GENERAL
|
| General type |
Colour Multifunctional for A4/A3 Format |
| Technology |
KYOCERA ECOSYS, COLOUR Laser HyPAS solution platform |
| Engine speed |
Up to 25/13 pages A4/A3 per minute in colour and b/w |
| Resolution |
600 x 600 dpi, multi-bit technology for print quality of 9,600 dpi equivalent x 600 dpi |
| Warm-up time |
Approx. 45 seconds or less from power on |
| Time to first print |
Approx. 10 seconds or less in b/w, 12 seconds or less in colour |
| Time to first copy |
Approx. 11.7 seconds or less in b/w, 13.6 seconds or less in colour |
| Dimensions (W x D x H) |
590 x 590 x 748 mm (with Document processor) |
| Weight |
Approx. 80 kg including toner container |
| Power consumption |
Sleep-mode: 0.9W, Stand-by: 125 W, Copying/Printing: 597 W |
| Power source |
AC 220 ~ 240 V, 50/60 Hz |
| Noise (ISO 7779) |
Noise (sound pressure level: ISO 7779/ISO 9296) Stand-by: 35 dB(A), Copying/Printing: 49 dB(A) in b/w |
| Safety standards |
TV/GS, CE - This product is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard. |
| General memory |
1,536 MB, max. 2,048 MB |
|
 |
PAPER HANDLING
|
| Input capacity |
100-sheet multi-purpose tray, 60256 g/m, A3, A4, A5, A6, B5, Letter, Legal, Folio, envelopes, Custom (98 x 148 to 297 x 432 mm) 500-sheet universal paper cassette, 60256 g/m, A3, A4, A5, B5, Letter, Legal, Folio |
| Max. input capacity with options |
1,600 sheets |
| Duplex unit |
Duplex as standard supports 60220 g/m |
| Max. output capacity |
Max. 280 sheets; 250 sheets face-down (main tray), plus 30 sheets (job separator tray) |
| Document processor |
Reversing document processor: 50-sheet, Simplex scan 45160 g/m, Duplex scan 50120 g/m, A3, A4, A5, B5, Letter, Legal, Custom (140x182 to 297x432mm) |
| General paper handling |
All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by KYOCERA under normal environmental conditions. |
|
|
PRINT
|
| Processor |
PowerPC464 - 800 MHz |
| Controller language |
PRESCRIBE |
| Emulations |
PCL 6 (5c/XL), KPDL3 (Postscript 3 compatible), PDF Direct print, XPS Direct print |
| Fonts |
93 outline fonts (PCL 6, KPDL3) + 8 (Windows Vista), 1 bitmap font, 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417) |
| Integrated Accounting |
100 department codes |
| Features |
Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, Private Print |
| Applicable OS |
All current Windows operating systems, MAC OS X Version 10.4 or higher, Unix, Linux as well as other operating systems on request. |
|
|
COPY
|
| Max. original size |
A3/Ledger |
| Digital copy features |
Scan-once-copy-many, electronic sort, 2in1, 4in1, job reserve, priority print, program, auto duplex copy, split copy, continuous scan, auto cassette change (PF-470 or PF-471 is required), copy density control, Prevent Bleed-Through |
| Exposure modes |
Auto, manual: 7 steps |
| Preset magnification ratios |
5 Reductions / 5 Enlargements |
| Zoom range |
25 - 400 % in 1% steps |
| Continuous copy |
1 - 999 |
| Image adjustments |
Text, photo, text + photo, graphic/map, printer output |
|
|
SCAN
|
| File type |
TIFF, PDF, PDF/A, JPEG, XPS |
| Scan features |
Integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder) at once |
| Original recognition |
Text, Photo, Text + Photo, optimised for OCR |
| Max. scan size |
A3 |
| Scan functionalities |
Scan-to-Email, Scan-to-FTP, Scan-to-SMB, Scan-to-USB Host, Network TWAIN, WIA, WSD scan |
| Scan resolution |
600, 400, 300, 200, 400 x 200, 200 x 100 dpi (256 greyscales per colour) |
| Scan speed |
40ipm (300dpi, A4, b/w, colour) |
|
|
FAX
|
| Compatibility |
ITU-T Super G3 |
| Modem speed |
Max. 33.6 kbps |
| Scanning speed |
2.0 seconds (Quick Scanning, Bitmap) |
| Transmission speed |
3 seconds or less |
| Scanning density |
Normal: 8 dot/mm x 3.85 line/mm, Fine: 8 dot/mm x 7.7 line/mm, Superfine: 8 dot/mm x 15.4 line/mm, Ultrafine: 16 dot/mm x 15.4 line/mm, Halftone: 256 gray scales |
| Max. original size |
A3/Ledger |
| Compression method |
JBIG, MMR, MR, MH |
| Fax features |
Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast |
|
|
INTERFACES
|
| Standard interface |
USB 2.0 (Hi-Speed), USB Host 2.0, Fast Ethernet 10/100/1000Base-TX, slot for optional print server, slot for optional CompactFlash-Card |
|
|
WARRANTY
|
| Warranty |
1-year warranty as standard (depending on the country). KYOCERA guarantees the drum and developer for 3 years or 200,000 pages (whichever occurs sooner), provided each device is used and cleaned in accordance with the service instructions. |
|
