All stock codes associated to this product
BX8071514900F, 6094384, CPI914900F, CPI9-14900F, 5032037279208
| Processor |
|---|
| Processor generation | Intel Core i9-14xxx |
| Processor manufacturer | Intel |
| Cooler included | Yes |
| Processor codename | Raptor Lake |
| Memory bandwidth supported by processor (max) | 89.6 GB/s |
| Processor cache | 36 MB |
| Processor ARK ID | 236853 |
| Processor family | Intel ® Core™ i9 |
| Processor cores | 24 |
| Processor socket | LGA 1700 |
| Box | Yes |
| Processor model | i9-14900F |
| Processor threads | 32 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 5.8 GHz |
| Stepping | B0 |
| Processor cache type | Smart Cache |
| Performance cores | 8 |
| Efficient cores | 16 |
| Performance-core boost frequency | 5.4 GHz |
| Performance-core base frequency | 2 GHz |
| Efficient-core boost frequency | 4.3 GHz |
| Efficient-core base frequency | 1.5 GHz |
| Processor base power | 65 W |
| Maximum turbo power | 219 W |
| Maximum number of DMI lanes | 8 |
| Memory |
|---|
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM, DDR5-SDRAM |
| Memory bandwidth supported by processor (max) | 89.6 GB/s |
| Memory channels | Dual-channel |
| Memory bandwidth (max) | 89.6 GB/s |
| Graphics |
|---|
| Discrete graphics card | No |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card model | Not available |
| Features |
|---|
| Maximum number of PCI Express lanes | 20 |
| Processor package size | 45 x 37.5 mm |
| Processor ARK ID | 236853 |
| Thermal Monitoring Technologies | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| PCI Express slots version | 4.0, 5.0 |
| PCI Express configurations | 1x16+1x4, 2x8+1x4 |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Scalability | 1S |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Market segment | Desktop |
| Harmonized System (HS) code | 8542310001 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Use conditions | PC/Client/Tablet |
| Direct Media Interface (DMI) Revision | 4.0 |
| Processor special features |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Intel Turbo Boost Max Technology 3.0 | Yes |
| Intel ® Speed Shift Technology | Yes |
| Intel ® Turbo Boost Technology | 2.0 |
| Intel ® Hyper Threading Technology (Intel ® HT Technology) | Yes |
| Intel ® AES New Instructions (Intel ® AES-NI) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel ® OS Guard | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel ® Secure Key | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel ® Boot Guard | Yes |
| Intel ® Thermal Velocity Boost | Yes |
| Intel ® Volume Management Device (VMD) | Yes |
| Intel ® Deep Learning Boost (Intel ® DL Boost) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel ® Turbo Boost Max Technology 3.0 frequency | 5.6 GHz |
| Intel ® Control-flow Enforcement Technology (CET) | Yes |
| Intel ® Thermal Velocity Boost Frequency | 5.8 GHz |
| Intel ® Thread Director | Yes |
| Intel ® Gaussian & Neural Accelerator (Intel ® GNA) 3.0 | Yes |
| Intel ® Standard Manageability (ISM) | Yes |
| Intel ® Adaptive Boost Technology | Yes |
| Operational conditions |
|---|
| Tjunction | 100 °C |
| Technical details |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Status | Launched |
| Market segment | Desktop |
| Launch date | Q1'24 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor cache type | Smart Cache |
| Harmonized System (HS) code | 8542310001 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Logistics data |
|---|
| Harmonized System (HS) code | 8542310001 |
| Weight & dimensions |
|---|
| Processor package size | 45 x 37.5 mm |
| Other features |
|---|
| Maximum internal memory | 192 GB |
| L2 cache | 32768 KB |
| CPU configuration (max) | 1 |
Intel i9 14900F CPU 4.3GHz (5.8GHz Turbo) 14th Gen LGA1700 24-Cores 32-Threads 68MB 65W Graphics Card Required Retail Raptor Lake with Fan
Essentials
Product Collection Intel ® Core™ i9 Processors (14th gen)
Code Name Products formerly Raptor Lake
Vertical Segment Desktop
Processor Number i9-14900F
CPU Specifications
Total Cores 24
# of Performance-cores 8
# of Efficient-cores 16
Total Threads 32
Max Turbo Frequency 5.8 GHz
Intel ® Thermal Velocity Boost Frequency 5.8 GHz
Intel ® Turbo Boost Max Technology 3.0 Frequency ‡ 5.6 GHz
Performance-core Max Turbo Frequency 5.4 GHz
Efficient-core Max Turbo Frequency 4.3 GHz
Performance-core Base Frequency 2 GHz
Efficient-core Base Frequency 1.5 GHz
Cache 36 MB Intel ® Smart Cache
Total L2 Cache 32 MB
Processor Base Power 65 W
Maximum Turbo Power 219 W
Memory Specifications
Max Memory Size (dependent on memory type) 192 GB
Memory Types Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels 2
Max Memory Bandwidth 89.6 GB/s
Expansion Options
Direct Media Interface (DMI) Revision 4
Max # of DMI Lanes 8
Scalability 1S Only
PCI Express Revision 5.0 and 4.0
PCI Express Configurations ‡ Up to 1x16+4 | 2x8+4
Max # of PCI Express Lanes 20
Package Specifications
Sockets Supported FCLGA1700
Max CPU Configuration 1
Thermal Solution Specification PCG 2020C
TJUNCTION 100 °C
Package Size 45.0 mm x 37.5 mm
