- Expands 2 independent RS-232 serial ports over Ethernet networking.
- Works as a PCIe add-on card operating experience with Ethernet Hot-Plug capability.
- DevicePort® Dock mode supports secured connection between PC host and DevicePort®.(*Note 1)
- Built-in SUNIX DevicePort® DPL2000Q High-Performance Ethernet-UART/Printer controller.
- SUNIX DevicePort® proprietary Ethernet I/O Redirection Technology. (*Note 2)
- Port auto-mapping with real time data transmit and receive communication.
- Physical COM port accessed via device manager.
- Up to 12 COM ports working on windows system simultaneously.
- Accesses tradition COM port by using existing software and AP.
- Low power consumption design for Green Environment.
- Certified by CE, FCC, VCCI, C-Tick, BSMI, RoHS, and Microsoft WHQL approval.
Note:
1. To prevent on-line spy recording, DevicePort® Dock Mode limits
specific Ethernet port connection, and it does not works on router or
switch operation.
2. Ethernet I/O Redirection technology is SUNIX proprietary protocol for COM, LPT, and digital IO expansion over category 5/6 Ethernet cable.
Specifications
Serial Communication
- Interface:RS-232
- Baud rate50bps ~115.2Kbps
- Controller:SUNIX DPL2000Q
- Stop bit:1, 1.5, 2
- BUS:Ethernet
- Parity:even, odd, none, mark, space
- No. of Port:2-port
- Flow Control:Xon/Xoff (software)
- FIFO:1Kbyte Hardware / per port
- Connector:DB9 Male
- Signal: DCD, TxD, RxD, RTS, CTS, DTR, DSR, GND, RI
- Protection:
- ±15KV ESD IEC6000-4-2 Air Discharge
- ±8KV ESD IEC61000-4-2 Contact Discharge
- ±4KV ESD IEC61000-4-2 Level2 Line-to-Line
Ethernet Communication
- Number of Ports
- 2-port (*Note 1)
- Upstream to Ethernet Switch
- Downstream to PC Host
- Speed: 10/100 Mbps, auto MDI/MDIX
- Connector: RJ45
- Magnetic Isolation Protection:1.0K Built-in
Power Requirements
- Input Voltage:5 to 12VDC
- Power Consumption:2.5W @ 5VDC
- Connector:DC-Jack
Driver Support
- Windows ClientXP (X86) / 7 / 8 / 8.1 / 10 (X86/X64)
- Windows Server2003 / 2008 / 2012R2 (X64)
Regulatory Approvals
- Hardware
- ?EUR: CE EN55022 Class B, EN55024
- US: FCC Part 15 Class B
- TAIWAN: BSMI: CNS13438
- AS/NZS: C-Tick: CISPR22 AS/NZS
- JAPAN: VCCI
- Software
- Microsoft WHQL Windows
- Microsoft Client: XP (X86) / 7 / 8 / 8.1 (X86/X64)
- Microsoft Server: 2003/2008/2012R2 (X64)
Environment
- Operation Temperature0 to 45°C
- Operation Humidity5 to 95% RH (non-condensing)
- Storage Temperature-20 to 85°C
Physical Characteristics
- Housing:ABS, PC, Metal
- Weight:145g
- Dimensions:121x81.93x27(mm), 4.7x3.2x1.0(inch)
