TGC DH-2908 Server Chassis 2U 670mm Depth with 8x 3.5" Hot-Swappable SATA/SAS Drive Bays, 12Gb/s MiniSAS

IMG 1 of 1
Our Price:
$835.00
or quickly purchase this product
Backorder
Part Number:
550349
(?) Brand:
TGC
Manuf No:
DH-2908
DH2908
Shipping Weight:
25 KG (Includes product packaging)
Estimate Shipping
Details Files Finance Images & Video

Enter email address to be notified when this item is available again

All stock codes associated to this product
DH-2908, DH2908

Part# DH-2908

  • 2U Rackmount Server Chassis
  • 483 x 670 x 88mm
  • Single or Redundant 2U PSU Compatibility
  • Supports EEB, CEB, ATX, and Micro ATX M/B Form Factors
  • 8 Hotswap 3.5 Drive Bays
  • 7 Low Profile PCI Expansion Slots
  • The Sliding Rail Kit is not included but can be ordered separately with part numberTGC-03Y

Features:

  • 2U rackmount design, compatible with standard 19 server racks
  • Black front panel finish for a professional and sleek appearance
  • 8 x 3.5 hot-swappable drive bays with MiniSAS (SFF-8643) connectors
  • Supports EEB (12 x 13), CEB (12 x 10.5), ATX (12 x 9.6), and Micro ATX (9.6 x 9.6) motherboards
  • Front panel with power and reset switches, plus power, LAN, and HDD LED indicators
  • 4 x 80mm high CFM PWM fans for optimal cooling (3 fixed, 1 optional)
  • Supports single or redundant 2U power supplies for power redundancy
  • 2 x USB 3.0 front-accessible ports for fast data transfer
  • Approximate weight: 12.6kg

Specifications:

  • Drive Bay: 8 x 3.5 Hot-Swappable SATA/SAS Drive Bays
  • Cooling Fans: 4 x 80mm High CFM PWM Fans (3 fixed, 1 optional)
  • Switch: Power ON/OFF x 1, System reset x 1
  • Indicator: Power ON/OFF x 1, HDD x 1, LAN x 1
  • Connector: Front accessible USB 3.0 port x 2
  • Motherboard Compatibility:
    • EEB (12 x 13)
    • ATX (12 x 9.6)
    • CEB (12 x 10.5)
    • Micro ATX (9.6 x 9.6)
  • Power Supply: Single 2U or Redundant 2U 1+1 (TGC or Delta)
  • Dimensions (WxDxH): 483 x 670 x 88 mm
  • Packing: Double-boxed
  • Weight: 12.6 kg (approx)
  • Environment Temperature:0/55 C, 32/131 F (Operating) -20/60 C, -4/140 F (Non-Operating)
  • Relative Humidity: 5% to 95%, non-condensing
  • Vibration (5-500Hz): 1 Grms (Operating), 2 G (Non-Operating)
  • Shock: 10 G (11ms duration, half sine wave) (Operating), 30 G (Non-Operating)

No additional files, specification sheets, guides or documentation found for product.

Warranty: 12 months*

Full manufacturers warranty details are available at the manufacturers web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
