CPU |
AMD
Ryzen Embedded V1500B 4-core/8-thread 2.2 GHz
processor |
|
CPU
Architecture |
64-bit
x86 |
|
Graphic
Processors |
Optional
via a PCIe adapter |
|
Floating
Point Unit |
Yes |
|
Encryption
Engine |
Yes (AES-NI) |
|
Hardware-accelerated
Transcoding |
Optional
via a PCIe adapter |
|
System
Memory |
8
GB SO-DIMM DDR4 (1 x 8 GB) |
|
Maximum
Memory |
64
GB (2 x 32 GB) |
|
Memory
Slot |
2
x SO-DIMM DDR4 |
|
Support
ECC memory |
|
For
dual-DIMM configurations, you must use a pair of identical DDR4
modules. |
|
Flash
Memory |
5GB
(Dual boot OS protection) |
|
Drive
Bay |
4
x 3.5-inch SATA 6Gb/s, 3Gb/s |
|
Drive
Compatibility |
3.5-inch
SATA hard disk drives |
|
2.5-inch
SATA hard disk drives |
|
2.5-inch
SATA solid state drives |
|
Hot-swappable |
The
following are not hot-swappable: M.2 SSDs, SSD cache drives, SSDs using
PCIe expansion slots. |
|
M.2
Slot |
2
x M.2 2280 PCIe Gen3 x1 slots |
|
The
M.2 SSD is not included as standard. |
|
M.2
SSD operations can easily generate excessive heat. It is recommended to
install a heatsink (from QNAP or a third-party provider) on the
M.2 SSD. |
|
SSD
Cache Acceleration Support |
Yes |
|
2.5
Gigabit Ethernet Port (2.5G/1G/100M) |
2 |
|
5
Gigabit Ethernet Port (5G/2.5G/1G/100M) |
Optional
via a PCIe adapter |
|
10
Gigabit Ethernet Port |
Optional
via a PCIe adapter |
|
Wake
on LAN (WOL) |
Yes |
|
Jumbo
Frame |
Yes |
|
PCIe
Slot |
2 |
|
Slot
1: PCIe Gen 3 x4 |
|
Slot
2: PCIe Gen 3 x4 |
|
USB
3.2 Gen 2 (10Gbps) Port |
3
x Type-A USB 3.2 Gen 2 5V/1A 10Gbps |
|
1
x Type-C USB 3.2 Gen 1 5V/1A 5Gbps |
|
IR
Sensor |
(QNAP
RM-IR004) |
|
HDMI
Output |
Optional
via a PCIe adapter |
|
Form
Factor |
Tower |
|
LED
Indicators |
Status/Power,
USB, LAN, Drive 1-4, M.2 SSD 1-2 |
|
Buttons |
Power,
Reset, USB Auto Copy |
|
Dimensions
(HxWxD) |
188.2
x 199.3 x 280.8 mm |
|
Weight
(Net) |
5.03
kg |
|
Weight
(Gross) |
6.04
kg |
|
Operating
temperature |
0
- 40 C (32F - 104F) |
|
Storage
Temperature |
-20
- 70C (-4F - 158F) |
|
Relative
Humidity |
5-95%
RH non-condensing, wet bulb: 27C (80.6F) |
|
Power
Supply Unit |
250W,
100-240V AC, 50-60Hz, 3.5A |
|
Power
Consumption: HDD Sleep Mode |
19.576
W |
|
Power
Consumption: Operating Mode, Typical |
29.792
W |
|
Tested
with drives fully populated. |
|
Fan |
System
fan: 1 x 120mm |
|
CPU
fan: 1 x 60mm |
|
Sound
Level |
21.4
db(A) |
|
System
Warning |
Buzzer |
|
Max.
Number of Concurrent Connections (CIFS) - with Max.
Memory |
2000 |
