Cisco IE-2000-4T-B Industrial Ethernet 2000 Series
Switches
Overview
The CiscoIndustrial Ethernet 2000 (IE 2000) Series is a range
of compact, ruggedized access switches that handle security, voice, and video
traffic across industrial networks. They provide customers in industries such as
automotive, oil and gas, mining, transportation, and energy with highly secure
access and industry-leading convergence using Cisco Resilient Ethernet Protocol
(REP).
Product Details
The Cisco IE 2000 Series are designed for low cost, low ports, and
small sizes. They offer:
- Four, eight, or 16 10/100Base-T Ethernet ports (Small Form-Factor
Pluggable [SFP] downlinks on selected models); fixed configurations with a
compact form factor
- Two gigabit combo ports: SFP (100 Mbps and 1 Gbps) or RJ45
uplink
- Dual-input DC power supply, alarm relays, DIN rail mount
- Industrial Power over Ethernet (PoE) solution
- Conformal coating available
- Swappable SD flash card and mini-USB connector
- Industrial environmental compliance and
certifications
- Industrial partner applications: Ethernet/IP and
PROFINET
Primary Benefits and
Features
- Easy deployment:
- Zero-touch discovery using Dynamic Host Control
Protocol (DHCP), express setup, and fast bootup time (60 seconds) to help in
migrating to an Ethernet environment without
resistance.
- Security:
- 802.1x, port security, and DHCP allow dynamic
port-based authentication; Secure Shell (SSHv2); SNMPv3 provides encrypted
administrator traffic during Telnet and SNMP sessions; TACACS+ and RADIUS
authentication facilitate centralized control and restrict unauthorized
users.
- Resiliency:
- Cisco REP ring protocol and PROFINET– Media Redundancy
Protocol (MRP)
- Manageability:
- Auto SmartPort, Web Device Manager, Telnet, HTTPS
access, SNMP, CNA, and Cisco Prime
Infrastructure.
- Network Address Translation (NAT):
- Line-rate, hardware-enabled 1:1 static address
translation designed to enable duplicate IP address usage in the Layer 2
machine node networks.
- Layer 3 routing:
- Industrial PoE:
- PoE (IEEE 802.af) and PoE+ (802.3at) supported on
selected models.
- Industrial automation protocols:
- EtherNet/IP (CIP) and PROFINET MRP (IEC 62439-2) allow
integration with existing management platforms from Rockwell, Siemens, and
others.
Product
Specifications
Switch Performance and Scalability
- Maximum Forwarding Bandwidth 3.8Gbps
- Maximum Switching Bandwidth 7.6Gbps
- Maximum Forwarding rate: 5.66Mpps with 64-byte packets
(Line-rate at all packet sizes)
- Egress buffer: 2 MB
- Unicast MAC addresses: 8000
- Internet Group Management Protocol (IGMP) multicast
groups: 255
- Maximum virtual LANs (VLANs): 1005
- IPv4 MAC security ACEs: 384 (default ternary
content-addressable memory [TCAM] template)
- Bidirectional, 128 NAT translation entries
- IPv4 routing: 3500 routes, IPv6 routing: 1750
routes
Figure 1. Industrial Ethernet 2000
Series
