Supported Operating Systems |
Operating system |
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) |
Operating system note |
This
system is preinstalled with Windows 7 Professional software and also
comes with a license and media for Windows 10 Pro software. You may only
use one version of the Windows software at a time. Switching between
versions will require you to uninstall one version and install the other
version. You must back up all data (files, photos, etc.) before
uninstalling and installing operating systems to avoid loss of your
data. |
Processor |
Chipset |
Intel® Q170 |
Processor speed |
500 MHz 3.2 GHz |
Processor family |
Intel® Core™ i5 processor |
Processor |
Intel® Core™ i5-6500 with Intel HD Graphics 530 (3.2 GHz, up to 3.6 GHz with Intel Turbo Boost, 6 MB cache, 4 cores) |
Memory |
Memory, standard |
4 GB DDR4-2133 SDRAM (1 x 4 GB) |
Memory slots |
2 SODIMM |
Drives |
Hard drive description |
1 TB SATA SSHD |
Optical drive |
Slim Tray-load SuperMulti DVD writer |
External drive bays |
One slim ODD (optional) |
Internal drive bays |
Two 2.5" |
Storage type |
SSHD |
Flash cache |
8 GB SSHD |
Flash cache note |
The
flash cache module is designed to accelerate the system response
experience and cannot be used as additional storage capacity. It is not
removable by and not accessible to the user. |
Display Specifications |
Display |
23" diagonal IPS widescreen backlit anti-glare non-touch LCD (1920 x 1080) |
Graphic Subsystem |
Graphics |
Intel® HD Graphics 530 |
Graphics |
Integrated |
Multimedia |
Audio |
Audio
by Bang and Olufsen utilizing HP Clear Sound Amp which supports the
integrated high-performance stereo 2.2W internal speakers, microphone
array, headphone jack, line-out jack and a microphone jack that is
retaskable to second headphone or line in. |
Webcam |
2 MP full HD webcam (optional) |
Input devices |
Keyboard |
HP USB Business Slim Keyboard |
Pointing device |
HP USB Mouse |
Connectivity and Communications |
Network interface |
Intel® i219M GbE |
Ports |
1 USB Type-C™ 2 USB 3.0 (1 charging) 1 headphone 1 microphone 1 SD 4 card reader (optional) |
Expansion slots |
1 M.2 2230 1 M.2 2280 |
Expansion slots note |
M.2 2230 slot for WLAN M.2 2280 slot for SSD |
I/O Port location |
Left side |
Ports |
4 USB 3.0 1 DisplayPort 1.2 1 RJ-45 1 audio line out 1 serial (optional) 2 PS/2 (keyboard/mouse) optional |
I/O Port location |
Back |
Battery and Power |
Power |
160 W, up to 90% efficient, active PFC (with integrated graphics) 200 W, up to 92% efficient, active PFC (with discrete graphics) |
Weights |
Weight |
Starting at 6.84 kg |
System Components |
Form factor |
All-in-one |
Security Management |
Security management |
HP BIOSphere with Sure Start Trusted Platform Module, SLB9670TT1.2FW4.40 (TPM) 1.2 (Common Criteria EAL4+ certified), field upgradeable to 2.0 SATA port disablement (via BIOS) Drive lock RAID (available as a configurable option) Intel® Identity Protection Technology (IPT) Serial, parallel, USB enable/disable (via BIOS) Optional USB port disable at factory (user configurable via BIOS) Removable media write/boot control Power-on password (via BIOS) Setup password (via BIOS) HP Solenoid Hood Sensor Support for chassis cable lock devices |
Security management footnote number |
[12] |
|
Software footnote number |
[10,11] |
Dimensions |
Minimum dimensions (W x D x H) |
567.2 x 59 x 392.7 mm |
Warranty |
Warranty |
On-site
Limited warranty: Three-year (3-3-3) limited warranty delivers three
years of on-site, next business-day service for parts and labor and
includes free telephone support 24 x 7. Three-year onsite and labor are
not available in all countries. Service offers terms up to 5 years by
choosing a Care Pack. To choose the right level of service for your HP
product, visit HP Care Pack Central: www.hp.com/go/cpc |
