Areca ARC-4607T2 Thunderbolt 2 to 16 Gbps FC
Adapter
Overview
ARC-4607T2, the 16 Gbps Fibre Channel solutions with Thunderbolt2,
specifically is designed for use in Apple new Mac Pro servers. ARC-4607T2 is
equipped with dual Thunderbolt 2 ports for connecting to any Thunderbolt
2-enabled host such as the new Mac Pro, and offers an additional Thunderbolt 2
port for daisy-chaining other peripherals. The Thunderbolt 2 Solution from Areca
provides the supreme performance so quick that it allows 4K video at the same
time while daisy chaining storages devices and doing a simultaneous 4K in/output
file transfers. ARC-4607T2, a Thunderbolt 2 to 16G Fibre Channel adapter, is
used to connect Thunderbolt 2 host computers to 16Gb external Fibre Channel
storage devices. ARC-4607T2 offers dual 16 Gbps Fibre Channel ports that will
auto negotiate with 16Gb, 8Gb, and 4Gb FC devices. With dual 16Gbps Fibre
Channel ports and dual 20 Gbps Thunderbolt 2 ports configurations, the
ARC-4607T2 is a best solution for hooking up to a high-speed Fibre channel SAN
network to achieve high-performance storage solution for 4K video workflows.
The ARC-4607T2 adapter brings the fastest available connections to Fibre
Channel SAN on any computer, and workstation with Thunderbolt 2 interface.
ARC-4607T2 adapter provides a blazing-fast storage connectivity solution with
enhanced reliability and performance to support any application and tiered
storage solution. ARC-4607T2 16Gbps dual channels expansion adapter is ideal for
large capacity external storage RAID and FC switch.
Specifications
- Enables Fibre Channel connectivity on systems with a Thunderbolt 2 port.
- Dual Fibre Channel Ports.
- 16 Gigabits per second data transfer rates.
- 3200 MB/sec maximum full-duplex throughput per channel.
- Supports all FC topologies: direct fabric, arbitratedloop and
point-to-point.
- Dual 20 Gbps Thunderbolt 2 ports with DisplayPort and device daisy-chain
support.
- Auto Negotiation to 16Gb, 8Gb and 4Gb devices.
- External LEDs for link and access status for each channel.
- Thunderbolt cable included.
- Two pluggable 16-Gb optical LC SFP+ modules (optional).
- Thunderbolt certified for Mac.
|
Form
Factor |
Mini
Box |
|
Host
Connection |
Two 20
Gb/s |
|
Thunderbolt Technology
Ports |
|
External
Ports |
2 x 16Gbps Fibre
Channel Ports |
|
OS
Support |
Mac OS X 10.8.5, 10.9
(Mavericks) and later & Windows 7/8 |
|
Enclosure
Management |
Thunderbolt
Port |
|
Cooling
Fan |
1 * noiseless cooling
fan |
|
Operating
Temperature |
0 ~
35C |
|
Operation
Humidity |
5% ~ 95 %,
Non-condensing |
|
Power
Supply/In/out |
65W / 100-240V
AC |
|
Dimension (W x
H x D) |
4.97 x 2.13 x 6.35 in
(150 x 64.4 x 191.7 mm) |
|
Weight (W/O
Drives) |
2.64 lbs /
1.2Kg |
