GENERAL |
|
|
Phase |
Single
Phase |
|
Form
Factor |
Rackmount,
Tower |
|
UPS
Topology |
Online
Double Conversion |
|
Energy
Saving Technology |
Online
ECO Mode Efficiency > 95% |
|
Active
PFC Compatibility |
Yes |
|
INPUT |
|
|
Generator
Compatibility |
Yes |
|
Nominal
Input Voltage ( Vac ) |
230
10% |
|
Input
Voltage Range ( Vac ) |
160
~ 300 |
|
Adjustable
Voltage Range ( Vac ) |
0~30%
Load for 80 ~ 300 Vac |
|
0~60%
Load for 120 ~ 300 Vac |
|
0~80%
Load for 140 ~ 300 Vac |
|
0~100%
Load for 160 ~ 300 Vac |
|
Input
Frequency ( Hz ) |
50
10 |
|
60
10 |
|
Input
Frequency Detection |
Auto-sensing |
|
Rated
Input Current ( A ) |
4.5 |
|
Input
Power Factor |
0.99 |
|
Input
Connector Type |
IEC
C14 |
|
Detachable
Power Cord Plug Type |
Schuko x 1 |
|
Power
Cord Length (ft.) |
5 |
|
Power
Cord Length (m.) |
1.5 |
|
OUTPUT |
|
|
Capacity
(VA) |
1000 |
|
Capacity
(Watts) |
900 |
|
On
Battery Waveform |
Pure
Sine Wave |
|
On
Battery Voltage(s) ( Vac ) |
208
1% |
|
220
1% |
|
230
1% |
|
240
1% |
|
Output
Voltage Setting |
Configurable |
|
On
Battery Frequency ( Hz ) |
50
0.5% |
|
60
0.5% |
|
Output
Frequency Setting |
Configurable |
|
Power
Factor |
0.9 |
|
ECO
Mode Voltage Tolerance |
15
% |
|
Overload
Protection |
Internal
Current Limiting, Circuit Breaker, Fuse |
|
Overload
Protection (Line Mode) |
110~120%
Load for 1 min, >120% Load Immediately |
|
Overload
Protection (Battery Mode) |
110~120%
Load for 10 sec, >120% Load Immediately |
|
Overload
Protection (Bypass Mode) |
>130%
Load Immediately |
|
Crest
Factor |
3:01 |
|
Harmonic
Distortion (Linear Load) |
THD3% |
|
Harmonic
Distortion (Non-linear Load) |
THD5% |
|
Internal
Bypass |
Automatic
Bypass, Manual Bypass |
|
Outlet(s)
- Total |
8 |
|
Outlet
Type |
IEC
C13 x 8 |
|
Outlet(s)
- Battery & Surge Protected |
8 |
|
Outlet(s)
- Critical Load (CL) |
4 |
|
Outlet(s)
- Non-Critical Load (NCL) |
4 |
|
Typical
Transfer Time ( ms ) |
0 |
|
BATTERY |
|
|
Runtime
at Half Load ( min ) |
11 |
|
Runtime
at Full Load ( min ) |
4 |
|
Typical
Recharge Time ( Hours ) |
4 |
|
Maximum
Charging Current ( A ) |
1.5 |
|
Start
On Battery |
Yes |
|
Smart
Battery Management (SBM) |
Yes |
|
User-replaceable |
Yes
- Qualified Personnel Only |
|
Battery
Type |
Sealed
Lead-acid |
|
Replacement
Battery Pack |
RBP0156 |
|
RBP
Quantity ( pcs ) |
1 |
|
Battery
Quantity (Each RBP) ( pcs ) |
2 |
|
Battery
Voltage (Each RBP) ( V ) |
24 |
|
Compatible
Extended Battery Module (EBM) |
BPSE24V40ART2U |
|
Extended
Battery Module Auto-detection |
Yes |
|
Max.
EBM Quantity ( pcs ) |
3 |
|
SURGE
PROTECTION & FILTERING |
|
|
Surge
Suppression ( Joules ) |
363 |
|
EMI/RFI
Filtration |
Yes |
|
Phone/Network
Protection RJ11/RJ45 (Combo) |
1-in,
1-out |
|
MANAGEMENT
& COMMUNICATIONS |
|
|
LCD
Panel |
Yes |
|
LCD
Types |
Color
LCD |
|
LCD
Information Display |
Operation
Type, Power Status, Battery Status, Load Status, Fault & Warning,
Other Information, Event & Log |
|
LCD
Setting & Control |
Mode
Setting, Alarm Setting, Input & Output, Battery
Setting |
|
HID
Compliant USB Port(s) |
1 |
|
Dry
Contact (with Relay) |
Yes |
|
Emergency
Power Off (EPO) Port |
Yes |
|
Audible
Alarms |
Battery
Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace
Battery |
|
Management
Cable ( pcs ) |
Power
Cord x2, USB Cable x1 |
|
Power
Management Software |
PowerPanel
Business (Recommended) |
|
SNMP/HTTP
Remote Monitoring |
Yes
- with optional RMCARD205 |
|
PHYSICAL |
|
|
Enclosure
Construction |
Metal |
|
Color |
Black |
|
Rackmount
Rail |
Yes |
|
Rackmount
Ears |
Yes |
|
PHYSICAL
SIZE - UPS MODULE |
|
|
Dimensions
(WxHxD) (in.) |
17.24
x 3.46 x 16.93 |
|
Dimensions
(WxHxD) (mm.) |
438
x 88 x 430 |
|
Weight
(lbs.) |
29.8 |
|
Weight
(kg.) |
13.5 |
|
Installed
Rack Height ( U ) |
2 |
|
SHIPPING
DIMENSIONS |
|
|
Dimensions
(WxHxD) (in.) |
21.3
x 9 x 21.7 |
|
Dimensions
(WxHxD) (mm.) |
540
x 230 x 550 |
|
Weight
(lbs.) |
39.1 |
|
Weight
(kg.) |
17.7 |
|
ENVIRONMENTAL |
|
|
Operating
Temperature (F) |
32
~ 104 |
|
Operating
Temperature (C) |
0
~ 40 |
|
Operating
Relative Humidity
(Non-condensing) ( % ) |
20
~ 90 |
|
Operating
Elevation ( feet/meters ) |
0-4,921
feet (0-1,500 meters) |
|
Storage
Temperature (F) |
-4
~ 122 |
|
Storage
Temperature (C) |
-20
~ 50 |
|
Storage
Relative Humidity
(Non-condensing) ( % ) |
10
~ 90 |
|
Storage
Elevation ( feet/meters ) |
0-4,921
feet (0-1,500 meters) |
|
Online
Thermal Dissipation ( BTU/hr ) |
380 |
|
Variable
Speed Fans |
20
steps automatically |
|
Audible
Noise at 1.5M from Surface of
Unit ( dBA ) |
45 |
|
CERTIFICATIONS |
|
|
Certifications |
CE,
EAC |
|
RoHS |
Yes |
|
WARRANTY |
|
|
Product
Warranty Period (Year) |
2 |
|
Battery
Warranty Period (Year) |
2 |
