All stock codes associated to this product
ST8000NM017B, HASEX8TB512E72B, HAS-EX8TB512E72B, SE3858012S, 06ST8000NM017B
The Exos 7E10 enterprise hard drive by Seagate is a reliable and cost-effective way to store up to 10TB of data for demanding data center operations that require 24/7 uptime. With ironclad security and rock-solid reliability, the Exos 7E10 drive helps to catalyse the datasphere and delivers trusted performance for data centre architects and IT professionals.
With state-of-the-art cache, on-the-fly errorcorrection algorithms, and rotational vibration design, the Exos 7E10 helps ensure consistent performance in replicated and RAID multi-drive systems. 10 that of desktop hard drives, Exos 7E10 drives are backed by a 2 million hour MTBF rating and support workloads of 550 TB per year.
You can tailor your nearline storage requirements for even greater improvements in lowering your TCO with user-definable innovative technology advancements like PowerChoice and Seagate RAID Rebuild. The Exos 7E10 delivers easy integration into bulk storage systems with 12 Gb/s SAS and SATA 6 Gb/s interface options. Meet your storage workload requirements in the most efficient and cost-effective data centre footprint on the market today.
Data Protection, Enhanced Reliability, and Security. Advanced security features help protect data where it lives on the drive. Exos 7E10 prevents unauthorised drive access and safeguards stored data with security features that include Secure Downloads &/span>agnostics, TCG-compliant Self-Encrypting Drive, and government-grade FIPS/Common Criteria tamper-resistent hard drive. 2 Seagate Secure drives simplify drive repurposing and disposal, help protect data-at-rest, and comply with corporate and federal data security mandates.
Best-Fit Applications
- Hyperscale applications/cloud data centres
- Massive scale-out data centres
- OLTP and HPC applications
- High-capacity density RAID storage
- Mainstream enterprise external storage arrays
- Distributed file systems, including Hadoop and Ceph
- Enterprise backup and restore D2D, virtual tape
- Centralised surveillance
Specifications
| Cache | 256MB |
| Capacity | 8TB |
| Form Factor | 3.5" |
| Interface | SATA |
| Misc. | |
| Product Family | Exos |
| RPM | 7200 |
| Series | Exos 7E10 |
| Warranty | 5 Years |
| Weight | 716 g |
| Bytes per Sector | 512 |
| Max. Sustained Transfer Rate OD | 255MB/s |
| MTBF | 2,000,000 hours |
Environmental
| Shock, Non-operating, (1 ms/2 ms) (Gs) | 150/300 |
| Shock, Operating 2 ms Read/Write (Gs) | 70/40 Gs |
| Temperature, Operating | 5°C – 60°C |
Power Consumption
| Idle Power, Average (W) | 7.06 |
| Power Supply Requirements | +12 V and 5 V |
| Typical Operating, Random Read (W) | 11.03 |
Reliability/Data Integrity
| Power-On Hours per Year | 8,760 |
| Reliability Rating @ Full 24?7 Operation (AFR) | 0.44% |
| Vibration, Non-operating: 10 Hz to 500 Hz (Grms) | 5 |
