Lenovo 4XB7A82259 ThinkSystem 480GB 2.5" 5400 PRO Read Intensive

Performance
Interface	Serial ATA III
Component for	Server/workstation
SSD capacity	480 GB
Memory type	3D TLC NAND
Random read (4KB)	95000 IOPS
Random write (4KB)	37000 IOPS
Read latency	170  Âµs
Write latency	42  Âµs
S.M.A.R.T. support	Yes
Hot-swap	Yes
Mean time between failures (MTBF)	3000000 h
Compatible products	ThinkSystem
Design
Certification	Micron Green Standard Built with sulfur resistant resistors CE (Europe): EN 55032 Class B, RoHS UKCA (UK): SI 2016/1091 Class B and SI 2012/3032 RoHS FCC: CFR Title 47, Part 15 Class B UL/cUL: approval to UL-60950-1, 2nd Edition, IEC 60950-1:2005 (2nd Edition); EN 60950-1 (2006) + A11:2009+ A1:2010 + A12:2011 + A2:2013 BSMI (Taiwan): approval to CNS 13438 Class B and CNS 15663 RCM (Australia, New Zealand): AS/NZS CISPR32 Class B KC RRA (Korea): approval to KN32 Class B, KN 35 Class B W.E.E.E.: compliance with EU WEEE directive 2012/19/EC TUV (Germany): approval to IEC60950/EN60950 VCCI (Japan): 2015-04 Class B IC (Canada): ICES-003 Class B Morocco: approval to EN55032/EN55024 Class B UkrSEPRO (Ukraine): EN55032 Class B, IEC60950/EN60950, RoHS (Resolution 2017 No. 139)
SSD form factor	2.5"
Features
Interface	Serial ATA III
Component for	Server/workstation
SSD capacity	480 GB
Memory type	3D TLC NAND
Random read (4KB)	95000 IOPS
Random write (4KB)	37000 IOPS
Read latency	170  Âµs
Write latency	42  Âµs
S.M.A.R.T. support	Yes
Hot-swap	Yes
Mean time between failures (MTBF)	3000000 h
Certification	Micron Green Standard Built with sulfur resistant resistors CE (Europe): EN 55032 Class B, RoHS UKCA (UK): SI 2016/1091 Class B and SI 2012/3032 RoHS FCC: CFR Title 47, Part 15 Class B UL/cUL: approval to UL-60950-1, 2nd Edition, IEC 60950-1:2005 (2nd Edition); EN 60950-1 (2006) + A11:2009+ A1:2010 + A12:2011 + A2:2013 BSMI (Taiwan): approval to CNS 13438 Class B and CNS 15663 RCM (Australia, New Zealand): AS/NZS CISPR32 Class B KC RRA (Korea): approval to KN32 Class B, KN 35 Class B W.E.E.E.: compliance with EU WEEE directive 2012/19/EC TUV (Germany): approval to IEC60950/EN60950 VCCI (Japan): 2015-04 Class B IC (Canada): ICES-003 Class B Morocco: approval to EN55032/EN55024 Class B UkrSEPRO (Ukraine): EN55032 Class B, IEC60950/EN60950, RoHS (Resolution 2017 No. 139)
SSD form factor	2.5"
Compatible products	ThinkSystem
Power
Power consumption (write)	3.1 W
Power consumption (read)	2.5 W
Operational conditions
Operating temperature (T-T)	0 - 70  Â°C
Storage temperature (T-T)	-40 - 85  Â°C
Operating relative humidity (H-H)	5 - 95%
Non-operating shock	1500 G
Technical details
Interface	Serial ATA III
Operating temperature (T-T)	0 - 70  Â°C
Storage temperature (T-T)	-40 - 85  Â°C
Operating relative humidity (H-H)	5 - 95%
Non-operating shock	1500 G
SSD form factor	2.5"
Weight & dimensions
Width	70 mm
Depth	100 mm
Height	7 mm
Weight	70 g

---

The ThinkSystem 5400 PRO Read Intensive SATA 6Gb SSDs are general-purpose self-encrypting SSDs (SEDs) based on the Micron 5400 PRO platform and are available in capacities ranging from 240GB to 7.86TB. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads. This product guide provides essential presales information to understand the 5400 PRO SSDs, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the 5400 PRO SSDs and consider their use in IT solutions.
