Essentials |
|
|
Product
Collection |
Intel
Xeon W Processor |
|
Code
Name |
Products
formerly Comet Lake |
|
Vertical
Segment |
Workstation |
|
Processor
Number |
W-1270P |
|
Status |
Launched |
|
Launch
Date |
Q2'20 |
|
Lithography |
14
nm |
|
Included
Items |
This
product is available in tray and box. For
boxed product | a thermal solution is not
included |
|
Use
Conditions |
Workstation |
|
CPU
Specifications |
|
|
Total
Cores |
8 |
|
Total
Threads |
16 |
|
Max
Turbo Frequency |
5.10
GHz |
|
Intel
Turbo Boost Max Technology 3.0 Frequency |
5.10
GHz |
|
Intel
Turbo Boost Technology 2.0 Frequency |
5.00
GHz |
|
Processor
Base Frequency |
3.80
GHz |
|
Cache |
16
MB Intel Smart Cache |
|
Bus
Speed |
8
GT/s |
|
TDP |
125
W |
|
Configurable
TDP-down Base Frequency |
3.50
GHz |
|
Configurable
TDP-down |
95
W |
|
Memory
Specifications |
|
|
Max
Memory Size (dependent on memory type) |
128
GB |
|
Memory
Types |
DDR4-2933 |
|
Max
# of Memory Channels |
2 |
|
Max
Memory Bandwidth |
45.8
GB/s |
|
ECC
Memory Supported
|
Yes |
|
Processor
Graphics |
|
|
Processor
Graphics |
Intel
UHD Graphics P630 |
|
Graphics
Base Frequency |
350
MHz |
|
Graphics
Max Dynamic Frequency |
1.20
GHz |
|
Graphics
Video Max Memory |
64
GB |
|
4K
Support |
Yes
| at 60Hz |
|
Max
Resolution (HDMI) |
4096x2160@30Hz |
|
Max
Resolution (DP) |
4096x2304@60Hz |
|
Max
Resolution (eDP - Integrated Flat Panel) |
4096x2304@60Hz |
|
DirectX*
Support |
12 |
|
OpenGL*
Support |
4.5 |
|
Intel
Quick Sync Video |
Yes |
|
Intel
InTru 3D Technology |
Yes |
|
Intel
Clear Video HD Technology |
Yes |
|
Intel
Clear Video Technology |
Yes |
|
#
of Displays Supported |
3 |
|
Device
ID |
0x9BC6 |
|
Expansion
Options |
|
|
Scalability |
1S
Only |
|
PCI
Express Revision |
3 |
|
PCI
Express Configurations |
Up
to 1x16 | 2x8 | 1x8+2x4 |
|
Max
# of PCI Express Lanes |
16 |
|
Package
Specifications |
|
|
Sockets
Supported |
FCLGA1200 |
|
Max
CPU Configuration |
1 |
|
Thermal
Solution Specification |
PCG
2015D |
|
TJUNCTION |
100C |
|
Package
Size |
37.5mm
x 37.5mm |
|
Advanced
Technologies |
|
|
Intel
Optane Memory Supported |
Yes |
|
Intel
Thermal Velocity Boost |
No |
|
Intel
Turbo Boost Max Technology 3.0 |
Yes |
|
Intel
Turbo Boost Technology |
2 |
|
Intel
Hyper-Threading Technology |
Yes |
|
Intel
Transactional Synchronization Extensions |
No |
|
Intel
64 |
Yes |
|
Instruction
Set |
64-bit |
|
Instruction
Set Extensions |
Intel
SSE4.1 | Intel SSE4.2 | Intel AVX2 |
|
Idle
States |
Yes |
|
Enhanced
Intel SpeedStep Technology |
Yes |
|
Thermal
Monitoring Technologies |
Yes |
|
Intel
Identity Protection Technology |
Yes |
|
Security
& Reliability |
|
|
Intel
vPro Platform Eligibility |
Yes |
|
Intel
AES New Instructions |
Yes |
|
Secure
Key |
Yes |
|
Intel
Software Guard Extensions (Intel SGX) |
Yes
with Intel ME |
|
Intel
OS Guard |
Yes |
|
Intel
Trusted Execution Technology |
Yes |
|
Execute
Disable Bit |
Yes |
|
Intel
Boot Guard |
Yes |
|
Intel
Virtualization Technology (VT-x) |
Yes |
|
Intel
Virtualization Technology for Directed I/O (VT-d)
|
Yes |
|
Intel
VT-x with Extended Page Tables (EPT) |
Yes |