Table 1. Industrial Ethernet 2000 Series
Configurations
|
Product
Number |
Total
Ports |
RJ45
Ports |
Combo
Ports |
SFP
Ports |
Manufacturing
License |
Type of possible
Upgrade |
IEEE
1588 |
L2NAT |
PoE(+) |
Conformal
Coating |
|
IE-2000-4T-B |
6 |
6 FE |
|
|
LAN Base |
1 |
|
|
|
|
Type of possible Upgrade Legend:
1: LAN Base to IP Lite Cisco IOS Software Upgrade
2: Enhanced LAN Base to IP Lite Cisco IOS Software Upgrade
3: LAN Lite to LAN Base Cisco IOS Software Upgrade
4: LAN Base to Enhanced LAN Base Cisco IOS Software Upgrade and License
Upgrade
U: Upgradable to L2NAT via Enhanced Lan Base or IP Lite license
Table 2. Product Specifications
|
Description |
Specification |
|
Hardware |
256 MB DRAM with ECC
memory |
|
IEEE 1588v2
FPGA |
|
64 MB on-board flash
memory |
|
1GB removable SD flash
memory card (optional) |
|
Mini-USB
connector |
|
Alarm |
Alarm I/O: Two alarm
inputs to detect dry contact open or close; one alarm output
relay |
|
Power
Consumption |
4-port downlink models:
9.5-15 W |
|
8-port downlink models:
12.5-20 W |
|
16-port downlink
models: 21-30 W |
|
4-port PoE/PoE+ models:
21-30 W (16-port base switch) and 4 PoE/PoE+ power
requirement |
|
Connectors and
Cabling |
100BASE-FX MMF (2 km),
-LX SMF (10 km) -ZX SMF (100 km), BX10 SMF (10 km) SFP and CWDM SFP- based
ports: LC fiber connectors |
|
10/100/1000BASE-T
ports: RJ-45 connectors, 4-pair Category 5 UTP
cabling |
Table 3. Cisco IE 2000 Software Features
|
LAN Lite
License |
Baseline
Features |
|
Layer 2
Switching |
IEEE 802.1, 802.3,
802.3at, 802.3af standard (see Table 6), VTPv2, NTP, UDLD, CDP, LLDP,
Unicast MAC filter, Resilient Ethernet Protocol (REP), Media Redundancy
Protocol (MRP) Ring (IEC 62439-2) |
|
Security |
SCP, SSH, SNMPv3,
TACACS+, RADIUS Server/Client, MAC Address Notification, BPDU Guard, SPAN
session |
|
Multicast |
IGMPv1, v2, v3
Snooping, IGMP filtering, IGMP Querier |
|
Management |
Fast Boot, Express
Setup, Web Device Manager, CNA, Cisco Prime, LMS, MIB, SmartPort, SNMP,
syslog |
|
Industrial
Ethernet |
EtherNet/IP, Profinet
v2 |
|
LAN Base
License |
Additional
Features |
|
Layer 2
Switching |
VTPv3, EtherChannel,
Voice VLAN, Flexlink |
|
Security |
IPv4 Port-Security,
DHCP Snooping, Dynamic ARP Inspection, IP Source Guard, 802.1x, Guest
VLAN. MAC Authentication Bypass, 802.1x Multi-Domain Authentication, Storm
Control, Trust Boundary, Access-List (ACL), IPv6 MLD
snooping |
|
Quality of
Service |
IPv4 Ingress Policing,
Rate-Limit, Egress Queuing/Shaping, AutoQoS |
|
Management |
Port-Based DHCP, Storm
Control - Unicast, Multicast, Broadcast, SPAN Sessions, RSPAN, DHCP
Server, Customized TCAM/SDM Size Configuration, Embedded Event Manager
(EEM) |
|
Industrial
Ethernet |
IEEE 1588
PTPv2 |
|
IPv4
Routing |
IPv4 static
routing |
|
IPv6
Routing |
IPv6 host support, HTTP
over IPv6, SNMP over IPv6 |
|
Enhanced LAN
Base |
Additional
Features |
|
Industrial
Management |
