| Operation |
|
| CPU |
ARM7 32-bit |
| O/S |
Proprietary |
| RTC |
Supports year, month, day, hour, minute, second (leap year supported) |
| Memory |
|
| FlashROM |
512 kB (Program storage + >15.000 barcodes + time stamp) |
| RAM |
64 kB |
| Operating indicators |
|
| Visual |
1 LEDbar (red/green/orange) |
| Non-visual |
Buzzer |
| Operating keys |
|
| Entry options |
2 keys total, 1 clear key, 1 scan key |
| Communication |
|
| USB |
Mini USB, Ver. 1.1, VCP |
| Power |
|
| Rechargeable battery |
Lithium-Ion 3.7V 150mAh |
| Operating time |
1.000 scans (1 scan / 5 sec) |
| Charging method |
Enclosed USB cable |
| Barcode scanner Optics |
|
| Light source |
650 nm visible laser diode |
| Scan method |
Vibrating mirror |
| Scan rate |
100 scans/sec |
| Reading pitch angle |
-30 to 0, 0 to +30 |
| Reading skew angle |
-50 to -8, +8 to +50 |
| Reading tilt angle |
-20 to 0, 0 to +20 |
| Curvature |
R>15 mm (EAN8), R>20 mm (EAN13) |
| Min. PCS value |
0.45 |
| Depth of field |
60 - 570 mm / 2.36 - 22.44 in (1.0 mm / 39 mil), 40 - 360 mm / 1.57 - 14.17 in (0.5 mm / 20 mil), 40 - 220 mm / 1.57 - 8.66 in (0.25 mm / 10 mil), 40 - 120 mm / 1.57 - 4.72 in (0.15 mm / 6 mil), 50 - 100 mm / 1.97 - 3.94 in (0.127 mm / 5 mil), at PCS 0.9 UPC |
| Supported Symbologies |
|
| Barcode (1D) |
JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey |
| Postal code |
Chinese Post, Korean Postal Authority code |
| Durability |
|
| Temperature in operation |
0 to 40 C / 32 to 104 F |
| Temperature in storage |
-20 to 60 C / -4 to 140 F |
| Ambient light immunity |
White 3,000 lx max, Fluorescent 3,000 lx max, Direct sun 50,000 lx max |
| Protection rate |
IP 42 |
| Physical |
|
| Dimensions (w x h x d) |
32 x 62 x 16 mm / 1.26 x 2.44 x 0.63 in |
| Weight body |
Ca. 28 g / 1 oz (incl. battery) |
| Case |
ABS, Black |
| Regulatory &Safety |
|
| Product compliance |
CE, FCC, VCCI, RoHS, JIS-C-6802 Class 2, IEC 60825-1 Class 2, FDA CDRH Class II |
