Scanning |
---|
Type | Built-in bar code reader |
Sensor type | CMOS |
Linear (1D) barcodes supported | Codabar, Code 128, Code 32, Code 39, Code 93, Discrete 2 of 5, EAN 128, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, Interleaved 2 of 5, JAN, MSI, Plessey, Trioptic, UPC-A, UPC-E |
2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, Han Xin, Micro QR Code, MicroPDF417, PDF417, QR Code |
Scanner type | 1D/2D |
Ports & interfaces |
---|
Connectivity technology | Wired |
Standard interfaces | RS-232, RS-485, USB |
Performance |
---|
Product colour | Black, Stainless steel |
Keys quantity | 4 keys |
LED indicators | Yes |
Buzzer | Yes |
Image formats supported | BMP, JPEG |
Design |
---|
Product colour | Black, Stainless steel |
Type | Built-in bar code reader |
Keys quantity | 4 keys |
LED indicators | Yes |
Power |
---|
Power source type | AC, RS-232, USB |
Power consumption (typical) | 5.5 W |
Power consumption (standby) | 3 W |
Input voltage | 90 - 264 V |
Input frequency | 47 - 63 Hz |
Weight & dimensions |
---|
Width | 292 mm |
Depth | 102 mm |
Height | 128 mm |
Weight | 5.7 kg |
Operational conditions |
---|
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 20 - 95% |
Technical details |
---|
Harmonized System (HS) code | 84716070 |
Logistics data |
---|
Harmonized System (HS) code | 84716070 |
