Dimensions |
2.9
in. L x 2.1 in. W x 1.3 in. D |
|
74
mm L x 54 mm W x 33 mm D |
|
Weight |
Triggered,
with battery: 6.46 oz./183 g |
|
Triggerless,
with battery: 6.00 oz./170 g |
|
Power |
3350
mAh capacity; PowerPrecision+; |
|
Li-Ion
Battery Pack |
|
Optical
Resolution |
1280
x 960 pixels |
|
Roll |
360 |
|
Pitch
Angle |
60
from normal |
|
Skew
Tolerance: |
60
from normal |
|
Aiming
Element |
655nm
Laser |
|
Illumination
Element |
Two
(2) warm white light LEDs |
|
Field
of View |
SR:
Horizontal: 48, Vertical: 36.7 |
|
MR:
Horizontal: 31, Vertical: 23 |
|
Ambient
Light Immunity (from total darkness) |
Indoor:
450 ft. candles (4,845 lux) |
|
Outdoor
Triggered: 9,000 ft. candles (96,900 lux) |
|
Outdoor
Triggerless: 1,200 ft. candles (12,917 lux) |
|
Motion
Tolerance |
25
inch per second, typical |
|
Supported
1D Symbologies |
Code
39, Code 128, Code 93, Codebar/NW7, Code 11, MSI, UPC/EAN, I 2of 5, Korean
3 of 5, GSI DataBar, Base 32 (Italian Pharma) |
|
Supported
2D Symbologies |
PDF417,
Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR
Code, Micro QR, Chinese Sensible (Han Xin), Postal
Codes. |
|
Supported
OCR Symbologies |
OCR-A,
OCR-B, MICR E13B, US Currency |
|
Supported
Aiming Modes |
Class
2 Laser, cross hair with bright center for sunlight visibility; Pick List
mode configurable |
|
Interface |
Bluetooth:
Class I, v 4.0 with Bluetooth Low Energy (BLE) |
|
Supporting
Profiles: Serial Port Profile (SPP), Human Interface Device Profile (HID),
Service Discovery Application Profile (SDAP) |
|
NFC
Tag: Tap-to-Pair; used to simplify the pairing process. Pairing: by
reading terminal BT address as a barcode on the host Zebra
device. |
|
LED |
Line
of Sight (LOS) 2 RGB LEDs located at the back side of the device
(programmable) |
|
Radio
and battery capacity status 1 RGB LED located on the top side of the
device |
|
Beeper |
Up
to 85 dBA @ 10 cm from the back of the device beeper
port |
|
Restore
Key |
User
accessible for emergency warm boot and Bluetooth reconnect (after
disconnect timeout) |
|
Scan
Triggering |
Manual
or automatic via Proximity Sensor technology |
|
Operating
Temp. |
-22F
to +122F/-30C to +50C |
|
Storage
Temp. |
-40F
to +140F/-40C to +60C incl. battery |
|
-40F
to +158F/-40C to +70C excl. battery |
|
Humidity |
5%
to 95% non-condensing |
|
Drop
Rating |
Multiple
6 ft. /1.8 m drops to concrete over the operating temperature
range |
|
Tumble
Rating |
1,000
tumbles @ 0.5 m |
|
Sealing |
IEC
60529: IP65 |
|
Vibration |
Sine
5-2000Hz, 4g peak, 1 hour per axis; Random 20-2000Hz, 6g RMS or 0.04g2/Hz,
1 hour per axis |
|
Electrostatic
Discharge (ESD) |
+/-20kVdc
air discharge |
|
+/-10kVdc
contact discharge |
