Scanning |
---|
Type | Handheld bar code reader |
Linear (1D) barcodes supported | Code 39, EAN-13, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, PDF417, Planet, POSTNET, U.P.C. |
2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code |
Wavelength | 650 nm |
Scanner type | 1D/2D |
Motion tolerance (cm/s) | 88.9 |
Tilt reading angle | 0 - 360° |
Pitch reading angle | -65 - 65° |
Yaw reading angle | -65 - 65° |
Light levels (direct sunlight) | 0 - 100000 lx |
Optical sensor resolution (W x H) | 1280 x 800 pixels |
Ports & interfaces |
---|
Connectivity technology | Wired |
Standard interfaces | USB |
Performance |
---|
Product colour | Black |
International Protection (IP) code | IP52 |
Protection features | Shock resistant |
Built-in display | No |
Certification | IEC 60825 Class 2 |
Image formats supported | BMP, JPEG |
Light levels (direct sunlight) | 0 - 100000 lx |
Design |
---|
Product colour | Black |
Type | Handheld bar code reader |
International Protection (IP) code | IP52 |
Protection features | Shock resistant |
Certification | IEC 60825 Class 2 |
Power |
---|
Power source type | DC |
Input voltage | 5 V |
Power consumption | 300 mA |
Weight & dimensions |
---|
Width | 68 mm |
Depth | 109 mm |
Height | 166 mm |
Weight | 161 g |
Packaging data |
---|
Cables included | USB |
Operational conditions |
---|
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 0 - 95% |
Light levels (direct sunlight) | 0 - 100000 lx |
Technical details |
---|
Sustainability certificates | RoHS |
Harmonized System (HS) code | 84716070 |
Compliance certificates | RoHS |
Packaging content |
---|
Cables included | USB |
Logistics data |
---|
Harmonized System (HS) code | 84716070 |