Layer 2 switching with
1:1 static Network Address Translation (NAT) |
|
IP Lite
License |
Additional
Features |
|
IPv4
Routing |
RIP, OSPF, EIGRP, VRF
Lite, PIM for L3 multicast routing including sparse (SM) and dense (DM)
mode. |
|
IPv6
Routing |
IPv6 Static routing,
OSPFv3 |
|
Security |
FIPS
140-2 |
|
Embedded Event
Manager |
EEM feature enabled
with IP Lite License |
Table 4. Compliance Specifications
|
Description |
Specification |
|
Safety
Certifications |
UL/CSA
60950-1 |
|
EN
60950-1 |
|
CB to IEC 60950-1 (with
country deviations) |
|
NOM to NOM-019-SCF1
(through partners and distributors) |
|
CE
Marking |
|
Hazard
Location |
ANSI/ISA 12.12.01
(Class1, Div2 A-D)* |
|
EN 60079-0, -15 ATEX
Certificate (Class 1, Zone2 A-D)* |
|
* Cabinet
enclosure required |
|
EMC Emissions and
Immunity Compliance |
FCC 47 CFR Part 15
Class A |
|
EN 55022A Class
A |
|
VCCI Class
A |
|
RoHS
compliance |
|
AS/NZS CISPR 22 Class
A, AS/NZS CISPR 24 |
|
CISPR11 Class A,
CISPR22 Class A |
|
ICES 003 Class
A |
|
KCC
-Korea |
|
CE
Marking |
|
C-Tick
(Australia) |
|
Russia
certification |
|
Brazil
certification |
|
IEC/EN/EN61000-4-2
(Electro Static Discharge), 15kV air/8kV contact |
|
IEC/EN 61000-4-3
(Radiated Immunity, 10 and 20 V/m) |
|
IEC/EN 61000-4-4 (Fast
Transients - 4kV power line, 4kV data line) |
|
IEC/EN 61000-4-5 (Surge
2 kV/1 kV) |
|
IEC/EN 61000-4-6
(Conducted Immunity, 10 V/emf) |
|
IEC/EN 61000-4-8 (Power
Frequency Magnetic Field Immunity) |
|
IEC/EN 61000-4-9 (Pulse
Magnetic Field Immunity) |
|
IEC/EN 61000-4-10
(Oscillatory Magnetic Field Immunity) |
|
IEC/EN 61000-4-11 (AC
power Voltage Immunity) |
|
IEC/EN 61000-4-29
(Voltage Dips Immunity) |
|
IEC/EN 61000-6-1
(Immunity for Light Industrial Environments) |
|
IEC/EN 61000-6-2
(Immunity for Industrial Environments) |
|
IEC/EN 61000-6-4 Class
A |
|
EN
61326 |
|
Shock and
Vibration |
IEC 60068-2-27
(Operational Shock: 30G 11ms, half sine) |
|
IEC 60068-2-27
(Non-Operational Shock 55-70G, trapezoidal) |
|
IEC 60068-2-6, IEC
60068-2-64, EN 61373 (Operational Vibration) |
|
IEC 60068-2-6, IEC
60068-2-64, EN 61373 (Non-operational Vibration) |
|
Industry
Standards |
UL508 |
|
CSA C22.2 No.
142 |
|
EN 61131-2 (EMC/EMI,
environmental, mechanical) |
|
Protective coating
(specific models only) |
|
Marine
DnV |
|
Substation KEMA (IEEE
1613, IEC 61850-3) |
|
Railway EN 50155
(EMI/EMC, environmental, mechanical) |
|
EN50121-3-2 |
|
EN50121-4 |
|
NEMA TS-2 (EMC,
environmental, mechanical) |
|
ABB Industrial IT
certification |
|
IP30 |
|
ODVA Industrial
Ethernet/IP support |
|
PROFINETv2.3
support |
|
Corrosive
Testing |
ISO-12944-6 |
|
IEC-60068-2-60 |
|
Humidity |
IEC 60068-2-52 (salt
fog mist, test Kb) marine environments |
|
IEC 60068
-2-3 |
|
IEC
60068-2-30 |
|
Relative humidity: 5%
to 95% non-condensing |
|
Operating
Temperature |
-40C to +70C (vented
enclosure - 40 LFM Air Flow) |
|
-40C to +60C (sealed
