All stock codes associated to this product
CMPSU850AXAU, CMPSU-850AXAU
Professional Series
AX860
Gold
Unprecedented Power Protection
The Corsair Professional Series Gold power supply pushes the state of the art for reliable delivery of clean power under imperfect conditions. If you require mission-critical stability or you simply want one of the best power supplies available, the Professional Series Gold is for you.
A Fully Modular Cabling System
All cables detach from the power supply. During installation, this gives you the flexibility of using only the cables you need for a clean system build with optimal airflow. And, when it's time to replace or upgrade your power supply, it can be removed from your system without interfering with your cabling the cables stay in place and connect to your new fully-modular Corsair power supply.
Incredible Efficiency
With 90% efficiency at 50% load, the Corsair Professional Series Gold power supply runs quieter, generates minimal excess heat, and saves you money every month. It's earned the 80 Plus Gold seal of approval, your guarantee that you're making the right choice for smart,efficient power delivery.
Corsair Professional Series Gold AX850 features:
- Supports the latest ATX12V v2.31 and EPS 2.92 standards and is backward compatible with ATX12V 2.2 and ATX12V 2.01 systems
- An ultra-quiet 120mm double ball-bearing fan delivers excellent airflow at an exceptionally low noise level by varying fan speed in response to temperature
- 80 Plus Gold certified to deliver at least 90% efficiency at 50% load
- Active Power Factor Correction (PFC) with PF value of 0.99
- Universal AC input from 90~264V
- No more hassle of flipping that tiny red switch to select the voltage input!
- A dedicated single +12V rail offers maximum compatibility with the latest components
- Over-voltage and over-current protection, under-voltage protection, and short circuit protection provide maximum safety to your critical system components
- High-quality Japanese capacitors provide uncompromised performance and reliability
- Completely modular cable system allows you to use only the cables you need
- Power supply upgrade and replacement is easy, as the cables only need to be disconnected at the power supply
- Low-profile, flat cable design reduces air friction and helps maximize airflow through your computer's chassis
- A seven year warranty and lifetime access to Corsair's legendary technical support and customer service
- Dimensions: 150mm(W) x 86mm(H) x 160mm(L)
- MTBF: 100,000 hours
- Safety Approvals: UL, CUL, CE, CB, FCC Class B, TV, CCC, C-tick
Ultra Low Noise - Hybrid Silent Fan Control
The Corsair AX850's energy-efficient design allows it to operate reliably with minimal cooling, and hence very low noise levels. The AX850's Hybrid Silent Fan Control technology offers three modes of cooling, depending on the load level. This includes a fanless mode of operation (0 rpm) up to about 20% load, a quiet, low fan speed cooling mode for typical loads up to around 50% load, and a higher performance cooling mode for more demanding loads. Noise levels still remain low even when fan speeds start to climb, thanks to the use of a premium-quality 120mm San Ace fan from industry-leader, Sanyo Denki.
Power Supply Charts
Noise Level Chart (Click for larger version)
 |
|
Efficiency Chart (CLick for larger version)
 |
Power Supply Specifications
|
CMPSU-850AX
|
| AC Input |
90-264V ~ 15A 50/60Hz |
| DC Output |
+3.3V |
+5V |
+12V |
-12V |
+5Vsb |
| Max. Current |
25A |
25A |
70A |
0.5A |
3A |
| Max Combined Wattage |
125W |
840W |
6W |
15W |
|
850 @ 50C ambient temperature
|
Corsair AX850 Connectors:
