All stock codes associated to this product
M90UHD
Mechanical Arm Visualizer (Document Camera)
The M90UHD is a visualizer with an impressive lineup of features that include a 13-megapixel camera, 4K imaging, and a transcendent 322X total zoom capacity. These characteristics help teachers demonstrate all types of materials in an extraordinarily vivid way. What’s more, instinctive function buttons, an extendable arm, and AVerTouch software allow teachers of any subject to create fantastic collaborations in next to no time.
The Only 322X Total Zoom
Equipped with a 14X optical and 23X digital zoom, the M90UHD’s amazing 322X total zoom buries the competition. Every student—even the ones in the back row—can enjoy a wonderful learning journey without missing a single detail.
Splendid 4K Image Quality
Ultra HD output resolution and 13 megapixels display every subtle detail of topographical maps, chemical experiments, stereo models, and more. This clarity improves teaching quality and enhances student comprehension.
One-Push Recording, Capturing, and Playback
Intuitive recording and capturing enable users to record the complete teaching process with one button. Also, the playback function lets teachers review their lessons and examine student behavior to successfully prevent any accidents.
Massive A3 Shooting Area
A larger than A3-size shooting area captures items as big as building models. In addition, the position indicator on the camera head helps teachers always display materials accurately.
Multiple Ports Fit Any Device
With HDMI, VGA, and USB jacks available, users can connect the M90UHD to any display or computer and use the devices they’re most familiar with to teach.
Super-Efficient Mechanical Arm
Featuring a low center of gravity and a fully adjustable, neatly foldable mechanical arm, the visualizer is easy to operate with only one hand and takes up minimal storage space.
Rapid Autofocus Banishes Blur
Some visualizers have a difficult time focusing on moving objects, but not this one. A single press of a button activates a premium-quality autofocus function that instantly clarifies the image and maintains students’ attention.
Embedded Light
The M90UHD offers an embedded light for adjusting luminance. Even in a dark presentation environment, teachers can easily provide a comfortable viewing experience.
AVerTouch Software
AVerTouch is ultra-powerful software designed exclusively for AVer visualizers. One touch connects your visualizer with mobile devices for content sharing, and you can sync to the cloud to automatically save annotated, captured, and recorded files. Teaching is incredibly fun when you use AVerTouch to engage with your students.
Specifications
Image Sensor 1/3.06" CMOS
Total Pixels 13 Megapixels
Output Resolution 4K
Full HD 1080p 60Hz HD 720p 60Hz
TV Lines 1,400
Zoom 322X
Total Zoom (14X Optical Zoom x 23X Digital Zoom)
Frame Rate 60fps (max.)
Focus Auto / Manual
Shooting Area A3 (420 x 315 mm max.)
Image Rotation Electronic: 0°, 180°
Mechanical: 0°, 90°, 180° (Camera Head)
Internal Storage 200 Pictures at XGA (1024 x 768)
External Storage Micro SD Card &USB Thumb Drive (FAT32 / 32 GB)
One-touch Recording Yes
One-touch Capturing Yes
Capture Modes Single / Continuous
User Profiles Yes, up to 3
Timer Yes
Flicker Filter Control Yes
ePTZ Yes
Light Source Embedded LED Lamp
HDMI I/O 1 in / 1 out
VGA I/O 1 in / 1 out
USB 2.0 Ports Type-A x 1 (USB Thumb Drive)
Type Mini-B x 1 (PC)
Audio Line out (3.5 mm)
Mic in (3.5 mm)
Built-in Mic
HDMI
Security Kensington Slot
Dimensions (W x D x H) Operating: 159.0 x 481.3 x 469.9 mm
Folded: 176.0 x 319.0 x 112.0 mm
Net Weight 2.2 kg
Power Source DC 5V / 3A
AC 100 to 240V, 50 / 60Hz
Warranty Visualizer: 5 Years
Accessories: 1 Year
Software AVerTouch
Windows OS Windows® 7, 10, 11
Mac OS Mac® 10.15, 11, 12
Chromeâ„¢ OS Chromeâ„¢ OS 75 or Later
(Available via the Sphere Lite App Only)
Package Contents
AVerVision M90UHD Unit
USB Cable
VGA Cable
Power Cable
Power Adapter (5V / 3A)
Remote Control with AAA Batteries x 2
Warranty Card
Quick Start Guide
CD
* Specifications may vary depending on location and are subject to change without notice.
