Essentials |
|
|
Product
Collection |
2nd Generation Intel
Xeon Scalable Processors |
|
Code
Name |
Products formerly
Cascade Lake |
|
Vertical
Segment |
Server |
|
Processor
Number |
5220R |
|
Status |
Launched |
|
Launch
Date |
Q1'20 |
|
Lithography |
14
nm |
|
Performance
Specifications |
|
|
# of
Cores |
24 |
|
# of
Threads |
48 |
|
Processor Base
Frequency |
2.20
GHz |
|
Max Turbo
Frequency |
4.00
GHz |
|
Cache |
35.75
MB |
|
# of UPI
Links |
2 |
|
TDP |
150
W |
|
Memory
Specifications |
|
|
Max Memory Size
(dependent on memory type) |
1
TB |
|
Memory
Types |
DDR4-2667 |
|
Maximum Memory
Speed |
2667
MHz |
|
Max # of Memory
Channels |
6 |
|
ECC Memory Supported
|
Yes |
|
Intel Optane DC
Persistent Memory Supported |
Yes |
|
Expansion
Options |
|
|
Scalability |
2S |
|
PCI Express
Revision |
3 |
|
Max # of PCI Express
Lanes |
48 |
|
Package
Specifications |
|
|
Sockets
Supported |
FCLGA3647 |
|
TCASE |
86C |
|
Package
Size |
76.0mm x
56.5mm |
|
Advanced
Technologies |
|
|
Intel Deep Learning
Boost (Intel DL Boost) |
Yes |
|
Intel Speed Select
Technology - Performance Profile |
No |
|
Intel Speed Select
Technology - Base Frequency |
No |
|
Intel Resource Director
Technology (Intel RDT) |
Yes |
|
Intel Speed Shift
Technology |
Yes |
|
Intel Turbo Boost Max
Technology 3.0 |
No |
|
Intel Turbo Boost
Technology |
2 |
|
Intel vPro Platform
Eligibility |
Yes |
|
Intel Hyper-Threading
Technology |
Yes |
|
Intel Virtualization
Technology (VT-x) |
Yes |
|
Intel Virtualization
Technology for Directed I/O (VT-d) |
Yes |
|
Intel VT-x with
Extended Page Tables (EPT) |
Yes |
|
Intel Transactional
Synchronization Extensions |
Yes |
|
Intel 64
|
Yes |
|
Instruction Set
Extensions |
Intel SSE4.2, Intel
AVX, Intel AVX2, Intel AVX-512 |
|
# of AVX-512 FMA
Units |
1 |
|
Enhanced Intel
SpeedStep Technology |
Yes |
|
Intel Volume Management
Device (VMD) |
Yes |
|
Security &
Reliability |
|
|
Intel AES New
Instructions |
Yes |
|
Intel Trusted Execution
Technology |
Yes |
|
Execute Disable Bit
|
Yes |
|
Intel Run Sure
Technology |
Yes |
|
Mode-based Execute
Control (MBE) |
Yes |
