| General |
| Device Type |
NAS server |
| Host Connectivity |
Gigabit Ethernet |
| Total Storage Capacity |
0 GB |
| Installed Devices / Modules Qty |
0 (installed) / 4 (max) |
| Width |
18 cm |
| Depth |
23.5 cm |
| Height |
17.7 cm |
| Weight |
3 kg |
| Built-in Devices |
Led panel |
| Processor / Memory |
| Processors Installed |
1 x Intel Celeron 2 GHz |
| Number of Cores |
Quad-Core |
| Max Supported Qty |
1 |
| RAM Installed |
2 GB (installed) / 8 GB (supported) - DDR3L |
| Flash Memory Installed |
512 MB |
| Storage Controller |
| Type |
RAID |
| Interface Type |
SATA 6Gb/s |
| RAID Level |
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID 5 hot spare |
| Networking |
| Data Link Protocol |
10Mb LAN, 100Mb LAN, GigE |
| Network / Transport Protocol |
TCP/IP, PPTP, L2TP, IPSec, iSCSI, SMTP, FTP, DHCP, Bonjour, SMB, DDNS |
| Remote Management Protocol |
SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, TFTP, SSH |
| Network Services Compatibility |
Microsoft
Active Directory (AD), Apple Bonjour Protocol, DHCP, DDNS, Microsoft
CIFS, Network File System (NFS), FTP, FTPS, Server Message Block (SMB),
Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring
and Versioning (WebDAV), SFTP |
| Features |
Trunking,
LDAP support, wake on LAN (WOL), Syslog support, manageable, E-mail
alert, print server, IPv6 support, video server, firmware upgradable,
proxy server, backup server, download client, file sharing, event log,
Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL)
support, SSH support, iTunes server, Jumbo Frames support, DHCP server,
FTP server, SMS alert, BitTorrent Client, UPnP Media Server, bandwidth
control, IPv4 support, surveillance station, teaming support, DLNA Media
Server, Apple Time Machine compatible, DHCP client, e-mail
notification, cloud backup, VPN Server, SFTP client, SNMP support, Apple
AirPlay |
| Encryption Algorithm |
FIPS 140-2, 256-bit AES |
| Compliant Standards |
DLNA CERTIFIED, UPnP |
| Security DVR |
| IP Cameras Supported |
40 |
| Expansion / Connectivity |
| Expansion Bays |
4 (total) / 4 (free) x hot-swap - 2.5" / 3.5" |
| Expansion Slots |
2 (total) / 1 (free) x SO-DIMM 204-pin |
| Interfaces |
2 x Ethernet 1000Base-T - RJ-45 2 x USB 3.0 - Type A 2 x USB 2.0 - Type A 1 x HDMI output |
| Miscellaneous |
| Cables Included |
2 x network cable |
| Features |
Security lock slot (cable lock sold separately), audible alarm, remote control, built-in cooling fan |
| Power |
| Power Device |
X external power adapter |
| Voltage Required |
AC 120/230 V |
| Power Consumption Operational |
33.88 Watt |
| Power Provided |
90 Watt |
| Software / System Requirements |
| Storage Operating System |
QNAP QTS 4.2 |
| OS Required |
UNIX,
Linux, Microsoft Windows Server 2003, Apple MacOS X or later, Microsoft
Windows Server 2008 R2, Microsoft Windows 7 (32/64 bits), Microsoft
Windows Server 2012, Windows 8 (32/64 bits), Microsoft Windows Server
2012 R2 |
| Environmental Parameters |
| Min Operating Temperature |
0 C |
| Max Operating Temperature |
40 C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