enclosure 0 LFM Air Flow) |
|
-34C to +75C (fan or
blower-equipped enclosure 200 LFM Air Flow) |
|
-40C to +85C (IEC
60068-2-2 Environmental Type Testing 16 hours) |
|
Operational altitude:
Up to 15,000 ft |
|
Storage
Temperature |
-40 C to +85 C (storage
temperature) |
|
IEC
60068-2-14 |
|
Storage altitude: Up to
15,000 ft |
|
Mean Time Between
Failure (MTBF) |
Mean time between
failure: 374,052 hours (42.7 years) |
|
Warranty |
Five-year limited
warranty on all IE-2000 HW PIDs and all IE Power Supplies defined in table
4 above. See link below for details on
warranty |
Table 5. Management and Standards
|
Description |
Specification |
Specification |
|
IEEE
Standards |
IEEE 802.1D MAC
bridges, STP |
IEEE 802.3af
Power over Ethernet |
|
IEEE 802.1p Layer
2 COS prioritization |
IEEE 802.3at
Power over Ethernet Plus |
|
IEEE 802.1q
VLAN |
IEEE 802.3ah
100BASE-X SMF/MMF only |
|
IEEE 802.1s
Multiple Spanning-Trees |
IEEE
802.3x full duplex on 10Base-T |
|
IEEE
802.1w Rapid Spanning-Tree |
IEEE 802.3
10BASE-T specification |
|
IEEE
802.1x Port Access Authentication |
IEEE 802.3u
100BASE-TX specification |
|
IEEE 802.1AB
LLDP |
IEEE 802.3ab
1000BASE-T specification |
|
IEEE 802.3ad Link
Aggregation (LACP) |
IEEE 802.3z
1000BASE-X specification |
|
IEEE 802.3af
Power over Ethernet provides up to 15.4WDC power to each end
device |
IEEE 1588v2 PTP
Precision Time Protocol |
|
IEEE 802.3at
Power over Ethernet provides up to 25.5WDC power to each end
device |
|
|
RFC
Compliance |
RFC 768:
UDP |
RFC 1305:
NTP |
|
RFC 783:
TFTP |
RFC 1492:
TACACS+ |
|
RFC 791: IPv4
protocol |
RFC 1493:
Bridge MIB Objects |
|
RFC 792:
ICMP |
RFC 1534 DHCP and
BootP interoperation |
|
RFC 793:
TCP |
RFC 1542:
Bootstrap Protocol |
|
RFC 826:
ARP |
RFC 1643:
Ethernet Interface MIB |
|
RFC 854:
Telnet |
RFC 1757:
RMON |
|
RFC 951:
BootP |
RFC 2068:
HTTP |
|
RFC 959:
FTP |
RFC 2131, 2132:
DHCP |
|
RFC 1157:
SNMPv1 |
RFC 2236: IGMP
v2 |
|
RFC
1901,1902-1907 SNMPv2 |
RFC 3376: IGMP
v3 |
|
RFC 2273-2275:
SNMPv3 |
RFC 2474:
DiffServ Precedence |
|
RFC 2571: SNMP
Management |
RFC 3046: DHCP
Relay Agent Information Option |
|
RFC 1166: IP
Addresses |
RFC 3580:
802.1x RADIUS |
|
RFC 1256: ICMP
Router Discovery |
RFC 4250-4252 SSH
Protocol |
|
Simple Network
Management Protocol (SNMP) MIB Objects |
BRIDGE-MIB |
CISCO-SNMP-TARGET-EXT-MIB |
|
CALISTA-DPA-MIB |
CISCO-STACK-MIB |
|
CISCO-ACCESS-ENVMON-MIB |
CISCO-STACKMAKER-MIB |
|
CISCO-ADMISSION-POLICY-MIB |
CISCO-STP-EXTENSIONS-MIB |
|
CISCO-AUTH-FRAMEWORK-MIB |
CISCO-SYSLOG-MIB |
|
CISCO-BRIDGE-EXT-MIB |
CISCO-TCP-MIB |
|
CISCO-BULK-FILE-MIB |
CISCO-UDLDP-MIB |
|
CISCO-CABLE-DIAG-MIB |
CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB |
|
CISCO-CALLHOME-MIB |
CISCO-VLAN-MEMBERSHIP-MIB |
|
CISCO-CAR-MIB |
CISCO-VTP-MIB |
|
CISCO-CDP-MIB |
ENTITY-MIB |
|
CISCO-CIRCUIT-INTERFACE-MIB |
ETHERLIKE-MIB |
|
CISCO-CLUSTER-MIB |
HC-RMON-MIB |
|
