Technical details |
---|
Product type | Group video conferencing system |
Number of persons | 6 person(s) |
Product colour | Black |
Wall mountable | Yes |
Bluetooth | Yes |
Bluetooth version | 5.0 |
Video |
---|
HD type | 4K Ultra HD |
Digital zoom | 4x |
Video formats supported | H.239,H.264,H.265 |
Supported video modes | 720p,1080p,2160p |
Supported graphics resolutions | 800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 768 (WXGA),1600 x 1200 (UXGA),1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080),3840 x 2160 |
Maximum frame rate | 60 fps |
Audio |
---|
Voice codecs | G.711,G.719,G.722,G.722.1,G.722.1C,G.728,G.729A |
Built-in speaker(s) | Yes |
Audio formats supported | AAC-LD |
Ports & interfaces |
---|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
USB connector type | USB Type-A, USB Type-C |
HDMI ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
Network |
---|
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Wi-Fi | Yes |
Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
Security algorithms | 128-bit AES,256-bit AES,FIPS 140-2,SSL/TLS |
Camera |
---|
Field of view (FOV) angle | 120° |
Display |
---|
Display | LCD |
Display diagonal | 20.3 cm (8") |
Display resolution | 1280 x 800 pixels |
Touchscreen | Yes |
Microphone |
---|
Number of microphones | 4 |
Operational conditions |
---|
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 15 - 80% |
Heat dissipation | 65 BTU/h |
Power |
---|
AC input voltage | 120 - 230 V |
AC input frequency | 50/60 Hz |
Weight & dimensions |
---|
Width | 441.8 mm |
Depth | 61.6 mm |
Height | 62.5 mm |
Weight | 730 g |
