ATEN Sensor Box for GN0116 - 1 x AC Current Sensor, 1 x Humidity Sensor

No Longer Available

Part Number:

139762

(?) Brand:

ATEN

Manuf No:

EA2110

Shipping Weight:

1 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

EA2110

ALTUSEN Sensor Box for GN0116 - 1 x AC Current Sensor, 1 x Humidity Sensor

Sensor Box for GN0116

For remote environment monitoring and management of critical computer systems over IP networks, ATEN provides various sensor boxes to work in tandem with the GN0116 (Guardian Over the NET ). EA2110/EA2210/EA2310 enables you to get status feedback on AC current, AC voltage and humidity. The sensor boxes can simply be connected to the Voltage Analog Input port of the GN0116 via Cat 5 (or higher) cable, and then configured and monitored over the internet with a web browser.

Sensor Box:
* EA2110: 1 x AC Current Sensor and 1 x Humidity Sensor
* EA2210: 2 x AC Current Sensors
* EA2310: 1 x AC Current Sensor and 1 x AC Voltage Sensor

Features

	Easy configuration and operation via GN0116's browser GUI interface
	Humidity, voltage and current settings allow equipment to be monitored for irregularities
	Ranges available: 0-25A (RMS) (EA2110/EA2210), 0-15A (RMS) (EA2310)
	Compact size
	Non-powered - sensor boxes are powered by the attached GN0116
	Sensor boxes are connected to the GN0116 via standard Cat 5 (or higher) cable for environment status monitoring

Package Content

	1x EA2110,EA2210 or EA2310 Sensor
	1x AC Current Sensor+Cable (EA2110)
	2x AC Current Sensor+Cable (EA2210)
	1x AC Power Cord (EA2310)
	1x Mounting Kit

Diagram

+ View enlargement

Specification

Function		EA2110	EA2210	EA2310
Connectors	To System	1 x RJ-45 Female
	AC Current Sensor	1 x Terminal Block	2 x Terminal Block	N/A
	Power Inlet	N/A	1 x IEC 60320/C14
	Power Outlet	N/A	1 x IEC 60320/C13 or 1 x NEMA 5-15R
Switches	Circuit Breaker	N/A		1 x Pushbutton
LEDs	Power	1 (Green)
Humidity Sensor	Measurement Range	0-100% Relative Humidity	N/A
AC Current Sensor	Measurement Range	0-25A (RMS)		0-15A (RMS)
AC Voltage Sensor	Measurement Range	N/A		80-120 VAC; 210-240 VAC
	O/P Rating	N/A		80-120 VAC ~; 12A (Max.), 50/60Hz 210-240 VAC ~; 9A (Max.), 50/60Hz
	I/P Rating	N/A
Environment	Operating Temp.	0-50C
	Storage Temp.	-20-60C
	Humidity	0-80% RH, Non-condensing
Physical Properties	Housing	Metal
	Weight	0.31 kg	0.31 kg	0.58 kg
	Dimensions ( L x W x H )	10.80 x 9.00 x 3.75 cm	10.80 x 8.10 x 3.75 cm	14.00 x 10.61 x 4.40 cm
