Product
Number |
1VD88A |
|
Functions |
Print |
|
Print
Technology |
HP
Thermal Inkjet |
|
Print
Languages |
Adobe
PostScript 3, Adobe PDF 1.7 ext 3, HP-GL/2, TIFF, JPEG, URF, CALS
G4 |
|
Model
Size |
1118
mm |
|
Guaranteed
Minimum Line Width |
0.06
mm (ISO/IEC 13660:2001(E))[3] |
|
Guaranteed
Minimum Line Width Footnote |
Measured
on HP Matte Film |
|
Theoretical
Minimum Line Width |
0.02
mm (PDF addressable @ 1200 dpi) |
|
Line
Accuracy |
0.1%[2] |
|
Line
Accuracy Note |
0.1%
of the specified vector length or 0.2 mm (whichever greater) at 23C
(73F), 50-60% relative humidity, on A0/E HP Matte Film in Best or
Normal mode with Original HP inks |
|
Print
Speed |
116
A1/hr, 26 sec/A1[1] |
|
Print
Speed Line Drawing (Economode, A1 Plain
Paper) |
116
pages per hour[1] |
|
Print
Time Black And White Line Drawing (Draft, Metric A1 Plain
Paper) |
33
sec/page |
|
Print
Time Line Drawing (Economode, A1 Plain Paper) |
26
sec/page[1] |
|
Maximum
Optical Density (Black) |
2.15
maximum black optical density (6 L*min) |
|
Print
Quality Color (Best) |
Up
to 2400 x 1200 optimized dpi |
|
Maximum
Optical Density Footnote (Black) |
With
HP Premium Instant Dry Photo Gloss media with Original HP
inks |
|
Non-Printable
Area (Cut-Sheet) |
3
x 17 x 3 x 3 mm |
|
Non-Printable
Area (Roll Media) |
3
x 3 x 3 x 3 mm |
|
Printing
Path |
Direct
printing from USB flash drive, email printing, HP driver for Windows, HP
Print Service for Android, Apple AirPrint for MacOS and for iOS, HP Print
for Chrome OS, HP Click, HP Smart App for iOS and
Android |
|
Printer
Drivers Included |
Raster
drivers for Windows and macOS; PostScript and PDF Windows drivers and
macOS PostScript driver |
|
Internal
Storage |
500
GB self-encrypting |
|
Memory |
128
GB (virtual)[4] |
|
Memory
Note |
Based
on 4 GB DDR3 RAM |
|
Connectivity,
Standard |
Ethernet,
Fast Ethernet, Gigabit Ethernet, 10/100/1000Base-T Ethernet (802.3,
802.3u, 802.3ab); USB Type-A host port |
|
Connectivity,
Optional |
HP
USB 3.0 to Gigabit LAN Adapter |
|
Network
Ready |
Standard |
|
HP
EPrint Capability |
Yes |
|
Mobile
Printing Capability |
Direct
print from mobile apps on iOS, Android and Chrome OS; email printing with
HP ePrint and HP Smart app for iOS and Android |
|
Power
Consumption |
<
100 W (printing); < 24 W (ready); < 0.3 W (< 6.5 W with embedded
Digital Front End) (sleep); 0.1 W (off) |
|
Power |
Input
voltage (auto ranging) 100-240 V (10%), 50/60 Hz (3 Hz), 2 A
max |
|
Number
Of Print Cartridges |
6
(cyan, magenta, yellow, photo black, matte black,
gray) |
|
Print
Cartridge Volume Delivered |
Cyan,
magenta, yellow, photo black, matte black, gray (300 ml); Cyan, magenta,
yellow, photo black, matte black, gray (130
ml) |
|
Print
Heads |
3
universal printheads, 2 colors each |
|
Print
Head Nozzles |
2112
each color |
|
Ink
Drop |
6
pl |
|
Ink
Types |
Dye-based
(C, M, Y, PK, G); pigment-based (MK) |
|
Finished
Output Handling |
Sheet
feed, two automatic roll feeds, automatic roll-switching, media bin,
automatic horizontal cutter |
|
Media
Types |
Bond
and coated paper (bond, coated, heavyweight coated, super heavyweight plus
matte), technical paper (natural tracing, translucent bond), film (clear,
matte), photographic paper (satin, gloss, semi-gloss, matte, high-gloss),
backlit, self-adhesive (polypropylene, vinyl) |
|
Media
Sizes Supported |
A4,
A3, A2, A1, A0 |
|
Media
Sizes, Custom |
210
x 279 to 1118 x 1676 mm |
|
Media
Sizes Standard (Metric Rolls) |
279
to 1118-mm |
|
Media
Width, Maximum |
1118
mm |
|
Media
Weight, Recommended |
60
to 328 g/m |
|
Media
Thickness |
Up
to 31.5 mil |
|
Roll
External Diameter |
135
mm |
|
Roll
Maximum Input |
2 |
|
Roll
Maximum Weight |
11.9
kg |
|
Recommended
Media |
C6810A
HP Bright White Inkjet Paper (FSC certified) 914 mm x 91.4 m (36 in x 300
ft);C6569C HP Heavyweight Coated Paper 1067 mm x 30.5 m (42 in x 100
ft);Q6581A HP Universal Instant-dry Satin Photo Paper (FSC certified) 1067
mm x 30.5 m (42 in x 100 ft);Q1406B HP Universal Coated Paper (FSC
certified) 1067 mm x 45.7 m (42 in x 150 ft) |
|
Supported
Primary Applications |
Line
drawings; Maps; Orthophotos; Presentations;
Renderings |
|
Operating
Temperature Range |
5
to 40C |
|
Storage
Temperature Range |
-25
to 55C |
|
Operating
Humidity Range |
20
to 80% RH |
|
Non-Operating
Humidity Range |
0
to 90% RH |
|
Acoustic
Power Emissions |
6.1
B(A) |
|
Acoustic
Power Emissions (Standby) |
5.0
B(A) |
|
Acoustic
Power Emissions (Sleep) |
<
3.1 B(A) |
|
Acoustic
Pressure Emissions |
45
dB(A) |
|
Acoustic
Pressure Emissions (Standby) |
32
dB(A) |
|
Acoustic
Pressure Emissions (Sleep) |
<
15 dB(A) |
|
Dimensions
Without Stand (W X D X H) |
1802
x 695 x 998 mm |
|
Package
Dimensions (W X D X H) |
1955
x 770 x 710 mm |
|
Weight |
74
kg |
|
Package
Weight |
128
kg |
|
What's
In The Box |
HP
DesignJet T1700 Printer, printheads, ink cartridges, printer stand,
spindles (x2), setup poster, introductory information, warranty, power
cords, label kits |
|
Software
Included |
HP
Click, HP Utility for Mac and Windows, HP WebJet Admin, HP Embedded Web
Server, HP JetAdvantage Security Manager, HP Partner Link, HP
MPS |
|
Warranty |
1
Year Limited Warranty (Next Business Day
On-Site) |
|
ENERGY
STAR Certified |
Yes |
|
Electromagnetic
Emission Standard |
Compliant
with Class B requirements, including: USA (FCC rules), Canada (ICES), EU
(EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan
(VCCI), Korea (KCC), South Africa (SABS) |
|
Environmental
Certifications |
ENERGY
STAR; WEEE; RoHS (EU, China, Korea, India); REACH; EPEAT
Silver |
