All stock codes associated to this product
20FN0016AU, 3134911
Overview
Features
Up to 6th Gen Intel Core i7 Processor
The new standard for PC performance has arrived with Intel 6th Gen Core
processors. This blazing fast, feature-packed processor family with built-in
security is ready to take your productivity, creativity, and 3D gaming to the
next level. Whats more, by enabling the exciting Windows 10 features, 6th Gen
Intel Core processors empower you to unleash your imagination and explore the
possibilities.
Up to Windows 10 Pro
Windows 10 Pro is designed to empower you and your business. It allows you to
do great things across your devices securely with anyone, anywhere, and at any
time. Fitting a variety of budgets, it's also very easy to use. So you can get
more done right from the start.
Fast Data Transfer
Move data between your laptop and other devices quickly with USB 3.0 it's up
to 10 times faster than previous USB technologies and backward-compatible with
USB 2.0.
Intel vPro Technology
Makes enterprise-level manageability even more convenient and cost-saving.
Manage, protect, repair, or locate your deployed laptops from anywhere in the
world.
Power Bridge Technology
Combining an internal battery with an external hot-swappable battery, Power
Bridge provides flexibility and maximum battery life. Swap batteries without
powering down your laptop, using an extra travel battery to increase your time
between charges.
Tested to Military Specifications
Military-specification testing validates the ruggedness, durability, and
quality of this laptop by testing against 11 parameters: high pressure,
humidity, vibration, high temperature, temperature shock, low pressure (15,000
ft), low temperature, solar radiation, fungus, salt fog, and dust.
Optional WWAN for 3G/4G connectivity
For true mobility, configure your laptop with WWAN connectivity so you can
access 3G or 4G networks provided by a third-party cellular phone service
company.
WiGig Docking Option
Improve useability with simple 802.11ad wireless docking. Eliminate cable
restriction and get instant, seamless connection from your laptop to your other
devices over the 60GHz band. Supports two visually lossless displays, mouse,
keyboard, webcam, and more, including I/O speeds as high as those available from
USB 3.0. Up to ten times faster than WiFi. Includes hibernation support and
standby.
Thin and Light Design; Long Battery Life
Starting at a mere 3.78 lbs and just 21mm thick, this laptop is ultraportable
its perfect for productivity on the go. And with up to 13 hours of battery life,
you can go all day without recharging.
Optional FHD (1920x1080) Anti-Glare Display With IPS and Multitouch
Technology
Configure your laptop with an FHD anti-glare display with In-Plane Switching
(IPS), and enjoy a premium visual experience. IPS technology allows for vivid
colors and nearly 180-degree viewing angles. Add a touch panel for enhanced
navigation and impeccable response time.
Business-Class Security
Available with fingerprint reader, this laptop lets you use biometrics for
login, so the swipe of your finger becomes your password. Intel security
features and vPro options step up protection and enhance manageability when
deploying upgrades. And a Trusted Platform Module (TPM) chip further encrypts
your critical information.
WiDi Technology
Wirelessly send movies, photos, presentations, and more from your laptop to
an HDTV.
Integrated 720p HD Webcam & Dual Noise-Cancelling
Microphones
Enjoy superior web conferencing on your laptop, which includes a low-light
sensitive 720p HD webcam with wide-angle viewing and face-tracking, dual
noise-cancelling microphones with configurations for crystal-clear private and
conference mode VoIP meetings, plus, convenient multimedia keys for quick and
easy access to microphone, speaker, and camera controls.
Stereo Speakers With Dolby Home Theater
Increased audio clarity and maximized volume output without distortion enjoy
a crisp, clear, immersive surround sound experience over built-in stereo
speakers. All the power and nuance of the cinema, all the immediacy of live
performance, now from your ThinkPad.
Specifications
Processor |
Intel Core i5-6300U
Processor (3M Cache, 2.4GHz), Turbo Boost 2.0 (3.0GHz), vPro |
Operating
System |
Windows 10 Home
64-bit |
|
Windows 10 Pro
64-bit - Lenovo recommends Windows 10 Pro. |
|
Windows 7 Professional
64-bit preinstalled through downgrade rights in Windows 10 Pro
64-bit |
Display |
14.0" FHD (1920x1080),
anti-glare, IPS, 250 nits, 16:9 aspect ratio, 700:1 contrast ratio, 160
viewing angle, optional multi-touch |
Multi-touch
(optional) |
In-cell touch, supports
10-finger gesture, 250 nits |
Graphics |
Intel HD Graphics 520,
supports external digital monitor via HDMI or Mini DisplayPort; supports
three independent displays; Max resolution: 3840x2160@60Hz (DisplayPort
via Mini DisplayPort cable); 1920x1080@60Hz (HDMI) |
Memory |
8GB
RAM |
Webcam |
HD720p, low light
sensitive, fixed focus |
Storage |
500GB
SSD |
Optical
drive |
None |
Dimensions (W x D x
H) |
339 x 232.5 x 21
mm |
Weight |
Non-touch with
3-cell+3-cell: 1.73kg |
|
Non-touch with
3-cell+6-cell: 1.87kg |
|
Touch with
3-cell+3-cell: 1.77kg Touch with 3-cell+6-cell:
1.90kg |
Case
material |
Glass-Fiber Reinforced
Plastic |
Case
colour |
Midnight
black |
Battery |
3-cell Li-Ion front
battery (23.2Wh) + 3-cell Li-Ion rear battery
(23.2Wh) |
|
3-cell Li-Ion front
battery (23.2Wh) + 6-cell Li-Ion Cylindrical High Capacity rear battery
(72Wh) |
Battery
life |
3-cell + 3-cell: Up to
10.4 hours |
|
3-cell + 6-cell: Up to
20.2 hours |
AC
adaptor |
45W |
Keyboard |
6-row, spill-resistant,
multimedia Fn keys, optional LED backlight |
UltraNav |
TrackPoint pointing
device and multi-touch with 3 buttons click pad |
ThinkLight
|
None |
Fingerprint
reader |
Optional |
Audio
support |
HD Audio, Realtek
ALC3245 codec / stereo speakers, 2W x 2 / dual array microphone, combo
audio/microphone jack |
Security
chip |
Trusted Platform Module
(Software & Hardware dTPM enabled) |
Security |
Power-on password, hard
disk password, supervisor password, security keyhole |
Chipset |
Intel SoC (System on
Chip) platform |
Ethernet |
Non-vPro model: Intel
Ethernet Connection I219-V (Jacksonville) |
|
vPro model: Intel
Ethernet Connection I219-LM (Jacksonville) |
Wireless
LAN |
Intel Dual Band
Wireless-AC 8260, 2x2, Wi-Fi + Bluetooth 4.1, no
vPro |
|
Intel Dual Band
Wireless-AC 8260, 2x2, Wi-Fi + Bluetooth 4.1,
vPro |
Wireless WAN
(optional) |
Wireless WAN
upgradable |
|
Wireless WAN, HUAWEI
ME906S, HUAWEI 4G LTE/ WCDMA/ HSPA/ GSM/ GPRS/ EDGE/ GNSS, M.2
card |
SIM
card |
None |
NFC |
None |
Mil-Spectest |
MIL-STD-810G military
certification |
Ports |
3 x USB 3.0 (one Always
On) |
|
Ethernet /
RJ45 |
|
Mini
DisplayPort |
|
HDMI |
|
4-in-1 reader (MMC, SD,
SDHC, SDXC) |
|
Combo audio/microphone
jack |
|
Dock
connector |
|
Optional Smart Card
Reader |
