P/N |
GGD-EDL-BKEINX-01 |
MOTOR |
Voltage: |
Input
110-240V, 50/60Hz, 4A |
Output
Max.32V, Max.10A |
Speed:
156 RPM (+/- 5%) |
Motor:
3 |
Duty
cycle: 1 min ON / 9 min OFF |
Torque:
7.2 Nm |
Safety
certifications: CE / UL 508 |
Controller: |
Standard
2-Button and Memory 4-Button |
Anti-collision
safety sensor: |
Allows
the desk to safely stop when colliding with unwanted objects during
operation |
Travel
speed: 33.3mm per second loaded |
Noise
level: 52 db. in motion |
FRAME |
Size: |
Main
desk: |
160cm
(L)x 80cm (W) |
62.99"
(L)x 31.49" (W) |
Side
desk: |
80cm
(L)x 60cm (W) |
31.49"
(L)x 23.62" (W) |
Height
range: 70cm ~ 110cm (27.5" ~ 43.3") |
Foot
size: |
Long: |
67.2cm
(L)x 10cm (W)x 5cm (H) |
26.46"
(L)x 3.94" (W)x 1.97" (H) |
Short: |
63.4cm
(L)x 10cm (W)x 5cm (H) |
24.96"
(L)x 3.94" (W)x 1.97" (H) |
Max
Load: 150 kg / 330 lb. |
Material:
Steel-constructed frame for max stability |
Cable
management: Yes |
DESKTOP |
Size: |
Main
Desk |
160cm
(L) x 80cm (W) |
62.99"
(L) x 31.49" (W) |
Side
Desk |
80cm
(L) x 60cm (W) |
31.49"
(L) x 23.62" (W) |
Desktop
thickness: 3cm / 1.18" |
Max
desktop support: |
Up
to super tower chassis (dimensions: 27.2" x 13.5" x
25.4") |
Materials: |
MDF
desktop - premium material with anti-scratch / high-pressure Laminate
P2 |
Scratch
coating: Yes |
Table
feet material: Iron |
OTHERS |
Top
finish: Black |
Frame
color: Black |
Included
extra-large black mouse pad: |
Full
Surface RGB Mouse Pad (Main Desk) |
160cm
(L) x 80cm (W) x 0.4cm (H) |
62.99"
(L) x 31.49" (W) x 0.157" (H) |
Full
Surface non-RGB Mouse Pad (Side Desk) |
80cm
(L) x 60cm (W) x 0.4cm (H) |
31.49"
(L) x 23.62" (W) x 0.157" (H) |
Shipping
dimensions: |
93.5cm
(L)x 93.5cm (W)x 42cm (H) |
36.81"
(L)x 36.81" (W)x 16.53" (H) |
G.W.:91.8kg/
202.38lb |
N.W.:76.9kg/169.53lb |
Warranty: |
Two-year
warranty (desktop, motor, frame, and
controller) |
