Essentials |
|
Product
Collection |
12th
Generation Intel Core i5 Processors |
Code
Name |
Products
formerly Alder Lake |
Vertical
Segment |
Desktop |
Processor
Number |
i5-12600KF |
Status |
Launched |
Launch
Date |
Q4'21 |
Lithography |
Intel
7 |
Use
Conditions |
PC/Client/Tablet |
CPU
Specifications |
|
Total
Cores |
10 |
#
of Performance-cores |
6 |
#
of Efficient-cores |
4 |
Total
Threads |
16 |
Max
Turbo Frequency |
4.90
GHz |
Performance-core
Max Turbo Frequency |
4.90
GHz |
Efficient-core
Max Turbo Frequency |
3.60
GHz |
Performance-core
Base Frequency |
3.70
GHz |
Efficient-core
Base Frequency |
2.80
GHz |
Cache |
20
MB Intel Smart Cache |
Total
L2 Cache |
9.5
MB |
Processor
Base Power |
125
W |
Maximum
Turbo Power |
150
W |
Memory
Specifications |
|
Max
Memory Size (dependent on memory type) |
128
GB |
Memory
Types |
Up
to DDR5 4800 MT/s Up to DDR4 3200 MT/s |
Max
# of Memory Channels |
2 |
Max
Memory Bandwidth |
76.8
GB/s |
Expansion
Options |
|
Direct
Media Interface (DMI) Revision |
4 |
Max
# of DMI Lanes |
8 |
Scalability |
1S
Only |
PCI
Express Revision |
5.0
and 4.0 |
PCI
Express Configurations |
Up
to 1x16+4 | 2x8+4 |
Max
# of PCI Express Lanes |
20 |
Package
Specifications |
|
Sockets
Supported |
FCLGA1700 |
Max
CPU Configuration |
1 |
Thermal
Solution Specification |
PCG
2020A |
TJUNCTION |
100C |
Package
Size |
45.0
mm x 37.5 mm |
Advanced
Technologies |
|
Intel
Gaussian &ural Accelerator |
3 |
Intel
Thread Director |
Yes |
Intel
Deep Learning Boost (Intel DL Boost) |
Yes |
Intel
Optane Memory Supported |
Yes |
Intel
Speed Shift Technology |
Yes |
Intel
Turbo Boost Max Technology 3.0 |
No |
Intel
Turbo Boost Technology |
2 |
Intel
Hyper-Threading Technology |
Yes |
Intel
Virtualization Technology (VT-x) |
Yes |
Intel
Virtualization Technology for Directed I/O (VT-d)
|
Yes |
Intel
VT-x with Extended Page Tables (EPT) |
Yes |
Intel
64 |
Yes |
Instruction
Set |
64-bit |
Instruction
Set Extensions |
Intel
SSE4.1 | Intel SSE4.2 | Intel AVX2 |
Idle
States |
Yes |
Enhanced
Intel SpeedStep Technology |
Yes |
Thermal
Monitoring Technologies |
Yes |
Intel
Volume Management Device (VMD) |
Yes |
Security
&liability |
|
Intel
AES New Instructions |
Yes |
Secure
Key |
Yes |
Intel
OS Guard |
Yes |
Execute
Disable Bit |
Yes |
Intel
Boot Guard |
Yes |
Mode-based
Execute Control (MBE) |
Yes |
Intel
Control-Flow Enforcement Technology |
Yes |
