Printer
Functions |
|
|
Min. Ink Droplet
Size |
1 picolitre
(minimum) |
|
Printing
Resolution |
9600 (horizontal) x
2400 (vertical) dpi1 |
|
Print
Speed2 |
B& A4: Approx.
14.5ipmColour A4: Approx. 10.4ipm,6"x4" Borderless: Approx. 36
secs |
|
Ink
Cartridges |
PGI-650BK,
CLI-651Y/CLI-651M/CLI-651C/CLI-651BK(optional PGI-650XL, CLIU-651XL and
PGI-655XXL high capacity cartridges) |
|
Ink Yield* (Borderless
4x6 photo) |
PGI-650BK / XL (approx.
2300 / 4600), CLI-651C / XL (approx. 121 / 270), CLI-651M / XL (approx.
140 / 313), CLI-651Y / XL (approx. 120 / 271); CLI-651BK / XL (approx 421
/ 1130) PGI-655 BK XXL (approx 7500) |
|
Ink Yield* (Plain paper
A4) |
PGI-650BK / XL (approx.
375 / 620), CLI-651C / XL (approx. 332 / 700), CLI-651M / XL (approx. 333
/ 670), CLI-651Y / XL (approx. 329 / 700); CLI-651BK / XL (approx. 1645 /
5000) PGI-655 BK XXL (approx 1000) |
|
Borderless
Printing3 |
Top/Bottom/Right/Left
margin: each 0 mm (Supported Paper Size: A3+, A3, A4, LTR, LDR, 4"x6",
5"x7", 8"x10", 10"x12") |
|
Plain Paper
Capacity |
150
sheets |
|
Supported Paper
Sizes |
A3+, A3, A4, A5, B5,
LTR, LGL, LDR, 4"x6", 5"x7", 8"x10", 10x12, Envelopes(DL, COM10), Custom
size (width 55 mm 329 mm, length 91 mm 676 mm) |
|
Supported Paper
Weights |
Plain Paper: 64-105
g/m2 , Canon specialty paper: max paper weight : approx. 300g/m2 (Photo
Paper Pro Platinum PT-101) |
|
Supported Paper Types
(Plain Paper) |
Plain
Paper |
|
Supported Paper Types
(Photo Paper) |
High Resolution Paper
(HR-101N)Photo Paper Pro Platinum (PT-101)Photo Paper Plus Glossy II
(PP-201)Photo Paper Plus semi-gloss (SG-201)Glossy Photo Paper "Everyday
Use" (GP-501)Glossy Photo Paper "Everyday Use" (GP-601)Matte Photo
Paper(MP-101) |
|
Supported Paper Types
(Other) |
T-shirt Transfers
(TR-301)Glossy Photo Stickers (PS-101)Envelopes (DL,
Com10) |
|
Mobile Phone/Tablet
Printing |
Print with any Apple or
Android devices through the PIXMA Printing Solutions App. Google Cloud
Print6 and Apple AirPrint supported. |
|
Protocol |
TCP/IP |
|
Wireless LAN Network
Type |
IEEE802.11n,
IEEE802.11g, IEEE802.11b |
|
Frequency Band /
Channel4 |
2.4GHz /
1-13 |
|
Wireless LAN
Range |
Indoor 50m (depends on
the transmission speed and conditions) |
|
Wireless LAN
Security |
WEP64/128bit,
WPA-PSK(TKIP/AES), WPA2-PSK(TKIP/AES) |
|
Wired LAN Network
Type |
IEEE802.3u(100BASE-TX)/IEEE802.3(10BASE-T) |
|
Wired LAN Data
Rate |
10M/100Mbps (auto
switchable) |
|
|
|
General
Features |
|
|
Interface |
USB 2.0
Hi-Speed; |
|
Operating
System |
Win: Windows XP SP3
(32-bit) / Vista SP1 / Vista SP2 / 7 / 7 SP1 / 8 / 8.1(Windows XP:XPS
Essentials Pack is required)Mac: OSX v10.6.8 or later, OS EI X Capitan
10.11 |
|
Included as
Standard |
PIXMA iX6860 All-in-One
printer, Setup CD-ROM and printed documents, 5 individual ink tanks,
sample photo paper, power cord and 12 month warranty
card |
|
Software
Included |
Easy WebPrint EX (IE7+
only), Canon Solution Menu, Adobe RGB, On Screen Manual and My Image
Garden |
|
Power
Source |
AC 100-240V,
50/60Hz |
|
Power
Consumption5 |
Standby (Lamp off,
connect to PC via WiFi): Approx 2.0W, OFF (Connect to PC via WiFi) 0.3 W,
Printing: Approx 24.0W. Energy Star / EPEAT Approved |
|
Min. Dimensions (W x D
x H) |
584 x 310 x 159
mm |
|
Weight |
Approx.
8.1kg |
|
|
|
Footnotes |
|
|
PIXMA
iX6860 |
1. 1 ink droplets
can be placed with a pitch of 1/9600 inch at minimum.2. Document print
speeds are the averages of ESAT in Office Category Test for the default
simplex mode, ISO/IEC 24734. Photo print speed is based on the default
setting using ISO/JIS-SCID N2 on Photo Paper Plus Glossy II and does not
take into account data processing time on host computer. Print speed may
vary depending on system configuration, interface, software, document
complexity, print mode, page coverage, type of paper used
etc.3. Paper types NOT supported for borderless printing are as
follows: Envelope, High Resolution Paper, T-Shirt Transfer, Photo
Stickers.4. 1-11 in US, CND, LTN, BRA and TW5. Print: When
printing ISO/JIS-SCID N2 on A3 size plain paper using default
settings.6. Scan related applications on PIXMA Cloud link is only
available when genuine Canon ink cartridges are in useSpecifications are
subject to change without notice. |
