All stock codes associated to this product
952000091, 952-000091, 5321220, 952000091(SCHED), 952-000091(SCHED)
Logitech Tap Room Scheduler for Meeting Rooms - Touch Screen - Graphite
Overview
Purpose-built scheduling panel for meeting rooms
RIGHT PLACE, RIGHT TIME
Tap Scheduler makes it easy to see meeting details and reserve a room for ad
hoc or future meetings. Easily deploy as a purpose-built scheduling panel for
leading room scheduling solutions to help workers find and claim the right
space.
GREEN MEANS GO
Quickly find an open room through colored LED lights that show availability
at a distance.
CLEAN AND EASY INSTALL
Included mounts and clean cabling help ensure a tidy and professional
setup.
PURPOSE-BUILT AS A SCHEDULING PANEL
Tap Scheduler was designed for easy viewing and usability, with a spacious
screen and a sleek, unobtrusive profile. Count on Tap Scheduler for reliable
performance with durable components that are built to last.
MAKE THE MOST OF YOUR SPACE
Easily add Tap Scheduler to a variety of meeting rooms, from phone booths to
video rooms to hangout nooks, helping employees quickly find the right meeting
location. Simple installations and an intuitive user experience drive fast
deployment and adoption.
PICK YOUR PLATFORM
Enable a seamless meeting experience through Tap Scheduler and Logitechs
suite of room solutions, which integrate with Microsoft Teams, Zoom Rooms, and
other service providers to raise the bar on collaboration.
SIMPLE TO MANAGE WITH LOGITECH SYNC
With Logitech Sync, you can monitor and manage Tap Scheduler along with your
other meeting room devices from one single platform.
UP TO THREE YEAR WARRANTY
Ensure peace of mind with an extended warranty for Tap Scheduler, adding one
additional year to the standard two-year limited hardware warranty.
Specifications
DIMENSIONS
Device-only
- Height: 165 mm
- Width: 246.2 mm
- Depth: 28.5 mm
- Weight: 0.7 kg
Surface-mounted
- Height: 165 mm
- Width: 246.2 mm
- Depth: 31.4 mm
Mullion-mounted
- Height: 165 mm
- Width: 292.6 mm
- Depth: 44.5 mm
TECHNICAL SPECIFICATIONS
Screen
- Size: 10.1 diagonal
- IPS (In-Plane Switching)
- LCD Panel with LED Backlighting
- Resolution: 1280 x 800 resolution
- Touch: Capacitive, 10 points multi-touch
- Brightness: 400 nits
- Contrast: 1000:1
- Anti Fingerprint: Oleophobic coating
- Viewing angle: 85 degrees (U/D/L/R)
- Position angle: 0 degrees (flat on mounting surface)
GENERAL SPECIFICATIONS
- Integrated accelerometer
- Integrated ambient light sensor
- 100 mm x 100 mm VESA FDMI
- Cable exits: horizontal / vertical / center
COMPATIBILITY AND CERTIFICATIONS
- Logitech Tap Scheduler integrates with leading room scheduling solutions
as a
- Microsoft Teams Panel
- Zoom Rooms Scheduling Display
- Robin-Powered scheduling panel
- Meetio scheduling panel
- See www.logitech.com/support/tapscheduler-compatibility for the latest
certification and compatibility information.
- Logitech CollabOS platform
- Logitech Sync Remote Management
- Power and Cables
- Power over Ethernet (PoE), IEEE 802.3af Type 1, Class 3
device*
*Requires PoE enabled network or PoE Injector and ethernet cable (Not
included)
PORTS AND INTERFACES
- Ethernet: 10/100 Mbps
- WiFi: 802.11a/b/g/n/ac
- Bluetooth 5.0 (inactive, reserved for future use)
Environmental
- Operating Temperature: 0 to 40C
- Storage Temperature: -40 to 70C
- Humidity: 10-95%
Security
- Full Disk Encryption: AES-128
- Data Encryption: Symmetric Keys, PKI
- Device Identity: Protected by device attestation
- Key Protection: Arm TrustZone
PACKAGE CONTENTS
- Logitech Tap Scheduler
- Multi-surface mount (glass/drywall)
- Corner mount accessory
- Mullion mount
- Mounting hardware
- Documentation
WARRANTY INFORMATION
- Ensure peace of mind with an extended warranty for Tap Scheduler, adding
one additional year to the standard two-year limited hardware
warranty.
- Contact your reseller for
availability.
