| Supported Operating Systems |
| Operating system |
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) |
| Operating system note |
This
system is preinstalled with Windows 7 Professional software and also
comes with a license and media for Windows 10 Pro software. You may only
use one version of the Windows software at a time. Switching between
versions will require you to uninstall one version and install the other
version. You must back up all data (files, photos, etc.) before
uninstalling and installing operating systems to avoid loss of your
data. |
| Processor |
| Chipset |
Intel® Q150 |
| Processor family |
Intel® Core™ i7 processor |
| Processor |
Intel® Core™ i7-6700 with Intel HD Graphics 530 (3.4 GHz, up to 4 GHz with Intel Turbo Boost, 8 MB cache, 4 cores) |
| Memory |
| Memory, standard |
8 GB DDR4-2133 SDRAM (2 x 4 GB) |
| Memory slots |
4 DIMM |
| Drives |
| Hard drive description |
256 GB SATA SE SSD |
| External drive bays |
One slim ODD
One SD 3 card reader (optional) |
| Internal drive bays |
Two 3.5" |
| Graphic Subsystem |
| Graphics |
Intel® HD Graphics 530 |
| Graphics |
Integrated |
| Multimedia |
| Audio |
DTS
Sound+â„¢ audio management technology, HD audio with Realtek ALC221 codec
(all ports are stereo), microphone and headphone front ports (3.5 mm),
line-out and line-in rear ports (3.5 mm), multi-streaming capable and
internal speaker. |
| Input devices |
| Keyboard |
HP USB Keyboard |
| Pointing device |
HP USB Mouse |
| Connectivity and Communications |
| Network interface |
Intel® I219LM Gigabit Network Connection LOM |
| Ports |
2 USB 3.0
2 USB 2.0 (1 fast charging)
1 headphone
1 microphone/headphone
1 SD 3 card reader (optional) |
| Expansion slots |
3 full height PCIe 3.0 x1
1 full height PCIe 3.0 x16 |
| I/O Port location |
Front |
| Ports |
6 USB 3.0
1 serial
1 serial (optional)
1 parallel (optional)
2 PS/2 (keyboard and mouse)
1 VGA
2 DisplayPort
1 audio line in
1 audio line out
1 RJ-45 |
| I/O Port location |
Back |
| Battery and Power |
| Power |
280 W standard efficiency, active PFC
280 W, up to 92% efficient, active PFC |
| Weights |
| Weight |
Starting at 7.35 kg |
| System Components |
| Form factor |
Microtower |
| Security Management |
| Security management |
Trusted Platform Module SLB9670TT1.2FW4.40 (TPM) 1.2 (Common Criteria EAL4+ certified), field upgradeable to 2.0
SATA port disablement (via BIOS)
Drive lock
Intel® Identity Protection Technology (IPT)
Serial, parallel, USB enable/disable (via BIOS)
Optional USB port disable at factory (user configurable via BIOS)
Removable media write/boot control
Power-on password (via BIOS)
Setup password (via BIOS)
HP Chassis (1 bay) Security Kit
Solenoid hood lock
Intrusion sensor
Support for chassis padlock devices
Support for chassis cable lock devices |
| Security management footnote number |
[13,14] |
| Software and Applications |
| Management features |
Intel® Standard Manageability |
| Software footnote number |
[10,11,12] |
| Dimensions |
| Minimum dimensions (W x D x H) |
170 x 358.3 x 355 mm |
| Warranty |
| Warranty |
3-year
(3-3-3) limited warranty and service offering includes 3 years of
parts, labor and on-site repair. Terms and conditions vary by country.
Certain restrictions and exclusions apply. |
