All stock codes associated to this product
4Y37A09730, 5224809, SVL-4Y37A09730, SVL4Y37A09730, 0889488525034
| Ports & interfaces |
|---|
| Supported storage drive interfaces | SAS, Serial ATA |
| Host interface | PCI Express x8 |
| PCI Express slots version | 4.0 |
| Internal SAS ports | 16 |
| Performance |
|---|
| RAID levels | 0, 1, 5, 6, 10, 50, 60 |
| SSD support | Yes |
| Internal memory | 8000 MB |
| Chipset | Broadcom SAS3916 |
| S.M.A.R.T. support | Yes |
| Number of devices supported | 16 |
| Data transfer rate | 12 Gbit/s |
| Harmonized System (HS) code | 84733080 |
| JBOD function | Yes |
| Technical details |
|---|
| Harmonized System (HS) code | 84733080 |
| System requirements |
|---|
| Linux operating systems supported | Yes |
| Logistics data |
|---|
| Harmonized System (HS) code | 84733080 |
The ThinkSystem RAID 940 family of PCIe 4.0 12 Gbps SAS RAID controllers are high-performance RAID-on-chip (ROC) adapters for connectivity to drives internal to the server. These adapters support RAID levels 0, 1, 10, 5, 50, 6 and 60, and include an extensive list of RAS and management features. This product guide provides essential presales information to understand the ThinkSystem RAID 940-8i, 16i and 32i adapters and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the adapters and consider their use in IT solutions. Change History Changes in the March 9, 2021 update: - The adapters now support Tri-Mode, which allows U.3 NVMe drives to be connected - Features section - The server support tables are now automatically updated (change history may not be updated) - Server support section
Introduction The ThinkSystem RAID 940 family of PCIe 4.0 12 Gbps SAS RAID controllers are high-performance RAID-on-chip (ROC) server adapters for connectivity to drives internal to the server. These adapters support RAID levels 0, 1, 10, 5, 50, 6 and 60, and include an extensive list of RAS and management features.
