HP 698533-B21 Smart Array P830/4G Controller

Payal - Techbuy Home Computers Custom PC Systems Tablets Networking Printers Phones Point of Sale Gaming

Merry Christmas from the team at Techbuy Christmas Trading Hours

HOME / Back -> Hard Drive Controllers -> SAS Controllers -> HP

HP 698533-B21 Smart Array P830/4G Controller

No Longer Available

Part Number:

319332

(?) Brand:

HP Web Site

Manuf No:

698533-B21
698533B21

Shipping Weight:

0.5 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Finance Images & Video

All stock codes associated to this product

698533B21, 698533-B21, 887111206985

HP Smart Array P830/4GB FBWC 12Gb 2-ports Int SAS Controller

698533-B21

Overview

HP Smart Array P830/4GB FBWC 6Gb 2-ports Int SAS Controller - 6Gb/s SAS - PCI Express 3.0 x8 - Plug-in Card - RAID Supported - 6, 60, 5, 50, 1, 10, 1 ADM, 0 RAID Level - 2 SAS Port(s)

Description

HP Smart Array P830/4GB FBWC 12Gb 2-ports Int PCIe x8 SAS Controller

The HP Smart Array P830 allows you to connect a total of 16 drives spanning two separate drive cages. P830 provides an SSD optimized controller solution that allows customers to attach 16 SSDs for maximum performance. The HP Smart Array P830i delivers an end to end 12 Gb/s SAS solution on the HP ProLiant DL580 Gen8 server. HP SSD Smart Path provides up to 4x better SSD read performance for Microsoft Windows, Linux and VMware.

Data Protection. Standard on P830 are RAID 6 ADG, RAID 60 , RAID 5 DDG, RAID 50, RAID 1&10, RAID 1 ADM & 10 ADM. Long term data retention with 4GB FBWC kit w/battery.

Specifications

Controller Type	6Gb/s SAS
RAID Supported	Yes
Host Interface	PCI Express 3.0 x8
RAID Levels	6 60 5 50 1 10 1 ADM 0
Data Backup Type	Flash Backed Cache
Total Number of SAS Ports	2
Height	4.4"
Width	6.6"
Form Factor	Plug-in Card
Thickness	0.7"
Green Compliant	Yes
Green Compliance Certificate/Authority	WEEE
Limited Warranty	3 Year

Extended specifications

Technical Information

Host Interface	PCI Express 3.0 x8
Controller Type	6Gb/s SAS
RAID Levels	6 60 5 50 1 10 1 ADM 0
RAID Supported	Yes
Number of Physical Drive Supported	16
Number of Logical Drive Supported	64
Platform Supported	PC Linux
Data Backup Type	Flash Backed Cache

Interfaces/Ports

Total Number of SAS Ports	2
Number of SAS Ports (Internal)	2

Physical Characteristics

Form Factor	Plug-in Card
Height	4.4"
Width	6.6"
Thickness	0.7"
Card Length	Full-length

Miscellaneous

Platform Supported	PC Linux
Green Compliant	Yes
Green Compliance Certificate/Authority	WEEE

Warranty

Limited Warranty

3 Year

No additional files, specification sheets, guides or documentation found for product.

Warranty: 1 Year Return to Base

Full manufacturers warranty details are available at the manufacturers (HP) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.

Visitor Reviews

[ There are no visitor reviews for this product yet]

Review Product

Click on a thumbnail to view it below

No related products found.
