Essentials |
|
|
Product
Collection |
3rd
Generation Intel Xeon Scalable Processors |
|
Code
Name |
Products
formerly Ice Lake |
|
Vertical
Segment |
Server |
|
Processor
Number |
6336Y |
|
Status |
Launched |
|
Launch
Date |
Q2'21 |
|
Lithography |
10
nm |
|
CPU
Specifications |
|
|
Total
Cores |
24 |
|
Total
Threads |
48 |
|
Max
Turbo Frequency |
3.60
GHz |
|
Processor
Base Frequency |
2.40
GHz |
|
Cache |
36
MB |
|
Intel
UPI Speed |
11.2
GT/s |
|
#
of UPI Links |
3 |
|
TDP |
185
W |
|
Memory
Specifications |
|
|
Max
Memory Size (dependent on memory type) |
6
TB |
|
Memory
Types |
DDR4-3200 |
|
Maximum
Memory Speed |
3200
MHz |
|
Max
# of Memory Channels |
8 |
|
ECC
Memory Supported
|
Yes |
|
Intel
Optane Persistent Memory Supported |
Yes |
|
Expansion
Options |
|
|
Scalability |
2S |
|
PCI
Express Revision |
4 |
|
Max
# of PCI Express Lanes |
64 |
|
Package
Specifications |
|
|
Sockets
Supported |
FCLGA4189 |
|
TCASE |
80C |
|
Package
Size |
77.5mm
x 56.5mm |
|
Advanced
Technologies |
|
|
Intel
Speed Select Technology Core Power |
Yes |
|
Intel
Speed Select Technology Turbo Frequency |
Yes |
|
Intel
Deep Learning Boost (Intel DL Boost) |
Yes |
|
Intel
Speed Select Technology - Performance Profile |
Yes |
|
Intel
Speed Select Technology - Base Frequency |
Yes |
|
Intel
Resource Director Technology (Intel RDT) |
Yes |
|
Intel
Speed Shift Technology |
Yes |
|
Intel
Turbo Boost Technology |
2 |
|
Intel
Hyper-Threading Technology |
Yes |
|
Intel
Virtualization Technology (VT-x) |
Yes |
|
Intel
Virtualization Technology for Directed I/O (VT-d)
|
Yes |
|
Intel
VT-x with Extended Page Tables (EPT) |
Yes |
|
Intel
Transactional Synchronization Extensions |
Yes |
|
Intel
64 |
Yes |
|
Instruction
Set Extensions |
Intel
SSE4.2 | Intel AVX | Intel AVX2 | Intel
AVX-512 |
|
#
of AVX-512 FMA Units |
2 |
|
Intel
Volume Management Device (VMD) |
Yes |
|
Security
& Reliability |
|
|
Intel
AES New Instructions |
Yes |
|
Intel
Software Guard Extensions (Intel SGX) |
Yes
with Intel SPS |
|
Intel
Trusted Execution Technology |
Yes |
|
Execute
Disable Bit |
Yes |
|
Intel
Run Sure Technology |
Yes |
|
Mode-based
Execute Control (MBE) |
Yes |
|
Intel
Total Memory Encryption |
Yes |
|
Intel
Platform Firmware Resilience Support |
Yes |
|
Maximum
Enclave Page Cache (EPC) Size for Intel SGX |
64
GB |
|
Intel
Crypto Acceleration |
Yes |
