All stock codes associated to this product
BIPAC3100SN, BIPAC 3100SN, 4719170002672
BiPAC 3100SN
Wireless-N Wall Plug Ethernet Access Point |
|
Extend your wireless coverage through Ethernet Access Point
The BiPAC 3100SN, a networking Router with integrated a 802.11n access point. The device can be used to bridge Ethernet devices such as wired modems or wireless routers, PCs, set-top-boxes, and game consoles, enabling users to share multimedia applications such as online games, IPTV and audio streaming with family or friends all around the house via Wi-Fi connections from room to room. The wireless-N Access Point can extend your wireless coverage with no more dead zones. Just plug the BiPAC 3100SN into any wall power socket, and you can easily set up a secure wireless network by pressing the Wi-Fi Protected Setup (WPS) button.
Key Features
Extended wireless coverage of up to 3 times the range of 802.11g products
WPS (Wi-Fi Protected Setup) for easy setup
Auto channel select
Supports Triple Play applications such as IPTV, VoIP and high-speed Internet access
Supports 10/100 BaseT Ethernet
Ideal for residential users
Extended Wireless CoverageWith an integrated 802.11n Wireless Access Point, the adapter can bridge wireless connections of up to 6 times the speed and 3 times the wireless coverage of an 802.11b / g network device. It supports a data rates up to 300Mbps and is also compatible with 802.11b / g equipment. The Wireless Protected Access (WPA-PSK / WPA2-PSK) and Wireless Encryption Protocol (WEP) features enhance the level of transmission security and access control over Wireless LAN. The device also supports the Wi-Fi Protected Setup (WPS) standard, allowing users to establish a secure wireless network by simply pushing a button.
Standards
Ethernet specifications: IEEE 802.3, IEEE 802.3x, IEEE 802.3u, Auto MDI/MDIX
Supported Operating Systems
Windows 98 / 98SE / Me / 2000 / XP / Vista
Other 10/100 Base-T Ethernet devices
Power Supply Specifications
Input: 100~240V AC, 50~60Hz
Protection: OCP, OVP, SCP
Wireless-N (device connection)
Compliant with IEEE 802.11n, 802.11g and 802.11b standards
2.4 GHz2.484 GHz frequency range
Auto channel select
Up to 300Mbps wireless operation rate
WPS (Wi-Fi Protected Setup) for easy setup
64/128 bits WEP supported for encryption
Wireless Security with WPA-PSK/ WPA2-PSK support
Hardware Specifications
Physical Interface
AC power plug
2x 2dbi antennas
WPS button
Reset button
RJ-45 compatible
LED display:
- POWER
- WLAN
- ETH
Physical Specifications
Dimensions (W, D, H):
4.42 x 3.05 x 1.75
(112.4mm x 77.4mm x 52.1mm)
Operating Environment
Operating temperature: 0 ~ 40 C
Storage temperature: -20 ~ 70 C
Humidity: 20 ~ 95% non-condensing
Networking
