All stock codes associated to this product
BX80684E2224G, 4512200, CPIXE2224G, CPI-XE-2224G, 735858418133, 5032037161015
Intel BX80684E2224G Xeon E-2224G Processor 8M Cache, 3.50
GHz
Benefits
- Faster time to value with Intel Select Solutions
- Strong, capable platforms for the data-fueled enterprise
- Next-generation platform for cloud-optimized, 5G-ready networks, and
next-generation virtual networks
- Breakthrough HPC and high-performance data analytics innovation
Empowering Transformation in a Data-Centric Era
Across an evolving digital world, disruptive and emerging technology trends
in business, industry, science, and entertainment increasingly impact the
world's economies. By 2020, the success of half of the world's Global 2000
companies will depend on their abilities to create digitally enhanced products,
services, and experiences,1and
large organizations expect to see an 80 percent increase in their digital
revenues,2all
driven by advancements in technology and usage models they enable.
This global transformation is rapidly scaling the demands for
flexible compute, networking, and storage. Future workloads will necessitate
infrastructures that can seamlessly scale to support immediate responsiveness
and widely diverse performance requirements. The exponential growth of data
generation and consumption, the rapid expansion of cloud-scale computing,
emerging 5G networks, and the extension ofhigh performance computing (HPC) and
artificial intelligence (AI) into new usages require that today's data centers
and networks urgently evolveor be left behind in a highly competitive
environment. These demands are driving the architecture of modernized,
future-ready data centers and networks that can quickly flex and scale.
TheIntel Xeon Scalable processor familyprovides
the foundation for a powerful data center platform that creates an evolutionary
leap in agility and scalability. Disruptive by design, this innovative processor
sets a new level of platform convergence and capabilities across compute,
storage, memory, network, and security. Enterprises and cloud and communications
service providers can now drive forward their most ambitious digital initiatives
with a feature-rich, highly versatile platform.
Enabling Greater Efficiencies and Lower TCO
Across infrastructures, from enterprise to technical computing
applications, theIntel Xeon Scalable processor familyis
designed for data center modernization to drive operational efficiencies that
lead to improved total cost of ownership (TCO) and higher productivity for
users. Systems built on theIntel Xeon Scalable processor familyare
designed to deliver agile services with enhanced performance and groundbreaking
capabilities, compared to the prior generation.
Performance to Propel Insights
Intel's industry-leading, workload-optimized platform with built-in AI
acceleration, provides the seamless performance foundation for the data-centric
era from the multicloud to intelligent edge, and back, theIntel Xeon Scalable
processor familywith
2nd Gen Intel Xeon Scalable processors enables a new level of consistent,
pervasive, and breakthrough performance.
Specifications
Essentials |
|
Product Collection |
Intel Xeon E Processor |
Code Name |
Products formerly Coffee
Lake |
Vertical Segment |
Server |
Processor Number |
E-2224G |
Status |
Launched |
Launch Date |
Q2'19 |
Lithography |
14 nm |
Performance |
|
# of Cores |
4 |
# of Threads |
4 |
Processor Base Frequency |
3.50 GHz |
Max Turbo Frequency |
4.70 GHz |
Cache |
8 MB |
TDP |
71 W |
Supplemental
Information |
|
Embedded Options Available |
No |
Description |
Support for up to 128GB system
memory may require a BIOS update. Please contact your hardware provider
regarding availability for your system. |
Memory
Specifications |
|
Max Memory Size (dependent on
memory type) |
128 GB |
Memory Types |
DDR4-2666 |
Max # of Memory Channels |
2 |
ECC Memory Supported |
Yes |
Processor
Graphics |
|
Processor Graphics |
Intel UHD Graphics P630 |
Graphics Base Frequency |
350 MHz |
Graphics Max Dynamic
Frequency |
1.20 GHz |
Graphics Video Max Memory |
128 GB |
4K Support |
Yes, at 60Hz |
Max Resolution (HDMI 1.4) |
4096x2160@24Hz |
Max Resolution (DP) |
4096x2304@60Hz |
Max Resolution (eDP -
Integrated Flat Panel) |
4096x2304@60Hz |
Max Resolution (VGA) |
N/A |
DirectX* Support |
12 |
OpenGL* Support |
4.5 |
Intel Quick Sync Video |
Yes |
Intel InTru 3D Technology |
Yes |
Intel Clear Video HD
Technology |
Yes |
Intel Clear Video
Technology |
Yes |
# of Displays Supported |
3 |
Device ID |
0x3E96 |
Expansion
Options |
|
Scalability |
1S Only |
PCI Express Revision |
3 |
PCI Express Configurations |
1x16,2x8,1x8+2x4 |
Max # of PCI Express Lanes |
16 |
Package
Specifications |
|
Sockets Supported |
FCLGA1151 |
Max CPU Configuration |
1 |
TCASE |
69.3C |
TJUNCTION |
100 |
Package Size |
37.5 mm x 37.5 mm |
Advanced
Technologies |
|
Intel Optane Memory Supported |
Yes |
Intel Turbo Boost Technology |
2 |
Intel vPro Platform
Eligibility |
Yes |
Intel Hyper-Threading
Technology |
No |
Intel Virtualization Technology
(VT-x) |
Yes |
Intel Virtualization Technology
for Directed I/O (VT-d) |
Yes |
Intel VT-x with Extended Page
Tables (EPT) |
Yes |
Intel TSX-NI |
Yes |
Intel 64 |
Yes |
Instruction Set |
64-bit |
Instruction Set Extensions |
Intel SSE4.1, Intel SSE4.2,
Intel AVX2 |
Idle States |
Yes |
Enhanced Intel SpeedStep
Technology |
Yes |
Thermal Monitoring
Technologies |
Yes |
Security &
Reliability |
|
Intel AES New Instructions |
Yes |
Secure Key |
Yes |
Intel Software Guard Extensions
(Intel SGX) |
Yes with Intel ME |
Intel Memory Protection
Extensions (Intel MPX) |
Yes |
Intel OS Guard |
Yes |
Intel Trusted Execution
Technology |
Yes |
Execute Disable Bit |
Yes |
Intel Boot Guard |
Yes |