CISCO-CONFIG-COPY-MIB |
IEEE8021-PAE-MIB |
|
CISCO-CONFIG-MAN-MIB |
IEEE8023-LAG-MIB |
|
CISCO-DATA-COLLECTION-MIB |
IF-MIB |
|
CISCO-DHCP-SNOOPING-MIB |
IP-FORWARD-MIB |
|
CISCO-ENTITY-ALARM-MIB |
IP-MIB |
|
CISCO-ENTITY-VENDORTYPE-OID-MIB |
LLDP-EXT-MED-MIB |
|
CISCO-ENVMON-MIB |
LLDP-MIB |
|
CISCO-ERR-DISABLE-MIB |
NETRANGER |
|
CISCO-FLASH-MIB |
NOTIFICATION-LOG-MIB |
|
CISCO-FTP-CLIENT-MIB |
OLD-CISCO-CHASSIS-MIB |
|
CISCO-IF-EXTENSION-MIB |
OLD-CISCO-CPU-MIB |
|
CISCO-IGMP-FILTER-MIB |
OLD-CISCO-FLASH-MIB |
|
CISCO-IMAGE-MIB |
OLD-CISCO-INTERFACES-MIB |
|
CISCO-IP-STAT-MIB |
OLD-CISCO-IP-MIB |
|
CISCO-LAG-MIB |
OLD-CISCO-MEMORY-MIB |
|
CISCO-LICENSE-MGMT-MIB |
OLD-CISCO-SYS-MIB< |
|
CISCO-MAC-AUTH-BYPASS-MIB |
OLD-CISCO-SYSTEM-MIB |
|
CISCO-MAC-NOTIFICATION-MIB |
OLD-CISCO-TCP-MIB |
|
CISCO-MEMORY-POOL-MIB |
OLD-CISCO-TS-MIB |
|
CISCO-PAE-MIB |
RMON-MIB |
|
CISCO-PAGP-MIB |
RMON2-MIB |
|
CISCO-PING-MIB |
SMON-MIB |
|
CISCO-PORT-QOS-MIB |
SNMP-COMMUNITY-MIB |
|
CISCO-PORT-SECURITY-MIB |
SNMP-FRAMEWORK-MIB |
|
CISCO-PORT-STORM-CONTROL-MIB |
SNMP-MPD-MIB |
|
CISCO-PRIVATE-VLAN-MIB |
SNMP-NOTIFICATION-MIB |
|
CISCO-PROCESS-MIB |
SNMP-PROXY-MIB |
|
CISCO-PRODUCTS-MIB |
SNMP-TARGET-MIB |
|
CISCO-RESILIENT-ETHERNET-PROTOCOL-MIB |
SNMP-USM-MIB |
|
CISCO-RTTMON-ICMP-MIB |
SNMP-VIEW-BASED-ACM-MIB |
|
CISCO-RTTMON-IP-EXT-MIB |
SNMPv2-MIB |
|
CISCO-RTTMON-MIB |
TCP-MIB |
|
CISCO-RTTMON-RTP-MIB |
UDP-MIB |
Service and Support
Cisco is committed to reducing your total cost of ownership (TCO). We offer a
portfolio of technical support services to help ensure that products operate
efficiently, remain highly available, and benefit from the most up-to- date
system software. The services and support programs described in Table 7 are
available as part of the Cisco Desktop Switching Service and Support solution
and are available directly from Cisco and through resellers.
Table 6. Cisco Services and Support Programs
|
Advanced
Services |
|
|
|
Cisco Total
Implementation Solutions (TIS), available directly from
Cisco |
Project
management |
Supplements existing
staff |
|
Cisco Packaged TIS,
available through resellers |
Site survey,
configuration, and deployment |
Helps ensure that
functions meet needs |
|
Cisco SMARTnet and
SMARTnet Onsite support, available directly from Cisco |
Installation, text, and
cutover |
Mitigates
risk |
|
Cisco Packaged SMARTnet
support program, available through resellers |
Training |
Helps enable proactive
or expedited issue resolution |
|
Cisco SMB Support
Assistant |
Major moves, adds, and
changes |
Lowers TCO by taking
advantage of Cisco expertise and knowledge |
|
Design review and
product staging |
Reduces network
downtime |
|
24-hour access to
software updates |
|
|
Web access to technical
repositories |
|
|
Telephone support
through the Cisco Technical Assistance Center (TAC) |
|
|
Advance replacement of
hardware parts |
|
Networking
