All stock codes associated to this product
WNDAP350, 606449064629
Performance - Wireless N with Concurrent dual band operation with quality of service
Mobility Up to 15x the speed and 10x the coverage of legacy products
Security Full enterprise security with WAP, WPA2, 802.1x with Radius and built in rogue AP detection
Advanced Speed and Range with Comprehensive Internet Security
- Up to 15x the speed and 10x the coverage of 802.11g networks
- Concurrent operation in 2.4 GHz and 5 GHz radio band for maximum wireless throughput
- Backward compatibility with 802.11a, 802.11g and 802.11b network devices
- Security features include WPA, WPA2, rogue AP detection and 802.1x with RADIUS support
- Support for 802.3af PoE for optimal placement of access point
Features
- Up to 15x the speed and 10x the coverage of 802.11a, 802.11g networks
- Operation in 5 GHz radio band to avoid interference from 802.11b or 802.11g network devices
- Concurrent operation in 2.4 GHz and 5 GHz radio band
- Backward compatibility with 802.11a, 802.11g and 802.11b network devices
- Integrated 802.3af PoE eliminates extra cables and enables optimal placement of the access point
- Comprehensive SNMP functionality for advanced network management
- Deploy wireless coverage over large areas with point-to-point and point-to-multipoint bridging via Wireless Distribution System (WDS)
- Security features include WPA, WPA2, rogue AP detection and 802.1x with RADIUS support
- Plenum-rated for safe and convenient placement above drop-down ceilings
- Metal case includes Kensington lock slot for anti-theft
- Internal antennas factory-optimized for maximum RF performance
- Antenna take-offs enable optional accessory antenna attachment for 2.4 GHz operations
- Lifetime hardware warranty
Specifications
Standards
- IEEE 802.11n draft 2.0 specification, 2.4 GHz and 5.0 GHz
- IEEE 802.11a 5.0 GHz
- IEEE 802.11g, IEEE 802.11b, 2.4 GHz
- WMM - Wi-Fi Multimedia prioritization
- Wireless Distribution System
- IEEE 802.3af Power over Ethernet (PoE)
Physical Specifications
- Dimensions: 32 x 190 x 124 mm (1.25 x 7.5 x 4.9 in)
- Weight: (.56 kg) 1.2 lb
Physical Interfaces
- One (1) 10/100/1000BASE-T Gigabit Ethernet (RJ-45) port with Auto Uplink (Auto MDI-X) with IEEE 802.3af Power over Ethernet (PoE) support
- Power adapter: 12V DC, 1A; plug is localized to country of sale
- Five(5) LEDs: Power, test, 100/1000 Mbps, link/ACT, 2.4 GHz band, 5.0 GHz band
- One (1) console port with standard RS-232C interface with DB-9 male connector
- Two (2) reverse SMA antenna connectors
Note: Not recommended for use with ProSafe Antennas ANT2405, ANT2409 or ANT24D18.
Power over Ethernet Required
Security
- Wi-Fi Protected Access (WPA, WPA2)
- Wired Equivalent Privacy (WEP) 64-bit, 128-bit encryption
- IEEE 802.1x RADIUS authentication with EAP TLS, TTLS, PEAP
- Wireless access control to identify authorized wireless network devices
- MAC address authentication
- VPN pass-through support
- Secure SSH telnet
- Secure Sockets Layer (SSL) remote management login
Network Management
- Remote configuration and management through Web browser, SNMP or telnet with Command Line Interface (CLI)
- SNMP management supports SNMP MIB I, MIB II, 802.11 MIB and proprietary configuration MIB
Advanced Wireless Features
- Point-to-point wireless bridge mode
- Point-to-multipoint wireless bridge mode
- Repeater mode
- Simultaneous wireless bridge and access point mode
- Wireless Distribution System (WDS)
- Adjustable transmit power control (TPC) from 100 mW down to 0 mW
Warranty
- Access point: NETGEAR Lifetime Warranty
- Power supply: 3-year warranty
Package Contents
- ProSafe Dual Band Wireless Access Point (WNDAP350)
- Ethernet cable
- Wall-mount kit
- Installation guide
- Resource CD
- 12V, 1A power adapter, localized to country of sale
Ordering Information
- North America: WNDAP350-100NAS
- Europe: WNDAP350-100ISS
- UK: WNDAP350-100UKS
- Asia: WNDAP350-100AUS
- Japan: WNDAP350-100JPS
ProSupport Service Packs Available
OnCall 24x7, Category 1
- PMB0331-100 (US)
- PMB0331 (non-US)
XPressHW, Category 1
This product is packaged with a limited warranty, the acceptance of which is a condition of sale. This product has been tested for quality assurance and this product or its components may have been recycled.
*Basic technical support provided for 90 days from date of purchase.
Maximum wireless signal rate derived from IEEE standard 802.11 specifications. Actual data throughput and wireless coverage will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate and wireless coverage. NETGEAR makes no express or implied representations or warranties about this products compatibility with any future standards.
"N", "Wireless-N" and "draft 802.11n" refer to compliance with IEEE 802.11n draft specification version 2.0 only.
System Requirements
- 2.4 GHz 802.11n draft specification adapter or 2.4 GHz 802.11 b/g wireless adapter or 5 GHz 802.11a wireless adapter
- Microsoft Windows Vista, XP, 2000, 98, Me, Mac OS, UNIX, Linux
- Internet Explorer 6.0, Mozilla Firefox 1.5
- We recommend using this product with the RangeMax Dual Band Wireless USB 2.0 Adapter (WNDA3100)
