| Supported Operating Systems |
| Operating system |
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro 64) |
| Operating system note |
This
system is preinstalled with Windows 7 Professional software and also
comes with a license and media for Windows 10 Pro software. You may only
use one version of the Windows software at a time. Switching between
versions will require you to uninstall one version and install the other
version. You must back up all data (files, photos, etc.) before
uninstalling and installing operating systems to avoid loss of your
data. |
| Processor |
| Chipset |
Intel® C236 |
| Processor speed |
3.5 GHz |
| Processor family |
Intel® Xeon® E3 processor |
| Processor |
Intel® Xeon® E3-1240 v5 (3.5 GHz, up to 3.9 GHz with Intel Turbo Boost Technology, 8 MB cache, 4 cores) |
| Number of processors |
1 |
| Memory |
| Memory, standard |
16 GB DDR4-2133 ECC registered SDRAM (2 x 8 GB) |
| Memory slots |
4 UDIMM |
| Standard memory note |
Transfer rates up to 2133 MT/s |
| Drives |
| Hard drive description |
HP Z Turbo Drive 256 GB PCIe SSD |
| Optical drive |
Slim SATA Blu-ray writer |
| External drive bays |
One shared 3.5" (shared with internal 3.5" bay)
One slim ODD |
| Internal drive bays |
One 3.5"
One 2.5"
One shared 3.5" (shared with external 3.5" bay) |
| Storage type |
SSD |
| Storage controller |
Integrated
SATA (4 ports 6 Gb/s) with RAID 0 (striped array) and RAID 1 (mirrored
array) supported on Windows operating system only. Requires identical
hard drives (speeds, capacity, interface). Integrated RAID 0, 1 (data
configuration) for PCIe SSDs. |
|
| Compatible displays |
HP Z27s 27-inch UHD Display
HP Z27q 27-inch IPS 5K Display
HP Z24s 24-inch UHD IPS Display
HP Z Display Z30i 30-inch IPS LED Backlit Monitor
HP Z Display Z27i 27-inch IPS LED Backlit Monitor
HP Z Display Z24i 24-inch IPS LED Backlit Monitor
HP Z Display Z23i 23-inch IPS LED Backlit Monitor
HP Z Display Z22i 21.5-inch IPS LED Backlit Monitor
HP DreamColor Z24x Professional Display
HP DreamColor Z27x Professional Display |
| Graphic Subsystem |
| Graphics |
NVIDIA® Quadro® K1200 (4 GB) |
| Graphics |
Discrete |
| Multimedia |
| Audio |
Integrated Realtek HD ALC221-VB audio |
| Input devices |
| Keyboard |
HP Wireless Business Slim Keyboard |
| Pointing device |
HP USB Optical Mouse |
| Connectivity and Communications |
| Network interface |
Integrated Intel® I219LM PCIe GbE |
| Ports |
2 USB 3.0
2 USB 2.0 (1 charging)
1 headphone
1 microphone/headphone |
| Expansion slots |
1 PCIe Gen3 x16
2 PCIe Gen3 x1 (x1 connector)
1 PCIe Gen3 x4 (x16 connector) |
| Expansion slots note |
All slots are low profile |
| I/O Port location |
Front |
| Ports |
6 USB 3.0
3 DisplayPort 1.2
1 serial
2 PS/2
1 RJ-45
1 audio line-in
1 audio line-out |
| I/O Port location |
Back |
| Ports |
1 USB 3.0
2 USB 2.0 |
| I/O Port location |
Internal |
| Ports note |
1
USB 3.0 and 2 USB 2.0 ports available as 2 separate 2x10(3.0 x1, 2.0
x1) and 1x6(2.0 x1) header. Supports one HP Internal USB 2.0 Port Kit
and one USB 3.0 media card reader. |
| Battery and Power |
| Power |
240 W 92% efficient, wide-ranging, active PFC |
| Weights |
| Weight |
Starting at 5.7 kg |
| System Components |
| Form factor |
Small Form Factor |
| Dimensions |
| Minimum dimensions (W x D x H) |
338 x 381 x 100 mm |
| Warranty |
| Warranty |
3-year
(3-3-3) limited warranty and service offering includes 3 years of
parts, labor and on-site repair. Terms and conditions vary by country.
Certain restrictions and exclusions apply. |
