Netgear WNDAP660 Dual Band Concurrent Premium Wireless N Access Point - 802.11a/g/n, 2-Port 10/100/1000 with Uplink (Auto MDI-X), Up To 450Mbps

No Longer Available

Part Number:

224569

(?) Brand:

Netgear Web Site

Manuf No:

WNDAP660-100AUS
WNDAP660100AUS

Shipping Weight:

1.5 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Finance Images & Video

All stock codes associated to this product

WNDAP660100AUS, WNDAP660-100AUS, 606449082203, 606449095807

PROSAFE ® Dual Band Concurrent Premium Wireless-N Access Point

WNDAP660

802.11n (3x3) Premium Access Point with throughput up to 450 Mbps
Advanced security with Wireless Intrusion Detection (WIDS) and Prevention (WIPS)
Dual band concurrent for both 2.4GHz and 5GHz radio band for maximum flexibility

Advanced Speed and Range with Comprehensive Internet Security

3 x 3 multiple-input, multiple-output (MIMO) with three spatial streams
Dual band concurrent in 2.4 and 5 GHz radio band for maximum wireless throughput
Stylish and elegant design with easy mounting options (e.g., ceiling, wall and desktop)
Backward compatibility with 802.11a, 802.11g and 802.11b network devices
Integrated Power over Ethernet (IEEE 802.3af and 802.3at PoE) lowers deployment costs
Deploy wireless coverage over large areas with point-to-point and point-to-multipoint bridging via Wireless Distribution System (WDS)
Security features include WPA, WPA2, rogue AP detection and 802.1x with RADIUS support
Internal antennas factory-optimized for maximum RF performance
Advanced Security with Wireless Intrusion Detection (WIDS) and Wireless Intrusion Prevention (WIPS) support
802.11n Beamforming to improve range and maximizes data rates
Device-based QoS to provide differentiated service level agreement to each user and device type
Bandsteering to load balance clients between 2.4 and 5 GHz
Redundant dual Ethernet ports to ensure maximum reliability

Specifications:

Standards

IEEE 802.11a 5GHz
IEEE 802.11g, IEEE 802.11b, 2.4GHz
IEEE 802.11n standard, 2.4GHz and 5GHz
WMM - Wireless MultiMedia prioritization
WDS - Wireless Distribution System
Power over Ethernet (PoE) IEEE 802.3af and 802.3at

Physical Specifications

Physical Dimensions (W x D x H): 253.75 x 253.76 x 54.76 mm(10.0 x 10.0 x 2.16 in)
Weight: 1.5 kg (3.31 lb)

Physical Interfaces

Two (2) 10/100/1000BASE-T Gigabit Ethernet (RJ-45) ports with Auto Uplink (Auto MDI-X) with IEEE 802.3af and 802.3at Power over Ethernet (PoE) support
Power adapter: 12V DC, 1.5A; plug is localized to country of sale
One (1) console port with RJ45 Interface
Three (3) reverse SMA antenna connectors
Five (5) LED: Power, Link/ACT, LAN, 2.4 GHz, 5 GHz

Security

Wi-Fi Protected Access (WPA, WPA2)
Wired Equivalent Privacy (WEP) 64-bit, 128-bit, and 152-bit encryption
IEEE 802.1x RADIUS authentication with EAP TLS, TTLS, PEAP
Wireless access control to identify authorized wireless network devices
MAC address authentication
VPN pass-through support
Secure SSH telnet
Security Sockets Layer (SSL) remote management login

Network Management

Remote configuration and management through Web browser, SNMP or telnet with command line interface (CLI)
SNMP management supports SNMP MIB I, MIB II, 802.11 MIB and proprietary configuration MIB

Advanced Wireless Features

Wireless Distribution System (WDS)
Bridge mode: Point-to-point wireless WDS mode
Bridge mode: Point-to-multipoint wireless WDS mode
Repeater mode
Adjustable Transmit Power Control (TPC) from 100 mW down to 0 mW

System Requirements

2.4 GHz/5 GHz 802.11n specification or 2.4 GHz 802.11b/g wireless adapter or 5 GHz 802.11a wireless adapter
Microsoft Windows Vista, XP, 2000, 98, Me, Mac OS, UNIX, or Linux
Internet Explorer 6.0 or Mozilla Firefox 1.5
We recommend using this product with N600 Wireless Dual Band USB Adapter (WNDA3100)

Package Contents

ProSafe Premium Dual BandWireless-N Access Point (WNDAP660)
Ethernet cable
Wall-mount kit
Installation guide
Resource CD
12V, 1A power supply
Warranty/support information card

Warranty

Access Point: ProSafe Lifetime Warranty
Power Supply: 3-year Warranty
