. (Currently available only for USA, European Union and Taiwan)
Specifications
| PERFORMANCE |
120GB |
240GB |
480GB |
| Sequential Read Speed1 |
530 MB/s |
540 MB/s |
545 MB/s |
| Sequential Write Speed1 |
420 MB/s |
525 MB/s |
525 MB/s |
Random Read Speed
(4KB, QD32)2 |
80,000 IOPS |
85,000 IOPS |
95,000 IOPS |
Random Write Speed
(4KB, QD32)2 |
90,000 IOPS |
90,000 IOPS |
90,000 IOPS |
| Steady-State Random Write Speed (4KB, QD32)3 |
12,000 IOPS |
21,000 IOPS |
23,000 IOPS |
1. Maximum sequential speeds are determined using ATTO
2. Small file I/O performance is measured using IOmeter 2010
3. Measured with Iometer 2010, 12 hour precondition to SNIA guidelines
| PHYSICAL |
| Usable Capacities (IDEMA) |
120GB, 240GB, 480GB |
| NAND Components |
A19nm Toshiba Multi-Level Cell (MLC) Flash |
| NAND Controller |
OCZ Barefoot 3 M10 |
| Interface |
SATA 3 6Gb/s (Backwards compatible with SATA II 3Gb/s) |
| Form Factor |
2.5-inch, 7mm height (fits utlra-thin notebooks) |
| Dimension (L x W x H) |
99.7 x 69.75 x 7mm |
| Weight |
113g |
| RELIABILITY / PROTECTION |
| Data Path Protection |
BCH ECC corrects up to 44 random bits/1KB |
| Endurance |
Rated for 20GB/day of host writes for 3 years under typical client workloads |
| Product Health Monitoring |
Self-Monitoring, Analysis and Reporting Technology (SMART) Support |
| Encryption |
AES-256 |
| MTBF |
2 million hours |
| ENVIRONMENTAL |
| Power Consumption |
Idle: 0.6W, Active: 3.45W |
| Operating Temperature |
0C ~ 70C |
| Storage Temperature |
-45C ~ 85C |
| Shock Resistance |
1000G/0.5ms |
| Vibration (Operational) |
2.17 Grms (7-800Hz) |
| Vibration (Non-operational) |
3.13 Grms (7-800Hz) |
| Altitude (Operational) |
-1,000 ft. to 10,000 ft. |
| Altitude (Non-operational) |
-1,000 ft. to 40,000 ft. |
| Certifications |
UL C/US, FCC, CE, C-Tick, KCC, BSMI, VCCI, WEEE |
| COMPATIBILITY |
| Serial ATA (SATA) |
Fully compliant with SATA International Organization: Serial ATA Revision 3.0. Fully compliant with ATA/ATAPI-8 Standard Native Command Queuing (NCQ) |
| Power Requirements |
Standard SATA Power Connector |
| Operating System |
Windows / Mac / Linux |
| Targeted Applications |
Client workstations and laptops |
| ADDITIONAL FEATURES |
| Performance Optimization |
TRIM (requires OS support), Idle Time Garbage Collection |
| Included Software |
Bundled with Acronis True Image HD* cloning software registration key |
| Included Accessories |
A 3.5-inch SSD desktop adapter bracket |
| Service & Support |
3-Year ShieldPlus Warranty, Toll-Free Tech Support, 24 Hour Forum Support, Firmware Updates |
*Current version of Acronis True Image HD supports Windows XP, Windows Vista, Windows 7, and Windows 8
| ORDERING INFORMATION |
PART NUMBER |
UPC |
| 120G |
VTX460A-25SAT3-120G |
842024036982 |
| 240G |
VTX460A-25SAT3-240G |
842024036999 |
| 480G |
VTX460A-25SAT3-480G |
842024037002 |
