All stock codes associated to this product
ATC700, CPCGATC700, CPCG-ATC700, 4719331550127
Overview
Features
- RGB fusion - 16.8M Customizable Color Lighting
- Dual 120mm 2 ball bearing (PWM) fans
- 3*10mm high performance copper heat-pipes
- Heat-Pipe direct touch technology
AORUS COOLING SYSTEM
DUAL 120MM 2 BALL BEARING PWM FANS
Attached 2 big 120mm PWM fans to each side of the heat-sink, will efficiently
dissipate the heat from the CPU at a very low noise level. PWM function provides
the accurate and efficient fan speed for the CPU, to optimize the noise
reduction and the thermal performance. GIGABYTE patented blade fan design
increases the airflow by 23%. And moreover, the 2 ball bearing structure will
provide longer and more stable lifespan.
120MM UNIQUE BLADE FAN DESIGN
The 120mm dynamic adjusting
fan provides the silent operation. The airflow is spilt by the triangle fan
edge, and guided smoothly through the 3D stripe curve on the fan surface,
effectively enhancing the airflow by 23% over the traditional fans.
DOUBLE BALL BEARING STRUCTURE
The double ball bearing structure has better heat endurance and efficiency
than sleeve structure. Hence it will provide longer life time.
HEAT-PIPE DIRECT TOUCH TECHNOLOGY
The 3x 100mm pure copper heat pipes are shaped to maximize the direct contact
area to the CPU for enhanced thermal transfer.
AORUS OUTLOOK
RGB FUSION
With 16.7M customizable color options and numerous lighting effects, you
could now choose the right scheme for your gaming rig through AORUS Graphics
Engine.
CYCLING - Smoothly cycles through all colors
CONSISTENT - Choose a color for static light
FLASH - Choose a color for flash effect
DUAL FLASH - Choose a color for double flash effect
BREATHING - Choose a color to fade in and out
DIMENSIONS
Specifications
|
Rated Voltage |
Fan :12V DC , LED : 12V |
|
Rated Current |
0.21A |
|
Fan Speed |
500-1700 RPM10% |
|
Bearing Type |
2 Ball Bearing |
|
Weight |
955 g |
|
CPU Socket |
Intel Socket 2066 / 2011 / 1366 / 1156 / 1155 / 1151 / 1150 /
775 |
|
AMD Socket FM2+, FM2, FM1, AM4, AM3+, AM3, AM2+, AM2, 939,
754 |
|
TDP |
>200W |
|
Dimensions (LxWxH) |
139 x 109 x 169 mm |
|
Heat Sink Dimensions (LxWxH) |
133 x 59 x 158 mm |
|
Heat Sink Material |
3 x 10mm Heat Pipes / Aluminum Fins |
|
Heat Sink Weight |
670 g |
|
Heat Pipe Dimensions |
10 mm |
|
Fan Dimensions |
120*25mm*2PCS |
|
Fan Air Flow |
14-53 CFM 10% |
|
Fan Air Pressure |
0.2-1.93 mmH2O 10% |
|
Fan Life Expectancy |
70000 Hrs |
|
Noise Level |
12 ~ 31 dBA |
|
Connector |
4 Pin |
|
Power Consumption |
2.52W |
|
Fan Weight |
142
g |
