All stock codes associated to this product
BX8071514100F, 6094463, CPI314100F, CPI3-14100F, 5032037279093
Processor |
---|
Processor generation | Intel Core i3-14xxx |
Processor manufacturer | Intel |
Cooler included | Yes |
Processor codename | Raptor Lake |
Memory bandwidth supported by processor (max) | 76.8 GB/s |
Processor cache | 12 MB |
Processor ARK ID | 236786 |
Processor family | Intel ® Core™ i3 |
Processor cores | 4 |
Processor socket | LGA 1700 |
Box | Yes |
Processor model | i3-14100F |
Processor threads | 8 |
Processor operating modes | 64-bit |
Processor boost frequency | 4.7 GHz |
Stepping | H0 |
Processor cache type | Smart Cache |
Performance cores | 4 |
Performance-core boost frequency | 4.7 GHz |
Performance-core base frequency | 3.5 GHz |
Processor base power | 58 W |
Maximum turbo power | 110 W |
Maximum number of DMI lanes | 8 |
Memory |
---|
Maximum internal memory supported by processor | 192 GB |
Memory types supported by processor | DDR4-SDRAM, DDR5-SDRAM |
Memory bandwidth supported by processor (max) | 76.8 GB/s |
Memory channels | Dual-channel |
Memory bandwidth (max) | 76.8 GB/s |
Graphics |
---|
Discrete graphics card | No |
On-board graphics card model | Not available |
On-board graphics card | No |
Discrete graphics card model | Not available |
Features |
---|
Maximum number of PCI Express lanes | 20 |
Processor package size | 45 x 37.5 mm |
Processor ARK ID | 236786 |
Thermal Monitoring Technologies | Yes |
Idle States | Yes |
Execute Disable Bit | Yes |
PCI Express slots version | 4.0, 5.0 |
PCI Express configurations | 1x16+1x4, 2x8+1x4 |
Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
Scalability | 1S |
Embedded options available | No |
CPU configuration (max) | 1 |
Market segment | Desktop |
Harmonized System (HS) code | 8542310001 |
Export Control Classification Number (ECCN) | 5A992C |
Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
Use conditions | PC/Client/Tablet |
Direct Media Interface (DMI) Revision | 4.0 |
Processor special features |
---|
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel 64 | Yes |
Intel ® Speed Shift Technology | Yes |
Intel ® Turbo Boost Technology | 2.0 |
Intel ® Hyper Threading Technology (Intel ® HT Technology) | Yes |
Intel ® AES New Instructions (Intel ® AES-NI) | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel ® OS Guard | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel ® Secure Key | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel ® Boot Guard | Yes |
Intel ® Volume Management Device (VMD) | Yes |
Intel ® Deep Learning Boost (Intel ® DL Boost) | Yes |
Mode-based Execute Control (MBE) | Yes |
Intel ® Control-flow Enforcement Technology (CET) | Yes |
Intel ® Gaussian & Neural Accelerator (Intel ® GNA) 3.0 | Yes |
Intel ® Standard Manageability (ISM) | Yes |
Operational conditions |
---|
Tjunction | 100 °C |
Technical details |
---|
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel 64 | Yes |
Status | Launched |
Market segment | Desktop |
Launch date | Q1'24 |
Intel Virtualization Technology (VT-x) | Yes |
Processor cache type | Smart Cache |
Harmonized System (HS) code | 8542310001 |
Export Control Classification Number (ECCN) | 5A992C |
Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
Logistics data |
---|
Harmonized System (HS) code | 8542310001 |
Weight & dimensions |
---|
Processor package size | 45 x 37.5 mm |
Other features |
---|
Maximum internal memory | 192 GB |
L2 cache | 5120 KB |
CPU configuration (max) | 1 |
Intel i3 14100F CPU 3.5GHz (4.7GHz Turbo) 14th Gen LGA1700 4-Cores 8-Threads 17MB 58W Graphics Card Required Retail Raptor Lake with Fan
Essentials
Product Collection Intel ® Core™ i3 Processors (14th gen)
Code Name Products formerly Raptor Lake
Processor Number i3-14100F
CPU Specifications
Total Cores 4
# of Performance-cores 4
# of Efficient-cores 0
Total Threads 8
Max Turbo Frequency 4.7 GHz
Performance-core Max Turbo Frequency 4.7 GHz
Performance-core Base Frequency 3.5 GHz
Cache 12 MB Intel ® Smart Cache
Total L2 Cache 5 MB
Processor Base Power 58 W
Maximum Turbo Power 110 W
Memory Specifications
Max Memory Size (dependent on memory type) 192 GB
Memory Types Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels 2
Max Memory Bandwidth 76.8 GB/s
Expansion Options
Direct Media Interface (DMI) Revision 4
Max # of DMI Lanes 8
Scalability 1S Only
PCI Express Revision 5.0 and 4.0
PCI Express Configurations ‡ Up to 1x16+4 | 2x8+4
Max # of PCI Express Lanes 20
Package Specifications
Sockets Supported FCLGA1700
Max CPU Configuration 1
Thermal Solution Specification PCG 2020C
TJUNCTION 100 °C
Package Size 45.0 mm x 37.5 mm
