All stock codes associated to this product
C31CH94212, 5227596
Featuring a sleek, modern design, the compact TM-m50 POS thermal
receipt printer meets the needs of businesses both now and in the
future. It can be dynamically shared by tablets, smartphones and PC-POS
or cloud POS systems.
The TM-m50 provides similar capabilities to a traditional POS printer
including USB connectivity and 180dpi. High volume POS customers will
benefit from fast print speeds of up to 350mm/s, and be confident that
the printer is supported by Epsons proven quality and reliability.
KEY FEATURES and BENEFITS
Sleek, compact and stylish design 3" thermal receipt printer supports traditional, cloud based and mPOS/tablet POS systems
- Connect to multiple devices
printer can be dynamically shared by legacy POS terminals, tablets and
mobile devices, as well as cloud servers and POS peripherals
- Triple-interface connectivity to help future-proof growing businesses maximum flexibility with built-in USB, Ethernet plus options for wireless technologies
- Online ordering ready Server Direct Print technology enables the printer to retrieve data from the Internet1
- Fast, reliable receipt printing speeds up to 350 mm/sec; printhead life of 200 km, auto cutter life of 2.2 million cuts
- Smart connectivity share data using a single USB cable (cable not included); charge smartphones and tablets2 3
- USB-Network-Tethering provides network connectivity from the printer to a tablet
Reliable and easy to use
Epson is a market leader in POS printing with a heritage of producing
high-quality and reliable systems. The TM-m50 is a highly intuitive
out-of-the-box solution that features: fast print speeds of up to
350mm/s, enhanced printhead and auto-cutter, and flexible drop-in paper
loading (front or top).
Adaptable
Quickly and easily customise receipts with logos and promotional
messages. Advance graphics and barcodes using high-quality, multiple
greyscale printing are also fast and simple to produce.
The TM-m50 is a feature packed, high performance solution with the
legacy features required to allow customers seamless integration into
their current systems.
Paper saving
Using backward paper feeding, or printing the logo when the receipt is
cut, can shorten receipt lengths reducing paper costs and consumption by
up to 30%.
Connectable
A single printer can be dynamically shared in mixed POS environments combining PC and Tablet solutions
Direct printing from web browsers
Epson's innovative ePOS-Print technology means the TM-m50 can quickly,
easily and seamlessly integrate with any PC, tablet, laptop or mobile
device via a Wi-Fi or Bluetooth interface. Whether the device is running
iOS, Android, Windows CE or Windows mobile, direct printing from the
web browser becomes possible without the need to install or update any
other drivers.
Easy pairing with mobile devices
NFC connectivity (Near Field Communication), means the TM-m50 can be
easily paired with tablets and smartphones. Simply bring the devices
close together to make the connection. For added convenience and
flexibility, pairing by QR code is also possible.
Simple set-up using Wi-Fi
The 'Easy Setting Functionality' on the TM-m50 creates an access point
for connecting smart devices. Once implemented, both devices can be
easily set-up and configured on a wireless network for prompt use.
Optional customer display DM-D30
Designed to match the dimensions and colours of the TM-m50 printer, the
DM-D30 customer display retains a stylish, integrated look and feel when
in use. This adaptable option can be connected to the printer via the
USB A port and, if a Wi-Fi dongle is required on the TM-m30, this can be
invisibly connected behind the DM-D30.
Optional wall mounting bracket
Mount the printer quickly and securely to any wall or vertical surface with the optional wall mounting bracket. By simply swapping just two printer covers, the TM-m50 converts from a horizontal to a vertical solution, maximising space even in the smallest retail environments.
PRINTER |
PRINT METHOD |
Direct thermal line printing |
PRINT RESOLUTION |
180 dpi |
PRINT FONTS / COLUMN CAPACITY |
Font A: 12 x 24 42 cpl (default); Font B: 9 x 24 56 cpl,
Kanji Font A: 24 x 24 24 cpl;
Kanji Font B: 16 x 16, 32 cpl (Korean) |
CHARACTER SIZE |
Font A: 1.41 x 3.39 mm;
Font B: 0.99 x 3.39 mm;
Kanji Font A: 3.39 x 3.39 mm;
Kanji Font B: 2.26 x 2.26 mm |
CHARACTER SET |
95 Alphanumeric
18 International
128x43 Graphic
Japanese (11,233 characters of JIS X0213:2004, 1 special character)
Simplified Chinese (28,553 characters of GB18030-2000)
Traditional Chinese (13,535 characters of Big5)
Korean (8,366 characters of KSC5601) |
PRINT SPEED |
Max. 350mm/sec |
CONNECTIVITY |
Built-in USB, built-in Ethernet(10/100Base-T/TX)
– Bluetooth 3.0+EDR
– Wireless (by optional USB wireless dongle) OT-WL06 (802.11 a/b/g/n/ac,2.4 GHz/5 GHz)
– Printer Discovery NFC (Near Field Communication)
– Simple AP (wireless network) |
PAPER SPECIFICATION |
DIMENSIONS |
80 mm: 79.5 ± 0.5 x 83 mm
3.13" ± 0.02" (width) x 3.27" (roll diameter)
58 mm: 57.5 ± 0.5 x 83 mm
2.26" ± 0.02" (width) x 3.27" (roll diameter) |
PAPER ROLL |
Drop in |
SENSORS |
Full end sensor |
POWER SPECIFICATION |
POWER CONSUMPTION |
Approx. 16.7W (operating)
Approx. 0.41W (standby) |
POWER |
100 – 230V AC, 50 to 60 Hz |
POWER SUPPLY |
AC Adaptor C |
RELIABILITY |
MTBF |
360,000 hours |
MCBF |
70 million lines |
AUTOCUTTER |
2.2 million cuts |
PRINTER OPTIONS |
COLOUR |
Epson Black, Epson Ultra White |
EMI STANDARD |
AS/NZS CISPR22 Class A, AS/NZS 4268 |
OVERALL DIMENSIONS |
WEIGHT |
WHAT'S IN THE BOX |
