Overview



Details

Performance

  • NVIDIA GTX 1070
  • 1920 CUDA Cores
  • 1594 MHz Base Clock
  • 1784 MHz Boost Clock
  • 191.2GT/s Texture Fill Rate

Memory

  • 8192 MB, 256 bit GDDR5
  • 8008 MHz (effective)
  • 256.3 GB/s Memory Bandwidth

Cooling

  • ACX 3.0
  • LED Logo: Yes (White)

Interface

  • PCI-E 3.0 16x
  • DVI-D, DisplayPort, DisplayPort, DisplayPort, HDMI

Resolution & Refresh

  • Max Monitors Supported: 4
  • 240Hz Max Refresh Rate
  • Max Digital : 7680x4320

Dimensions

  • Height: 4.376in - 111.15mm
  • Length: 10.5in - 266.7mm
  • Width: Dual Slot

Operating System Support

  • Windows 10 32/64bit
  • Windows 8 32/64bit
  • Windows 7 32/64bit

Requirements

  • Minimum of a 500 Watt power supply.
  • An available 8-pin PCI-E power connector
  • Total Power Draw : 170 Watts

Product Warranty

This product comes with a 3 year warranty. Registration is recommended.

Features

Simultaneous Multi-Projection

Simulates seperate viewports of the same scene giving improved performance in VR and improved display accuracy in NVIDIA Surround.

NVIDIA Ansel

Revolutionary new 360-degree image capture.

NVIDIA G-SYNC

NVIDIA G-SYNC monitors feature revolutionary NVIDIA technology that eliminates screen tearing while also reducing input lag. The result is the smoothest, fastest, and most responsive gaming experience ever seen.

NVIDIA GPU Boost 3.0

Dynamically maximizes clock speeds based on workload and allows enthusiast-class controls such as temperature target and fan controls, extra over-voltage headroom, and optimizations for water-cooling solutions. This allows gamers to push performance to new levels.

Vulkan API

A next generation graphics and compute API from Khronos Group that provides high-efficiency, cross-platform access to modern GPUs.

PCI Express 3.0

This card is designed for the PCI Express 3.0 bus architecture, offering the highest data transfer speeds for the most bandwidth-hungry games and 3D applications. It also maintains backwards compatibility with existing PCI Express motherboards for the broadest support.

HDMI 2.0b, DisplayPort 1.4 and Dual-Link DVI

The latest standards in DisplayPort and HDMI interfaces.

EVGA ACX 3.0 Cooling

EVGA ACX 3.0 once again brings new and exciting features to the award winning EVGA ACX cooling technology. SHP 2.0 gives increased heatpipes and copper contact area for cooler operation, and optimized fan curve for even quieter gaming. Of course, ACX 3.0 coolers also feature optimized swept fan blades, double ball bearings and an extreme low power motor, delivering more air flow with less power, unlocking additional power for the GPU.

VR Ready

Discover next-generation VR performance, the lowest latency, and plug-and-play compatibility with leading headsets-driven by NVIDIA VRWorks technologies.

NVIDIA SLI w/ HB Bridge Support

NVIDIA's new SLI HB bridge doubles the available transfer bandwidth compared to the NVIDIA Maxwell architecture.

NVIDIA GameStream

Stream extreme GeForce GTX PC gaming experiences to portable device like NVIDIA SHIELD with super-smooth, low-latency performance.

Microsoft DirectX 12

Support for the latest Microsoft DirectX API to enable next-generation gaming.

OpenGL 4.5 Support

Supporting the latest standards in the OpenGL API.

Max Digital Resolution - 7680x4320

DisplayPort 1.4 Ready supporting up to 7680x4320 resolution at 60Hz

Built for EVGA Precision XOC

This new version of Precision is built for the NVIDIA Pascal architecture and combines the best of EVGA Precision and EVGA OC Scanner to give you never before seen overclocking features and built in automatic tuning.

Specifications

Base / Boost (Clock)

1594 / 1784

BIOS Chips

1

Cooler Type

ACX 3.0

Power Type

8-Pin

Power Phase

4+1

Max Power Draw

170W

Performance Level

Better

Backplate

No
