Scanning |
---|
Type | Fixed bar code reader |
Sensor type | Photo diode |
Linear (1D) barcodes supported | Code 39, U.P.C., UPC-A, Planet, UPC-E, POSTNET |
2D (matrix & stacked) barcodes supported | Composite Codes, Aztec Code, Data Matrix, PDF417, QR Code, MaxiCode |
Wavelength | 655 nm |
Scanner type | 1D/2D |
Light levels (direct sunlight) | 0 - 96900 lx |
Optical sensor resolution (W x H) | 752 x 480 pixels |
Ports & interfaces |
---|
Connectivity technology | Wired |
Standard interfaces | USB, RS-232 |
Performance |
---|
Product colour | Black |
International Protection (IP) code | IP54 |
Built-in processor | Yes |
Processor frequency | 624 MHz |
Light levels (direct sunlight) | 0 - 96900 lx |
Design |
---|
Product colour | Black |
Type | Fixed bar code reader |
International Protection (IP) code | IP54 |
Power |
---|
Power source type | USB, RS-232 |
Input voltage | 5 V |
Weight & dimensions |
---|
Width | 62 mm |
Depth | 58.4 mm |
Height | 29.2 mm |
Weight | 111 g |
Operational conditions |
---|
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | -20 - 50 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 85% |
Light levels (direct sunlight) | 0 - 96900 lx |
Technical details |
---|
Harmonized System (HS) code | 84716070 |
