Specification
|
| Model |
DE45-HG |
| Housing Material: |
SECC t=0.8mm |
| Housing Color: |
Black |
| Form Factor: |
AOpen Form Factor |
| Dimension: |
6.54(W) x 1.89(H) x 6.18(D)inch
166(W) x 48(H) x 157(D)mm |
| Volume: |
1.25L |
| Weight(Kg/Pound) : |
1.22kg / 2.68 pound (N.W.) |
| CPU: |
FSB 667/800/1066MHz
Support Intel Core 2 Duo, Celeron Mobile CPU (Penryn & Santa Rosa Refresh) TDP35W
Socket P |
| Chipset: |
Intel GM45+ICH9M Chipset |
| Memory: |
Dual Channel Mode
200-pin DDRII SO-DIMM x 2
Max memory size : 8GB*
Note : * For 4GB above memory suggestion please install 64-bit operation system.
DDRII 667/800 |
| Graphics: |
HDMI Port x 1, D-Sub VGA Port x 2
Intel GMA X4500MHD |
| Expansion Slot: |
mini Card Slot : x 1
mini PCI Slot : N/A |
| Audio: |
Realtek ALC662 HD Audio CODEC on-board
Stereo / 5.1 CH with HDMI |
| LAN: |
Intel Gigabit Ethernet 10/100/1000 |
| USB: |
Integrated in chipset
USB 2.0 Port x 4 (2 Rear, 2 Front) |
| IEEE 1394: |
N/A |
| Storage: |
ATA Connector : x 1 (for Slim Optical)
S-ATA Connector : x 1 (for 2.5" HDD) |
| Storage Bay: |
Slot-in Slim ODD Bay : x 1
2.5" SATA II HDD Bay : x 1
CF card socket : N/A |
| Chassis: |
Slot-in Slim ODD Bay x 1
2.5" SATA II HDD Bay x 1 |
| Front Panel IO: |
Power Button x 1
HDD indicator (Blue) x 1
Power indicator (Blue) x 1
USB 2.0 Port x 2 |
| Rear Panel IO: |
DC in Jack : x 1
DVI Port : N/A
VGA Port : x 2
HDMI Port : x 1
S-Video Out Port : N/A
USB 2.0 Port : x 2
IEEE 1394 Port : N/A
RJ-45 LAN Jack : x 1
Legacy RS232 Serial Port (COM Port) : RS232 Serial Port x 1
PS/2 Port : N/A
Audio Set Line-In : N/A
Audio Set Line-Out : x 1
Audio Set Mic-In : x 1
Upgrade for Antenna Port : x 1
Kensington Lock Hole : x 1
Audio I/O Ports : 2.1 channel Audio I/O Ports x 1 (Line-Out, Mic-In)
D-Sub Port : D-Sub VGA Port x 2 |
| Security: |
N/A
Kensington Lock Hole : x 1 (Rear) |
| CPU Thermal: |
Module : AOpen Thermal Module
Noise : 27dB |
| WatchDog Timer: |
1 ~ 255 sec/min |
| Adapter: |
90W (20V, 4.5A) AC Adapter |
| Input Voltage: |
AC 100 ~ 240V |
| Environment: |
MTBF : 40,000 hrs
Operating Temperature : 0 ~ 50C (32 ~ 122F)
Storage Temperature : -30 ~ 60C (-22 ~ 140F)
Relative Humidity : 90% RH (45C non-Condensing)
Operating Vibration : 0.5Grms, Random, 10~500Hz, X,Y,Z 3Axes, 0.5hr/Axis
Non-Operating Vibration : 2Grms, random, 10~300Hz, X,Y,Z 3Axes, 1hr/Axis
Operating Shock : 8G, half sine, 11ms duration, X,Y,Z 3Axes, 6Direction, 3 shocks/direction
Non-Operating Shock : 50G, Half sine, 11ms duration |
| Accessory: |
90W Power Adapter x 1
DE-SATA V1 : X 1
Optional : Please check out our "Accessories" for detail
Power Cord x 1
MPI-SATA Riser Card x 1
AOpen Proprietary "L" Bracket x 1
Screw Bag M3*L5 (4pcs) x 1 (for 2.5" HDD)
Screw Bag M3*L5 (8pcs) x 1 (for 'L' Bracket)
Screw Bag M2*L3 (7pcs) x 1 (for ODD and Riser Card)
Utilities & Drivers CD x 1
Assembly Guide x 1 |
| Certification: |
CE, FCC, UL, CB |
| Support OS: |
Windows Vista Home Ultimate / Premium / Basic, Windows XP, Windows Embedded |
