| Supported Operating Systems |
| Operating system |
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) |
| Operating system note |
This
system is preinstalled with Windows 7 Professional software and also
comes with a license and media for Windows 10 Pro software. You may only
use one version of the Windows software at a time. Switching between
versions will require you to uninstall one version and install the other
version. You must back up all data (files, photos, etc.) before
uninstalling and installing operating systems to avoid loss of your
data. |
| Processor |
| Chipset |
Intel® Q170 |
| Processor family |
Intel® Core™ i7 processor |
| Processor |
Intel® Core™ i7-6700 with Intel HD Graphics 530 (3.4 GHz, up to 4 GHz with Intel Turbo Boost, 8 MB cache, 4 cores) |
| Memory |
| Memory, standard |
8 GB DDR4-2133 SDRAM (2 x 4 GB) |
| Memory slots |
4 DIMM |
| Drives |
| Hard drive description |
128 GB SATA SSD |
| Optical drive |
Slim SATA SuperMulti DVD-RW |
| External drive bays |
One 5.25"
One ODD
One slim ODD
One SD 4 card reader (optional) |
| Internal drive bays |
Two 3.5"
One 2.5" |
| Graphic Subsystem |
| Graphics |
Intel® HD Graphics 530 |
| Graphics |
Integrated |
| Multimedia |
| Audio |
DTS
Studio Soundâ„¢ audio management technology, HD audio with Realtek ALC221
codec, microphone and headphone front ports (3.5 mm), line-out and
line-in rear ports (3.5 mm), multi-streaming capable, internal speaker
(standard) |
| Input devices |
| Keyboard |
HP USB Business Slim Keyboard |
| Pointing device |
HP USB Mouse |
| Connectivity and Communications |
| Network interface |
Intel® I219LM Gigabit Network Connection LOM |
| Ports |
2 USB 3.0
2 USB 2.0 (1 fast charging)
1 headphone connector
1 headphone/microphone |
| Expansion slots |
1 full-height PCIe x16 (x4)
1 full-height PCIe x16
2 full-height PCIe x1 |
| I/O Port location |
Front |
| Ports |
6 USB 3.0
1 serial
2 PS/2 (keyboard and mouse)
1 VGA
2 DisplayPort
1 audio line in
1 audio line out
1 RJ-45 |
| I/O Port location |
Back |
| Battery and Power |
| Power |
280 W, up to 92% efficient, active PFC |
| Weights |
| Weight |
Starting at 9.43 kg |
| System Components |
| Form factor |
Microtower |
| Security Management |
| Security management |
HP BIOSphere with Sure Start
Trusted Platform Module, SLB9670TT1.2FW4.40 (TPM) 1.2 (Common Criteria EAL4+ certified), field upgradeable to 2.0
SATA port disablement (via BIOS)
Drive lock
RAID (available as a configurable option)
Intel® Identity Protection Technology (IPT)
Serial, parallel, USB enable/disable (via BIOS)
Optional USB port disable at factory (user configurable via BIOS)
Removable media write/boot control
Power-on password (via BIOS)
Setup password (via BIOS)
HP Solenoid Hood Lock/Sensor
Support for chassis padlocks and cable lock devices
HP Chassis (1 bay) Security Kit |
| Security management footnote number |
[13,14] |
|
| Software footnote number |
[10,11,12] |
| Dimensions |
| Minimum dimensions (W x D x H) |
170 x 425.4 x 389 mm |
| Warranty |
| Warranty |
3-year
(3-3-3) limited warranty and service offering includes 3 years of
parts, labor and on-site repair. Terms and conditions vary by country.
Certain restrictions and exclusions apply. |
